  • Page 1 ® Supports Open AT embedded ANSI C applications Fastrack Supreme User Guide WA_DEV_Fastrk_UGD_001 5 june, 2007 UK / Europe Office Australia / Asia Pacific Office USA / Canada Office Tel: +44 (0)845 9000 601 Tel +61 (0)282 442 363 Tel +1-866-849-3441...

  • Page 2: Document History

    Fastrack Supreme User Guide WA_DEV_Fastrk_UGD_001 Document History Revision Date List of revisions 9 February, 07 First Issue 001a 23 February, 2007 Update DC cable GPIO mapping, add AutoShutDown 001b 21 May, 07 Add detail of IES, RTC and serial port autoshutdown...

  • Page 3: Overview

    Fastrack Supreme User Guide WA_DEV_Fastrk_UGD_001 Overview The FASTRACK Supreme 10 and FASTRACK Supreme 20 are discrete, rugged cellular Plug & Play ® Wireless CPU offering state-of-the-art GSM/GPRS (and EGPRS for FASTRACK Supreme 20) connectivity for machine to machine applications. Proven for reliable, stable performance on wireless networks worldwide, Wavecom’s latest generation of FASTRACK Supreme continues to deliver rapid time to market and painless integration.
  • Page 4 WA_DEV_Fastrk_UGD_001 RoHS Directive The FASTRACK Supreme is now compliant with RoHS Directive 2002/95/EC, which sets limits for the use of certain restricted hazardous substances. This directive states that "from 1st July 2006, new electrical and electronic equipment put on the market does not contain lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB), and polybrominated diphenyl ethers (PBDE)".

  • Page 5: Cautions

    Cautions Information furnished herein by WAVECOM is accurate and reliable. However, no responsibility is assumed for its use. Please read carefully the safety recommendations given in Section 9 for an application based on FASTRACK Supreme Plug & Play. Trademarks ®...

  • Page 6: Web Site Support

    Fastrack Supreme User Guide WA_DEV_Fastrk_UGD_001 Web Site Support General information about Wavecom and its range of www.wavecom.com products: Specific support is available for the FASTRACK Supreme ®: Plug & Play Wireless CPU ® Open AT Introduction: www.wavecom.com/OpenAT Developer community for software and hardware: www.wavecom.com/forum...

  • Page 7: Table Of Contents

    Fastrack Supreme User Guide WA_DEV_Fastrk_UGD_001 Contents DOCUMENT HISTORY ............................2 OVERVIEW ................................3 CAUTIONS .................................5 TRADEMARKS ..............................5 COPYRIGHT ..............................5 WEB SITE SUPPORT ............................6 CONTENTS ................................7 LIST OF FIGURES ............................11 LIST OF TABLES.............................12 REFERENCES ............................13 Reference Documents.........................13 ® 1.1.1 Open AT Software Documentation ..................13 1.1.2...
  • Page 8 5.10 Main AT Commands for the Plug & Play .....................44 5.11 Firmware Upgrade Procedure ......................45 TROUBLESHOOTING ..........................46 No Communication with the FASTRACK Supreme through the Serial Link ........46 Receiving "ERROR" Message......................46 Receiving "NO CARRIER" Message ....................47 FUNCTIONAL DESCRIPTION .........................50 Architecture............................50 EU and US Bands..........................51...
  • Page 9 Fastrack Supreme User Guide WA_DEV_Fastrk_UGD_001 7.3.1 General Presentation.........................51 7.3.2 Protections..........................51 RS232 Serial Link ..........................51 7.4.1 General Presentation.........................51 7.4.2 Autobauding Mode ........................52 7.4.3 Pin Description...........................53 7.4.4 Serial Port Auto shut down Feature ..................53 General Purpose Input/Output (GPIO) ....................54 BOOT..............................54 RESET..............................54 7.7.1 General presentation .........................54...
  • Page 10 Fastrack Supreme User Guide WA_DEV_Fastrk_UGD_001 10 RECOMMENDED ACCESSORIES......................76 11 ONLINE SUPPORT ..........................77 confidential © Page: 10 / 77...

  • Page 11: List Of Figures

    Figure 11: SIM card lock feature ........................35 Figure 12: FASTRACK Supreme mounting......................36 Figure 13: Recommended power supply connection on trucks................38 Figure 14: Example of electrical connection which may dramatically damage the FASTRACK Supreme ..39 Figure 15: Functional architecture ........................50 Figure 16: RS232 Serial Link signals .......................52 Figure 17: Reset sequence diagram ........................56...

