All manuals and user guides at all-guides.com CONGRATULATION FOR YOUR CHOICE! Matrix is the only splitter - switcher that allows musicians to control their equipment. Matrix is able to: - Buffer the signal of your guitar. Matrix - Insert in chain 3 low level loops. - Page 3 All manuals and user guides at all-guides.com MATRIX FLOW DIAGRAM In from Out to input From Amp Input Spk out Out to input pre/out Head L & R pre/head MATRIX head snd head return Power Out Mute Loop Loop Loop...
- Page 4 All manuals and user guides at all-guides.com...
- Page 5 All manuals and user guides at all-guides.com ® The following examples show you how to connect 2 heads, 1 foot pedal effect, 1 rack effect and 1 4x12” stereo speaker cabinet 8 ohm 9Vdc power cable Select 2x8ohm supplied cables (1 4x12”speaker cabinet) 220V-250mAT MADE IN ITALY SWITCHES...
- Page 6 All manuals and user guides at all-guides.com ® The following examples show you how to connect 2 heads, 1 foot pedal effect, 1 rack effect and 2 1x12” speaker cabinets 16 Ohm 9Vdc power cable Select 2x16ohm Supplied cables (2 1x12”speaker cabinets) (stereo jack) 220V-250mAT MADE IN ITALY SWITCHES...
-
Page 7: Power Amp
All manuals and user guides at all-guides.com ® The following examples show you how to connect 1 heads,1 pre and power amp, 2 foot pedal effects, 1 rack effect and 1 4x12” stereo speaker cabinet 8 ohm 9Vdc power cable Supplied cables Select 2x 8ohm Supplied cables... - Page 8 All manuals and user guides at all-guides.com ® The following example show you how to connect 1 head,1preamp (using the power amp of the head),2 foot pedal efx,1 rack efx, 1 4x12”cabinet 9 Vdc power cable supplied cables supplied cables (Jack stereo) (Jack stereo) (Jack stereo)
- Page 9 All manuals and user guides at all-guides.com ® The following example show you how to connect 2 preamp, 1 poweramp,2 footpedal efx,1rack efx, 1 stereo cabinet. 9 Vdc power cable supplied cables supplied cables (Jack stereo) (Jack stereo) (Jack stereo) (Jack stereo) 220V-250mAT MADE IN ITALY SWITCHES...
- Page 10 All manuals and user guides at all-guides.com ® The following example shows you how to connect 2 heads, 1 foot pedal effect, 1 rack effect and one speakers cabinet 16 Ohm. 9Vdc power cable Select 2x16ohm Supplied cables (2 1x12”speaker cabinets) (stereo jack) SWITCHES LOOPS...
- Page 11 All manuals and user guides at all-guides.com GENERAL INFORMATION SYNTHESIS EFFECTS The main characteristic of the synsthesis effect (see example) is to modify the signal wave form. (i.e. the distortion effects). This kind of effect should be used between the guitar and the input of your amp, in a standard connection chain. MODULATION EFFECTS The main characteristic of the modulation effect (see example) is to add and/or lay other wave forms to the signal.
-
Page 12: General Information
− In case of damage contact the shop where you bought the appliance. − The appliance must be earthed in conformity to the national previsions in force. For any further information and/or support contact us. Brunetti Marco & C. S.a.s Via Deí Bonomini, 25/27 I - 41100 MODENA - ITALIA Phone number : +39 059 / 243404 http://www.brunetti.it...
