WE LOVE WHAT WE DO.
BLOK-JET
SILENT
Instruction Manual
english

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BLOK-JET SILENT 1 Micro-Smart and is the answer not in the manual?

Questions and answers

Related Manuals for Cattani BLOK-JET SILENT 1 Micro-Smart

Summary of Contents for Cattani BLOK-JET SILENT 1 Micro-Smart

  • Page 1 WE LOVE WHAT WE DO. BLOK-JET SILENT Instruction Manual english...

  • Page 3: Table Of Contents

    CONTENTS General operation data Introduction Signs and warnings Assembly and startup Starting up, testing and instructing personnel. Compressor AC200 and AC300 operation Operation of suction unit Micro-Smart and Turbo-Smart Routine maintenance compressor AC200 and AC300 Extraordinary maintenance compressor AC200 and AC300 Routine maintenance Micro-Smart and Turbo-Smart Extraordinary maintenance Micro-Smart and Turbo-Smart Instructions for finding and changing parameters of Smart suction unit...

  • Page 4: General Operation Data

    GENERAL OPERATION DATA 50/60 HZ BLOK-JET SILENT 1 Model Micro-Smart AC200 Nominal voltage 230 V 230 V Nominal frequency 50/60 Hz 50 Hz Absorbed power 7,7 A Protection level against direct and indirect Class I Class I contacts Alternating operation with Method of use Continuous use physical adsorption dryer...
  • Page 5 GENERAL OPERATION DATA 50/60 HZ BLOK-JET SILENT 2 Model Turbo-Smart "B"** AC300 Nominal voltage 230 V 230 V Nominal frequency 50/60 Hz 50 Hz Absorbed power 7,5 A 10,2 A Protection level against direct and indirect Class I Class I contacts Alternating operation with Method of use...
  • Page 6 GENERAL OPERATION DATA Alternating current IEC 417-5032 Protective earth IEC 417-5019 Protection level against direct and indirect contacts CEI EN 60601-1 Open (disconnection from power supply mains) IEC 417-5008 Closed (disconnection from power supply mains) IEC 417-5007 Alternating current IEC 417-5032 Three-phase alternating current with neutral IEC 335-1 Earth (operation)

  • Page 7: Introduction

    Block- Jet Silent. Updated manuals are available from our website www.cattani.it . We recommend you refer SIGNS AND WARNINGS Read the manual before you assemble the device...

  • Page 8: Assembly And Startup

    ASSEMBLY AND STARTUP RECOMMENDED PRECAUTIONS Before opening the packaging check carefully for signs of damage and verify that the Shockwatch HANDLE WITH CARE indicator is not red. If it is red, accept the delivery WARNING WARNING “with reservations” after making sure that the SHOCKWATCH equipment is in perfect condition.
  • Page 9 ASSEMBLY AND CONNECTIONS Blok-Jet Silent 1 and 2 are designed for surgeries that need to reduce footprint and noise, they can be installed indoor provided the air exhausted by the suction unit is conveyed outside and the air for the compressor is supplied from the outside. We recommend you treat exhaust air and the air supplied to the compressor with HEPA H14 antibacterial filters.
  • Page 10 Make sure that the suction tubes are clear from debris. Insert the Ø 50 mm tube provided into “SUCTION” inlet no. (9), connect the suction of the Blok-Jet Silent unit to the central system of the clinic. Connect the Ø 50 mm heat-resistant tube to tube holder (10) (“EXHAUST AIR”).
  • Page 11 RECOMMENDED PRECAUTIONS Blok-Jet Silent is equipped with an internal ventilation system which, taking air from the room, lowers the internal temperature produced by the equipment during operation. The room will also have to be equipped with a ventilation system, with exhaustion and an inlet for air supply, in order to guarantee a flow that will maintain room temperature in the range + 5 °C to 35 °C.
  • Page 12 ASSEMBLY When Blok-Jet Silent is installed on a lower level level before connecting with the suction unit. This than the surgeries, the suction piping must go will remove the potential energy that the liquids down to the level of the suction unit, with a couple produce when flowing downward.

  • Page 13: Starting Up, Testing And Instructing Personnel. Compressor Ac200 And Ac300 Operation

    STARTING UP, TESTING AND INSTRUCTING PERSONNEL COMPRESSOR AC200 AND AC300 OPERATION STARTING UP, TESTING AND INSTRUCTING PERSONNEL Once you have assembled and electrically connected interpret danger warnings and light signals (3-4) and to the Blok-Jet Silent, simply switch on the unit (1) and correctly carry out maintenance operations with Puli-Jet send the permissive signal from one of the dental units plus new, Pulse Cleaner and antifoaming tablets.