  • Page 12: List Of Tables

    Table 10: Values of network registration ......................43 Table 11: Main usual AT commands for the Plug & Play .................44 Table 12: Solutions for no connection with FASTRACK Supreme through serial link ........46 Table 13: Solutions for "NO CARRIER" message....................48 Table 14: Interpretation of extended error code ....................49 Table 15: Mechanical characteristics .......................59...

  • Page 13: References

    Programming Guide (Ref. TBD) ® Open AT Customer Release Note (Ref. WM_ASW_OAT_DVD_00062) Remark: The document above is for Open AT3.12 and FASTRACK Supreme will use new release of Open AT4.21. Reference document not yet available and TBC. 1.1.2 AT Software Documentation AT commands interface Guide for X51 (Ref.

  • Page 14: Abbreviations

    Fastrack Supreme User Guide References Note: New versions of software may be available. Wavecom recommends customers to check the web site for the latest documentation. Abbreviations Abbreviation Definition Alternating Current Accumulated Call Meter Adaptive Multi-Rate ® ATtention (prefix for Wireless CPU...
  • Page 15 Fastrack Supreme User Guide References Abbreviation Definition Full Type Approval Global Certification Forum GrouND GPIO General Purpose Input Output GPRS General Packet Radio Service Global System for Mobile communications Half Rate Input International Electrotechnical Commission Internal Expansion Socket IESM Internal Expansion Socket Module...
  • Page 16 Fastrack Supreme User Guide References Abbreviation Definition Radio Frequency Interference Ring Indicator Root Mean Square Request To Send Receive Subscriber Identification Module SubMiniature version A RF connector Short Message Service Signal-to-Noise Ratio Sound Pressure Level SpeaKer SRAM Static RAM Transmission Control Protocol / Internet Protocol...

  • Page 17: Packaging

    Fastrack Supreme User Guide Packaging 2 Packaging Contents The complete package content of the FASTRACK Supreme consists of (see): • one packaging box (A), • one FASTRACK Supreme (B), • two holding bridles (C), • one power supply cable with fuse integrated (D) •...

  • Page 18: Packaging Box

    Fastrack Supreme User Guide Packaging Packaging Box The packaging box is a carton box (see) with the following external dimensions: • width: 54.5 mm, • height: 68 mm, • length: 108 mm. A packaging label is slicked on the packaging box cover and supports the: •...

  • Page 19: Production Labelling

    Fastrack Supreme User Guide Packaging Production Labelling A production label (see Figure 3) located at the FASTRACK Supreme back side gives the following information: • product reference (FASTRACK Supreme 10 or FASTRACK Supreme 20), • part number (WM19183), • CE marking, •...

  • Page 20: General Presentation

    Fastrack Supreme User Guide General Presentation 3 General Presentation Description The FASTRACK Supreme description is given in the Figure 4 below. Sub HD Micro-Fit connector connector Screw for Back Plate connector Back Plate SIM card inside Back Cap SIM connector...

  • Page 21: Figure 5: Fastrack Supreme Holding Bridles

    General Presentation CAUTION: Users are free to remove the back plate for IESM board plug in/unplug without voiding the warrantee of the FASTRACK Supreme. However, the warrantee will be voided if unscrewing any screw of the back cap. In addition, two holding bridles are provided to tighten the FASTRACK Supreme on a support.

  • Page 22: External Connections

    Fastrack Supreme User Guide General Presentation External Connections 3.2.1 Connectors 3.2.1.1 Antenna Connector The antenna connector is a SMA type connector for a 50 Ω RF connection. SMA connector for antenna connection Figure 6: SMA connector for antenna connection 3.2.1.2...

  • Page 23: Sub Hd 15-Pin Connector

    Multiplex with INT1 Warning: Both pin 3 and pin 4 are used by GPIO interface. It is strictly prohibited to connect them to any power supply at the risk of damage to the FASTRACK Supreme. 3.2.1.3 Sub HD 15-pin Connector The Sub D high density 15-pin connector is used for: •...

