- Page 1 June 18, 2021 Ver1.00 Thermal Infrared Camera ARTCAM-384P2-THERMO INSTRUCTION BOOKLET ARTRAY CO., LTD. - 1 -...
-
Page 2: Table Of Contents
Contents Attention ..........................- 3 - Introduction ........................- 6 - Main Features........................- 6 - The Product ........................- 7 - Connections ........................- 7 - 5.1. How to Connect a Camera ..................- 7 - Specifications ........................- 8 - 6.1. -
Page 3: Attention
1. Attention ■About this manual 1．Before using the camera, please read this manual thoroughly. 2．Please keep this manual reachable and always refer to the contents when needed. 3．Please contact us if the manual is lost or damaged. We will provide a replacement. 4．We cannot guarantee the safety of improper uses of the camera. - Page 4 ■For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own. Please stop using the product and turn off the power immediately when: ・...
- Page 5 For more details, please refer to the sites below: Hardware Warranty: www.artray.us/download/artray_warranty.pdf ■Dispose To dispose this product, please return the camera to us. If you decide to dispose the camera without returning it us, please follow related regulations and have the camera disposed as an industrial waste.
-
Page 6: Introduction
2. Introduction ARTCAM-384P2-THERMO is a thermal infrared camera, which adopts microbolometer and sensitive to FIR wavelength between 8～14μm. The resolution of this camera is 384 x 288 pixels. Adopting USB2.0 interface, thus enables direct data transfer to PC without a capture board or a host adapter card. -
Page 7: The Product
4. The Product 1) Camera 2) 3m USB2.0 cable 3) Viewer Software (including temperature calibration data) < Option > 1) Germanium lens (Focal length : 6.2mm / 8mm / 13mm / 19mm) 5. Connections 5.1. How to Connect a Camera ・USB Output ・NTSC Output (Option) - 7 -... -
Page 8: Specifications
6. Specifications 6.1. Detailed specifications Items Sensor Type Uncooled Micro bolometer Detected Wavelength 8~14µm Interface USB2.0, NTSC (Option) Resolution 384(H) X 288(V) Pixel Pitch 17μm Output Bits 14bit Frame Rate 50fps Electronic shutter 56.88µs Operability > 99.8 % Temperature 0°C~120°C Measurement Range Temperature Resolution <... -
Page 9: Dimensional Outline
6.2. Dimensional outline - 9 -... -
Page 10: Systems Requirements
What may cause the problem is that the regulation of the power lines becomes not enough, and so causes impudence mismatch on data signals. *For the recommended extension cable, please contact our sales department. (TEL: +81-3389-5488) ARTRAY CO., LTD. Obtained ISO 9001: 2015 2018/9/17 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan Tel: +81-3-3389-5488 Fax: +81-3-3389-5486 Email: sales@artray.us...
