- Page 1 IntelliCold® Pharmacy Refrigerator Operating Instructions - RLDF/G 19 www.labcold.com...
- Page 2 WEEE: Disposal at end of life. This equipment, when being disposed of in an EU Member State, is subject to the Waste Electrical and Electronic Equipment Regulations (WEEE) and must be recycled and disposed of in accordance with EU directive 2002/96/EC as applied in local laws of that State at the time of disposal. This refrigerator contains flammable insulation gases and must be disposed of in the appropriate way by competent persons.
- Page 3 Do not store explosive substances such as aerosol cans with fl ammable propellant in this appliance. Labcold RLDF/G refrigerators are designed for the storing of pharmaceuticals, medicines and laboratory products and are for professional use only by suitably trained, competent persons.
- Page 4 Need calibration? Labcold are a UKAS calibration laboratory #8898 8898 We can calibrate your refrigerator AND your independent thermometer We don’t just use UKAS traceable equipment, we use UKAS methodology and training for assured technical competence...
-
Page 5: Table Of Contents
Operating instructions for your IntelliCold® Pharmacy Refrigerator Contents Before Use .......................1 A Closer Look ......................2 Alarm battery back up.............2 Remote connections............2 IntelliCold® Controller..................3 Plug In and Switch On..................4 Muting the alarm..............6 Accessing the Menu....................6 Viewing the set point............7 Viewing software version..........7 Centigrade /Fahrenheit...........8 Alarm Time Out..............8 Internal light...............9... -
Page 6: Before Use
Before Use Labcold IntelliCold® Pharmacy Refrigerator. Your fridge has been Thank you for purchasing a purposely designed and precision built for the safe storage of vaccines, samples, reagents and other temperature sensitive pharmaceuticals. Although great care has been taken in the manufacture of your refrigerator, damage can occur in transit. -
Page 7: A Closer Look
Remote Alarm The remote alarm connection is located at the back of the fridge. Connections Labcold If you have a repeat alarm kit this is where the wires need to be connected. Please see the separate instructions for more information. -
Page 8: Intellicold® Controller
IntelliCold® Controller The IntelliCold® controller fitted to the front of your refrigerator has been designed by Labcold for the safe storage of vaccines, medicines, samples and reagents. It is fitted with an exclusive touch controller that displays the temperature detected by two temperature probes, one located in the back of the fridge and one you can position yourself, for example inside a packet to monitor a load temperature. -
Page 9: Plug In And Switch On
Plug In and Switch On Labcold Before plugging in your refrigerator for the first time make sure the power cable is free from damage and check that your voltage corresponds to that on the serial plate. It is recommended that you do not use extension cords or multiple socket adapters. Make sure the power cable is not bent, pinched or compressed and that it can be easily accessed. - Page 10 After setting the month you next need to set the day. The controller will now flash followed by 2 digits, for example d98. Adjust the digits using the arrow icons/buttons as above, so if it is June adjust the digits to 21. When adjusted, touch the tick icon/button as before. After setting the day you next need to set the hour.
-
Page 11: Muting The Alarm
Muting the Alarm to1H To mute the alarm, wait until the controller is showing the high alarm screen and touch to1H the mute icon/button. The high alarm screen will then flash to confirm you have muted to2H it and the alarm will stop sounding. Repeat for alarm (if enabled). -
Page 12: Viewing The Set Point
When you access the menu the first menu option is to view the set point, see above. The set point is one of the parameters that you can not change but you can view it. Your Labcold IntelliCold® pharmacy refrigerator leaves the factory with a set point of 5oC as advised... -
Page 13: Centigrade/Fahrenheit
Centigrade/Fahrenheit Should you wish to change the temperature scale from centigrade to Fahrenheit enter the menu as before and use the arrow icons/buttons until you get to a screen displaying Touch the tick icon/button to enter this function as before. °... -
Page 14: Internal Light
The battery alarm is enabled by default. If you put 4AA batteries in your refrigerator the alarm will sound if the batteries are faulty, removed or there is a mains power failure. Labcold strongly recommends that you fit batteries to your IntelliCold® pharmacy refrigerator for... -
Page 15: Second Temperature Probe To2
Turning the Battery Alarm Off If you do not fit batteries you will need to turn this alarm to OFF. To do so, hold both the arrow icons/buttons to enter the menu. Scroll through until you get to the screen that shows and touch the tick icon/button. -
Page 16: Viewing Alarm Limits
