- Page 1 Feb 4, 2022 Ver1.00 USB3.0 I n G a A s NIR LINE SENSOR CAMERA ARTCAM-L1024TNIR Series INSTRUCTION BOOKLET ARTCAM-L1024DTNIR ARTCAM-L1024DBTNIR ARTRAY CO., LTD. - 1 -...
-
Page 2: Table Of Contents
Contents Attention ..............................- 3 - Introduction .............................. - 6 - Features ..............................- 6 - The Product .............................. - 6 - Connections .............................. - 7 - 5.1. Connecting Method ......................... - 7 - Specifications ............................- 8 - 6.1. Specifications ........................... -
Page 3: Attention
1. Attention ■About this Manual 1. Before using the camera, please read this manual thoroughly. 2. Please keep this manual reachable and always refer to the contents when needed. 3. Please contact us if the manual is lost or damaged. We will provide a replacement. 4. - Page 4 ■ For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own. Please stop using the product and turn off the power immediately when: ・...
- Page 5 For more details, please refer to the sites below: Hardware Warranty: http: //www.artray.us/download/artray_warranty.pdf ■ Dispose To dispose this product, please return the camera to us. If you decide to dispose the camera without returning it us, please follow related regulations and have the camera disposed as an industrial waste.
-
Page 6: Introduction
2. Introduction ARTCAM-L1024TNIR Series is a Near-infrared camera, which adopts InGaAs (Indium Gallium Arsenide) Linear Image Sensor and has high sensitivity to the wavelength band from 900nm to 1700nm Adopting USB3.0 interface, thus enables direct data transfer to PC without a capture board or a host adapter card. -
Page 7: Connections
5. Connections 5.1. Connecting Method Please connect the camera to the PC by using the attached USB3.0 cable. Camera’s power is supplied from the AC adapter (DC12V). - 7 -... -
Page 8: Specifications
6. Specifications 6.1. Specifications Items ARTCAM-L1024DTNIR ARTCAM-L1024DBTNIR Sensor Type G10768-1024D G10768-1024DB Model Number InGaAs Linear image sensor Active Pixels 1024 Active Image Size 25.6(H)×0.1(V)mm 25.6(H)×0.025(V)mm Scanning Mode Line scan Pixel Size 25(H)×100(V)μm 25(H)×25(V)μm Wavelength 900 ~ 1700nm Line Rate ≒31.446kHz (max.) Data Rate 5MHz Saturation Capacity... -
Page 9: Optional Functions
6.2. Optional Functions 6.2.1. Trigger Shooting (optional) External trigger function may be available based on your order options. This camera has an external trigger electronic circuit, which is insulated by a photocoupler, and thus enables synchronized shooting by the input signal received from the external circuit. HR10A-7R-6S(73)(HIROSE) ※The connector pin and pin assignment may be changed. -
Page 10: About The Terminals On The Back Of The Camera
6.2.3. About The Terminals On The Back Of The Camera External I/O terminal HR10A-7R-6S(73) (HIROSE) USB3.0 microB Port Power Port DC12V - 10 -... -
Page 11: Dimensional Outline
7. Dimensional Outline 7.1. ARTCAM-L1024DTNIR/L1024DBTNIR HR10A-7R-6S(73)(HIROSE) Drawing of the base without a tripod mount ※The above specifications may change. - 11 -... - Page 12 Illustrations of the relationship between the Mount and the Sensor surface - 12 -...
-
Page 13: Spectral Sensitivity Characteristics (Reference Value)
8. Spectral Sensitivity Characteristics (Reference Value) 8.1. ARTCAM-L1024DTNIR/ L1024DBTNIR - 13 -... -
Page 14: System Requirements
What may cause the problem is that the regulation of the power lines becomes not enough, and so causes impudence mismatch on data signals. *For the recommended extension cable, please contact our sales department. (TEL: +81-3389-5488) ARTRAY CO., LTD. Obtained ISO 9001: 2015 2018/9/17 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan Tel: +81-3-3389-5488 Fax: +81-3-3389-5486 Email: sales@artray.us...