  • Page 14: Operation Of Suction Unit Micro-Smart And Turbo-Smart

    OPERATION OF SUCTION UNIT MICRO-SMART AND TURBO-SMART OPERATION The suction assembly (9) (through tube 10) creates vacuum in the centrifugal separator (11). The fluid received from the surgeries, through the manifold tube (2) flows into the centrifugal separator (11). The centrifugal separator separates air from liquids: the air is exhausted outside through tube no.

  • Page 15: Routine Maintenance Compressor Ac200 And Ac300

    ROUTINE MAINTENANCE COMPRESSOR AC200 AND AC300 ROUTINE MAINTENANCE TO BE CARRIED OUT BY TRAINED MEMBERS OF THE SURGERY STAFF • Danger of electrical shock, even 230 V can be fatal. • High temperature. • Generic danger sign. • Obligatory direction of flow or rotation. Before getting close to the compressor remove power and make sure that nobody can restore power without informing the person in charge...

  • Page 16: Extraordinary Maintenance Compressor Ac200 And Ac300

    45/55 seconds AC200 and AC300. You can find it on our website while regeneration and cooling time is a third of the www.cattani.it in various languages. charging time. Check electrical absorption. Every time the compressor stops, a small amount of dry...

  • Page 17: Routine Maintenance Micro-Smart And Turbo-Smart

    ROUTINE MAINTENANCE MICRO-SMART AND TURBO-SMART ROUTINE MAINTENANCE Ordinary maintenance to be carried out by trained members of the surgery staff. • Be aware of hazard signs and protect yourself with glasses, gloves and disposable overalls. EVERY DAY • Check the display for possible alarms, if danger •...

  • Page 18: Extraordinary Maintenance Micro-Smart And Turbo-Smart

    EXTRAORDINARY MAINTENANCE MICRO-SMART AND TURBO-SMART EXTRAORDINARY MAINTENANCE Extraordinary maintenance is to be carried out by a trained technician, using original spare parts. • Be aware of hazard signs and wear protective glasses, gloves and disposable overalls. • Check maintenance condition, ensure that Magnolia products are being used.
  • Page 19 If you need a more detailed description, we invite you to refer to the operation manual of Smart suctions units. You can find it on our website www.cattani.it in various languages. cod: ed. 09-2021...

  • Page 20: Instructions For Finding And Changing Parameters Of Smart Suction Unit

    CHANGING PARAMETERS IN THE MENUS OF THE SMART SUCTION UNITS MAIN MENUS When the control unit is switched on, the graphic display will show the Cattani logo for 10 seconds, then the main menu will appear. MAIN MENU“A1” This menu shows parameters such as operating frequency, time for suction unit activation, temperature, amalgam container (if any) and system software revision.
  • Page 21 CONTROL MENU “A2” Counters – Odom . A2 Power Cycles 00000 Number of switch-ons from master switch Uptime [h] 00000 Total switch-on hours (with motors off) Work Cycles 00000 Number of activations by suction control Work Time [h] 00000 Actual operation hours (motors on) Aspirator [h] 00000 Hours operation in relation to frequency Fan Cycles...
  • Page 22 This is where you can adjust switch-off delay and other technical parameters. FACTORY SETTINGS RESTRICTED ACCESS Use of this menu is strictly reserved to Cattani. WI FI SETTINGS This menu can be accessed without a password; here you can set your Wi-Fi parameters.
  • Page 23 Password and the cursor will disappear. Press to go back to “Cattani SpA” menu. Now you can change the parameters of the “User Parameters” menu. Repeat the same procedure to enter the password 0000456000 and access the changes of the “System Parameters Setup”.
  • Page 24 Centrifugal separator current System temperature Maximum temperature detected (can be reset with code 19404 in menu drive commands) Maximum detected temperature Power bus voltage Maximum bus voltage recorded Ripple bus voltage cod: ed. 09-2021...
  • Page 25 You can select Italian (0), English (1), French (2), Spanish (3), German (4) and Russian (5). Press Enter and use arrows to select number. Press Enter to confirm change Generated code This code is generated by Cattani S.p.A. Each machine has a unique code. Activation code (if any) cod: ed. 09-2021...
  • Page 26 “SYSTEM PARAMETERS SETUP” MENU To access this menu, enter Access Password 0000456000 (see instructions on p.21). Now you can change some of the settings. To change the parameters in this menu: Scroll the menu with the arrows to highlight the parameters you want to change.
  • Page 27 Blower current limit for medium vacuum level (only Micro-Smart and Micro- Smart Cube) Surgery vacuum level (only Micro-Smart and Micro-Smart Cube) Maximum blower frequency for surgery vacuum level (only for Micro-Smart and Micro-Smart Cube) Blower current limit for surgery vacuum level (only Micro-Smart and Micro- Smart Cube) Switch-off delay (max.
  • Page 28 Options used Enables or disables reading of amalgam sensor. 0- without amalgam separator 1- with amalgam separator Commands to inverter. Reserved for factory settings cod: ed. 09-2021...