Green Book, Chapter 3 page 27 and you cannot change them. Should you need them to be 01256 705 580 or email service@labcold.com. altered please contact our service team on To view the parameter, access the menu by holding the two arrow icons/buttons and scroll through the options until you come to screen LПt. -
Page 17: Viewing Min/Max Temperatures
Min/Max Temperatures To view your high/low temperature make the icons/buttons are visible by putting your hand on the controller as described in page 6. Touch the high/low icon and the controller will display the minimum and maximum temperatures recorded by probe and repeat this process for probe enabled). -
Page 18: Alarm Guide
Alarm Guide Your IntelliCold® Pharmacy refrigerator is fitted with audio and visual alarms to help keep the contents safe. All can be muted but unless the alarm condition is resolved, the alarm will return after the time out interval (see page 8). The controller will show a code to explain why the fridge is alarming. -
Page 19: Light Icon/Button
° 1 ° C Door Lock Labcold Your pharmacy and vaccine fridge is fitted as standard with a door lock with 2 keys unless the digital lock has been specified. To lock, push the key in gently and twist 90o to the left, to unlock twist 90o to the right. -
Page 20: Digital Door Lock
There is also a master override key (optional extra) that enables you to open the refrigerator in the normal way should you wish to or in an emergency. Labcold digital combination lock is backed by a UK one year parts and labour warranty. - Page 21 Getting Started Follow the instructions on page 4 -11 to set up your refrigerator. We especially recommend that you install 4 AA batteries (supplied) in to the battery compartment located on the right hand side of the fridge near the base ( see page 2) because this will allow you to be able to open the digital lock if there is a failure of mains power.
- Page 22 The master key is unique to digital combination locks. Should you wish to use the lock as a digital lock again but have no record of the user code please contact our service team on 01256 705 580 or service@labcold.com.
-
Page 23: Micro Sd Card
The card is supplied with an adapter for convenience so you can use a regular SD card reader slot if required. You cannot use any Micro SD card with your Labcold IntelliCold® pharmacy refrigerator. Only the Micro SD cards from Labcold are encoded to work with the controllers. - Page 24 01256 705 580 service@ initialization has failed, please contact our service team on labcold.com, and if you see it means the wrong Micro SD card for that refrigerator is being used. Try again with the correct Micro SD card. Viewing the data When you insert you insert the SD card in to your computer you will see csv folders named in yymm format.
-
Page 25: Pharmacy Drawers
Pharmacy Drawers PHARMDRAWER2019 are optional extras for IntelliCold® refrigerators models RLDF/G1019 and 1519 and can be used with shelves depending on your requirement. We recommend that you clean them with warm soapy water and dry them thoroughly before use. 01256 705 570 Should you require any more drawers please contact our sales department on Fitting Instructions To install your drawer, position 4 of the shelf... - Page 26 Two plastic white clips are supplied with each draw. These must be pushed in to the holes located on either side at the back of the drawer runner frame. Use this way up with the pointed end section at the Flat back bottom of the clip...
- Page 27 Place the drawer frame on top of the shelf supports. Make sure that the shelf supports fully engage with the 4 holes on the reverse of the drawer frame. Holes on the reverse of the drawer frame designed to engage with the shelf supports fi tted to the refrigerator racking Lower the holes on the drawer frame on to the 4 shelf supports...
- Page 28 Finally, push the white clips at the rear of the drawer frame in to the shelf racking as far as they will go. The white clips will not engage fully, but they will engage enough to stop the drawer from tipping when fully extended Drawer frame Back of refrigerator...
-
Page 29: Caring For Your Fridge
Caring for your Fridge Labcold As with all refrigerators, your refrigerator, although designed to provide you with many years of fault free service, will perform better if it is regularly maintained and calibrated as per the Green Book, chapter 3 page 28. In addition to the above, attention needs to be paid to the loading of the fridge to ensure maximum temperature and energy efficiency. -
Page 30: Troubleshooting
My fridge is making a gurgling noise Labcold refrigerators work by evaporating a gas with low GWP properties. This is what causes the back of the refrigerator to get cold,. As part of this process the gas has to turn back in to liquid. -
Page 31: Useful Information
To register your warranty, please complete the enclosed warranty form or visit our web site at www.labcold.com, click on the ‘Warranty Registration’ tab and follow the instructions. Full warranty terms and conditions can also be viewed and downloaded from the Labcold website. - Page 32 www.labcold.com...