  • Page 24: Figure 8: Sub Hd 15-Pin Connector

    Fastrack Supreme User Guide General Presentation Figure 8: Sub HD 15-pin connector Table 2: Sub HD 15-pin connector description Pin # Signal I/O type Description Comment (CCITT / EIA) CDCD/CT109 STANDARD RS232 Data Carrier Detect RS232 CTXD/CT103 STANDARD RS232 Transmit serial data...

  • Page 25: Ies Connector

    Fastrack Supreme User Guide General Presentation Pin # Signal I/O type Description Comment (CCITT / EIA) CSPK2P Analog Speaker positive line CCTS/CT106 STANDARD RS232 Clear To Send RS232 CRTS/CT105 STANDARD RS232 Request To Send RS232 CRI/CT125 STANDARD RS232 Ring Indicator...

  • Page 26: Figure 9: Ies Connector For Feature Expansion

    Fastrack Supreme User Guide General Presentation For sales and support, please contact Wavecom sales/FAE or your distributor. Pin 50 Pin 2 Pin 49 Pin 1 Figure 9: IES connector for feature expansion confidential © Page: 26 / 77...

  • Page 27: Table 3: Ies Connector Description

    Fastrack Supreme User Guide General Presentation Table 3: IES Connector Description Signal Name Reset Dealing with Voltage I/O* Description Number type State unused pins Nominal Ground Ground GPIO4 COL0 GSM-1V8 Pull-up Keypad column 0 GPIO5 COL1 GSM-1V8 Pull-up Keypad column 1...
  • Page 28 Fastrack Supreme User Guide General Presentation Signal Name Reset Dealing with Voltage I/O* Description Number type State unused pins Nominal firmware update GPIO8 COL4 GSM-1V8 Pull-up Keypad column 4 GPIO26 Open Drain I²C Clock GPIO19 GSM-2V8 GPIO27 Open Drain I²C Data...

  • Page 29: Power Supply Cable

    Fastrack Supreme User Guide General Presentation 3.2.2 Power supply cable Figure 10: Power supply cable confidential © Page: 29 / 77...
  • Page 30 Fastrack Supreme User Guide General Presentation Component Characteristics Micro-Fit connector Part number: MOLEX 43025-0400 4-pin Cable length: ∼1.5 m Cable Wire Core: tinned copper 24 x 0.2 mm Section: 0.75 mm confidential © Page: 30 / 77...

  • Page 31: Features And Services

    Fastrack Supreme User Guide Features and Services 4 Features and Services Basic Features and Services Basic features of the FASTRACK Supreme and available services are summarized in the table below. Table 4: Basic features of the FASTRACK Supreme Features GSM850 / GSM900 DCS1800 / PCS1900 ®...
  • Page 32 Fastrack Supreme User Guide Features and Services Features GSM850 / GSM900 DCS1800 / PCS1900 RS232 (V.24/V.28) Serial interface supporting: Interfaces Baud rate (bits/s): 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 230400, 460800 and 921600. Autobauding (bits/s): from 1200 to 921600.
  • Page 33 Fastrack Supreme User Guide Features and Services Features GSM850 / GSM900 DCS1800 / PCS1900 Call forwarding. supplement Call barring. services Multiparty. Call waiting and call hold. Calling line identity. Advice of charge. USSD DC power supply Other Real Time Clock with calendar Complete shielding For other detailed technical characteristics, refer to Section 8.

  • Page 34: Additional New Features

    Real Time Clock (RTC) for Saving Date and Time The FASTRACK Supreme has now implemented the Real Time Clock for saving date and time when the Plug & Play is unplugged from the DC power supply through the DC power cable.

  • Page 35: Sim Card Lock Feature

    4.2.5 SIM Card Lock Feature The FASTRACK Supreme has now implemented a SIM connector having a carrier with lock. This helps ensuring the user to have proper SIM card insertion and locked before proper use of GSM network. SIM card is inserted but not locked. GSM network is SIM card is inserted and being locked properly.

  • Page 36: Using The Fastrack Supreme Plug & Play

    Getting Started 5.1.1 Mount the FASTRACK Supreme To mount the FASTRACK Supreme on its support, bind it using the holding bridles as shown in the Figure 12 below. Figure 12: FASTRACK Supreme mounting For the drill template, refer to Figure 18.