  • Page 29: Configuration Of Wi-Fi (Wireless) Communication

    CONFIGURATION INSTRUCTIONS WI-FI (WIRELESS) COMMUNICATION Available in models Notes from serial Number WP5xxxxx Turbo-Smart (new keypad with external display, (produced from October 2015) removable) Micro-Smart from serial Number WM3xxxxx (produced from October 2015) cod: ed. 09-2021...
  • Page 30 Turbo-Smart and Micro-Smart can be controlled through the SmartApp. SETTING UP CONNECTION AND COMMUNICATION ON THE SUCTION UNIT When power is switched on, the display will show this picture. Menu A1 WI-FI OFF Press to Menu “A4” WI-FI SCAN Press and wait for network search Once the search is complete, it will show all available Wi-Fi networks close to the device.
  • Page 31 In Menu M0, use the arrows to scroll to WI-FI Menu M5. To access the Menu, press Now, the Wi-Fi menu shows in S0 the non-changeable IP address (dynamic IP). In the Wi-Fi menu to control the selected network n SSID M5 S1.
  • Page 32 Check that DHCP is set to 1. Check that M5-S5 is set to 2. Now, press the left arrow and then EXC to back to Main menu “A1”, where you can see Wi-Fi ON. When communication with a PC is on, the display will show Wi-Fi DATA.

  • Page 33: Alarm Descriptions

    ALARM DESCRIPTIONS Alarm codes Description Solution Microcontroller memory alarm Contact technician Microcontroller memory alarm Contact technician Short circuit caused by one of the two Check cause of short circuit and remove motors Contact technician (card probably Short circuit before motor control damaged) Failed capacitor charging Contact technician (replace card)

  • Page 34: Important Warnings

    • Updated manuals are available from our website: • The warranty and manufacturer’s liability shall www.cattani.it . We recommend you refer to these cease to apply if the equipment is serviced with especially for the latest safety updates.

  • Page 35: Waste Disposal

    WASTE DISPOSAL INFORMATION FOR PROFESSIONAL USERS • Pursuant to art. 13 law decree no.151 of 25 July, prevent possible negative effects on the environment “Implementation of directive 2011/65 UE ROHS and and on health and favours the reuse and/or recycling 2003/108/CE on restrictions on the use of hazardous of the materials with which the equipment is made.

  • Page 36: Pictures

    WIRING DIAGRAMS BLOK-JET SILENT 1 COMPRESSOR UNIT Fig. A cod: ed. 09-2021...
  • Page 37 MICRO-SMART UNIT cod: ed. 09-2021...
  • Page 38 cod: ed. 09-2021...
  • Page 39 LAYOUT cod: ed. 09-2021...
  • Page 40 TERMINAL STRIP cod: ed. 09-2021...
  • Page 41 TERMINAL STRIP cod: ed. 09-2021...
  • Page 42 WIRING DIAGRAMS BLOK-JET SILENT 2 COMPRESSOR UNIT Fig. B cod: ed. 09-2021...
  • Page 43 TURBO-SMART UNIT cod: ed. 09-2021...
  • Page 44 cod: ed. 09-2021...
  • Page 45 LAYOUT cod: ed. 09-2021...
  • Page 46 TERMINAL STRIP cod: ed. 09-2021...
  • Page 47 TERMINAL STRIP cod: ed. 09-2021...
  • Page 48 We reduce costs: less maintenance and lower energy costs mean that we are always the most economical on a cost-benefit analysis. We reduce environmental impact: we save 50% on raw materials, and allow you to save between 30% and 50% on electrical consumption. Via Natta 6/A 43122 Parma – Italy T +39 0521 607 604 info@cattani.it WWW.CATTANI.IT...

This manual is also suitable for:

Blok-jet silent 1 ac200Blok-jet silent 2 turbo-smart bBlok-jet silent 2 ac300