  • Page 37: Check The Communication With The Fastrack Supreme

    5.1.4 Reset the FASTRACK Supreme To reset the FASTRACK Supreme, a hardware reset signal is available on pin 14 of the Sub HD 15-pin connector (RESET). The FASTRACK Supreme reset is carried out when this pin is low for at least 200 μs.

  • Page 38: Specific Recommendations When Using The Fastrack Supreme On Trucks

    It is highly not recommended to connect directly the power supply on the battery rather than on the circuit breaker. The FASTRACK Supreme may be damaged when starting the truck if the circuit breaker is switched OFF (in this case, the truck ground and the battery ground will be connected through the FASTRACK Supreme as shown in the figure below).

  • Page 39: Fastrack Supreme Operational Status

    FASTRACK Supreme Operational Status The FASTRACK Supreme operational status is given by the red LED status located next to the SIM connector on the FASTRACK Supreme panel. The Table 5 below gives the meaning of the various statuses available.

  • Page 40: Echo Function Disabled

    FASTRACK Supreme echo function ( command). ATE1 In a Machine To Machine communication with the FASTRACK Supreme, it is recommended to disable the FASTRACK Supreme echo function ( command) in order to avoid useless CPU processing. ATE0 For further information on commands, refer to "AT Commands Interface Guide"...

  • Page 41: Verify The Received Signal Strength

    (*)For further information on the other possible responses and their meaning, refer to "AT Commands Interface Guide" [6]. Switch between EU/US Band(s) To switch between EU/US band(s) for the FASTRACK Supreme, use a communication software such as a HyperTerminal, then enter command.

  • Page 42: Check The Band(S) Selection

    Plug & Play initialization. Refer to "AT Commands Interface Guide" [6] for further information on AT commands. Check the Band(s) Selection To check the band selection for the FASTRACK Supreme, use a communication software such as a HyperTerminal, then enter command.

  • Page 43: Verify The Fastrack Supreme Network Registration

    Using the FASTRACK Supreme Plug & Play Verify the FASTRACK Supreme Network Registration 1. Make sure a valid SIM card has been previously inserted and locked in the FASTRACK Supreme SIM card holder. 2. Using a communication software such as a HyperTerminal, enter the following AT commands: to enter PIN code xxxx.

  • Page 44: 5.10 Main At Commands For The Plug & Play

    Fastrack Supreme User Guide Using the FASTRACK Supreme Plug & Play If the FASTRACK Supreme is not registered, perform the following procedure: • Check the connection between the FASTRACK Supreme and the antenna. • Verify the signal strength to determine the received signal strength (refer to Section 5.5).

  • Page 45: 5.11 Firmware Upgrade Procedure

    (1*) The command "AT+CMEE=1" switch to a mode enabling more complete error diagnostics. 5.11 Firmware Upgrade Procedure The firmware upgrade procedure is used to update the firmware embedded into the FASTRACK Supreme. That procedure consists in downloading the firmware into internal memories through the RS232 serial link available on the SUB-D 15-pin connector.

  • Page 46: Troubleshooting

    No Communication with the FASTRACK Supreme through the Serial Link If the FASTRACK Supreme does not answer to AT commands through the serial link, refer to the table below for possible causes and solutions. Table 12: Solutions for no connection with FASTRACK Supreme through serial link...

  • Page 47: Receiving "No Carrier" Message

    Enter again the AT command which previously caused the reception of "ERROR" message in order to get the Mobile Equipment error code. When the verbose error report method is enabled, the response of the FASTRACK Supreme in case of error is as follows: •...

  • Page 48: Table 13: Solutions For "No Carrier" Message

    If no success, try bearer selection type by AT command: AT+CBST=0,0,3 If the FASTRACK Supreme returns a "NO CARRIER" message, you may have the extended error code by using AT command . Refer to the table below for interpretation of extended error code.

  • Page 49: Table 14: Interpretation Of Extended Error Code

    Fastrack Supreme User Guide Troubleshooting Table 14: Interpretation of extended error code Error Code Diagnostic Hint Unallocated phone number Normal call clearing User busy No user responding User alerting, no answer Call rejected Number changed Normal, unspecified Requested facility not subscribed Check your subscription (data subscription available?).

  • Page 50: Functional Description

    Fastrack Supreme User Guide Functional Description 7 Functional Description Architecture FASTRACK Supreme Plug & Play RS232 Interface BOOT Internal Quik RESET ® Wireless CPU Q2687 Microphone Microphone Audio Interface Operating Speaker Speaker Status SUB HD 15 pins GPIO-21 GPIO-25 V+BATT...

  • Page 51: Eu And Us Bands

    See paragraph 8.2.1 for more information. 7.3.2 Protections The FASTRACK Supreme is protected by a 800 mA / 250 V fuse directly bonded on the power supply cable. The FASTRACK Supreme is also protected against voltage over +32 V. Filtering guarantees: •...

  • Page 52: Autobauding Mode

    7.4.2 Autobauding Mode The autobauding mode allows the FASTRACK Supreme to detect the baud rate used by the DTE connected to the RS232 serial link. Autobauding mode is controlled by AT commands. See "AT Commands Interface Guide" [6] for details on this function.

  • Page 53: Pin Description

    7.4.4 Serial Port Auto shut down Feature The UART1 can be shut down when there is no activity between the DTE and the FASTRACK Supreme Plug & Play. This can help for improving power consumption performance. Serial Port Auto shut down feature is easily controlled by AT command...

  • Page 54: General Purpose Input/Output (Gpio)

    Fastrack Supreme User Guide Functional Description General Purpose Input/Output (GPIO) The FASTRACK Supreme provides two General Purpose Input / Output lines available for external use: GPIO21 and GPIO25. These GPIOs may be controlled by AT commands: • for a write access to the GPIO value, when the GPIO is used as an output, AT+WIOW •...

  • Page 55: Reset Sequence

    The RESET process is activated either by the external RESET signal or by an internal signal (coming from a RESET generator). This automatic reset is activated at Power-up. The FASTRACK Supreme remains in RESET mode as long as the RESET signal is held low. Caution: This signal should be used only for "emergency"...

  • Page 56: Audio

    Fastrack Supreme User Guide Functional Description ~ RES ET W irele s s CP U A T a n s w e rs “ O K” ST A T E O F T H E W irele s s RES ET m o d e...

  • Page 57: Speaker Outputs

    Fastrack Supreme User Guide Functional Description 7.8.2 Speaker Outputs This connection is differential to reject common mode noise and TDMA noise. Speaker outputs are connected to internal push-pull amplifiers and may be loaded down between 32 to 150 Ohms and up to 1 nF (see details in table Speaker gain vs Max output voltage, in "AT Commands Interface Guide"...

  • Page 58: Real Time Clock (Rtc)

    DC power source. 7.10 FLASH LED The FASTRACK Supreme has a red LED indicator to show the status of the GSM network. For detail description of the various status, please refer to Section 5.3. However, during operation mode of Slow Standby, there will be no network registration and so the red LED indicator will always be ON.

  • Page 59: Technical Characteristics

    < 120 grams (FASTRACK Supreme + bridles + power supply cable) 101.5 cm Volume Aluminum profiled Housing The next page gives the dimensioning diagram of the FASTRACK Supreme including the clearance areas to take into account for the FASTRACK Supreme installation. confidential © Page: 59 / 77...

  • Page 60: Figure 18: Dimensioning Diagram

    Fastrack Supreme User Guide Technical Characteristics Figure 18: Dimensioning diagram confidential © Page: 60 / 77...

  • Page 61: Electrical Characteristics

    Maximum current 2.1 A Peak at 5.5 V. (TBC) Note : The FASTRACK Supreme is permanently powered once the power supply is connected. The following table describes the consequences of over-voltage and under-voltage with the FASTRACK Supreme. Warning: All the input voltages specification described in this Section are at the FASTRACK Supreme input.

  • Page 62: Power Consumption

    Fastrack Supreme User Guide Technical Characteristics 8.2.2 Power Consumption The following table provides information on power consumption of the FASTRACK Supreme, assuming an operating temperature of +25 °C and using a 3 V SIM card. Table 18: Power consumption (1*) Power Consumption in...
  • Page 63 Fastrack Supreme User Guide Technical Characteristics Power Consumption in E-GSM 900 DCS 1800 E-GSM 900/DCS 1800 MHz - GPRS class 10 @ 5.5V GSM900: During 2TX bursts @ PCL8 (Gamma 6) @ 13.2V DCS1800 : During 2TX bursts @ PCL2 (Gamma 5)
  • Page 64 (1*):The power consumption might vary by 5 % over the whole operating temperature range (-20 °C to +55 °C). (2*): In this Mode, the RF function is active and the FASTRACK Supreme synchronized with the network, but there is no communication.

  • Page 65: Audio Interface

    Fastrack Supreme User Guide Technical Characteristics 8.2.3 Audio Interface The audio interface is available through the Sub HD 15-pin connector. Table 19: Audio parameters caracteristics Audio parameters Unit Comments Microphone input current @2 V/2 k Ω Absolute microphone input voltage...

  • Page 66: General Purpose Input/Output

    Fastrack Supreme User Guide Technical Characteristics Table 22: Recommended characteristics for the speaker: Feature Value Type 10 mW, electro-magnetic Z = 32 to 50 Ω Impedance Sensitivity 110 dB SPL min. (0 dB = 20 µPa) Frequency response compatible with the GSM specifications 8.2.4...

  • Page 67: Rf Characteristics

    Fastrack Supreme User Guide Technical Characteristics Table 26: Operating conditions Parameter Minimum Maximum Unit ~RESET time (Rt) µs ~RESET time (Rt) at power up only Cancellation time (Ct) 0.57 0.57 1.33 Hysterisis Voltage 1 This reset time is the minimum to be carried out on the ~RESET signal when the power supply is already stabilized.

  • Page 68: Rf Performances

    Fastrack Supreme User Guide Technical Characteristics 8.2.7.2 RF Performances RF performances are compliant with the ETSI recommendation GSM 05.05. The RF performances for receiver and transmitter are given in the table below. Table 28: Receiver and transmitter RF performances Receiver E-GSM900/GSM850 Reference Sensitivity -104 dBm Static &...

  • Page 69: External Antenna

    The FASTRACK Supreme remains fully functional, across the specified temperature range. Some GSM parameters may occasionally deviate from the ETSI/PTCRB specified requirements and this deviation does not affect the ability of the FASTRACK Supreme to connect to the cellular network and function fully, as it does within the Class A range.

  • Page 70: Table 31: Environmental Standard Constraints

    Fastrack Supreme User Guide Technical Characteristics The detailed climatic and mechanics standard environmental constraints applicable to the FASTRACK Supreme are listed in the table below: Table 31: Environmental standard constraints Environmental Tests Environmental Classes (IEC TR 60721-4) (IEC 60721-3) Operation...
  • Page 71 Warning: The specification in the above table applies to the FASTRACK Supreme product only. Customers are advised to verify that the environmental specification of the SIM Card used is compliant with the FASTRACK Supreme environmental specifications.

  • Page 72: Conformity

    Protections 8.5.1 Power Supply The FASTRACK Supreme is protected by a 800 mA / 250 V fuse directly bonded on the power supply cable. The model of fuse used is: FSD 800 mA / 250 V FAST-ACTING . confidential ©...

  • Page 73: Overvoltage

    When input voltages exceed +32 V, the supply voltage is disconnected in order to protect the internal electronic components from an overvoltage. 8.5.3 Electrostatic Discharge The FASTRACK Supreme withstands ESD according to IEC 1000-4-2 requirements for all accessible parts of the FASTRACK Supreme except the RF part: • 8 kV of air discharge, •...

  • Page 74: Safety Recommendations

    Observe any warning signs and manufacturers’ recommendations. The FASTRACK Supreme Plug & Play is designed for and intended to be used in " fixed " and " mobile " applications: "Fixed" means that the device is physically secured at one location and is not able to be easily moved to another location.

  • Page 75: Care And Maintenance

    Do not expose the FASTRACK Supreme Plug & Play to any extreme environment where the temperature or humidity is high. Do not use or store the FASTRACK Supreme Plug & Play in dusty or dirty areas. Its moving parts (SIM holder for example) can be damaged.

  • Page 76: Table 32: List Of Recommended Accessories

    Fastrack Supreme User Guide Recommended Accessories 10 Recommended Accessories Accessories recommended by Wavecom for the FASTRACK Supreme are given in the table below. Table 32: List of recommended accessories Designation Part number Supplier 1140.26 ALLGON Quad-band antenna MA112VX00 MAT Equipement...
  • Page 77 Fastrack Supreme User Guide Online Support 11 Online Support Wavecom provides an extensive range on online support which includes the following areas of Wavecom’s wireless expertise: • the latest version of this document • new versions of our Operating System user guides ®...
