User Manual
HyperX Cloud Alpha S™ Headset
Find the language and latest documentation for your headset here.
HyperX Cloud Alpha S Headset Installation Guide
. . . . . . . . . . . . For instructions in English
. . . . . . . . . . . . . . . . . . Para instrucciones en Español
. . . . . . . . . Für Anleitungen in Deutsch
. . . . . . . . . . . . . . . . . . Pour des instructions en Français
. . . . . . . . . . . . . . . . . . Per le istruzioni in Italiano
. . . . . . . . . . . . Por as instruções em Português
. . . . . . . . . . . . . . . . . . Instrukcje w jezyku Polskim
. . . . . . . . . . . . . . . . . . Для инструкции на Pусском
. . . . . . . . . . . . . . . . . . Turkce talimatlar icin
. . . . . . . . . . . . . . . . . .日本語マニュアル用
. . . . . . . . . . . . . . . . . .한국어 안내
. . . . . . . . . . . . . . . . . . คำ � แนะนำ � ภ�ษ�ไทย
. . . . . . . . . . . . . . . . . . Để xem hướng dẫn bằng tiếng Việt
Simplified Chinese . . . . .简体中文说明书
Traditional Chinese . . . .繁體中文說明
Advertisement
Table of Contents
Related Manuals for HyperX Cloud Alpha S
Summary of Contents for HyperX Cloud Alpha S
- Page 1 Find the language and latest documentation for your headset here. HyperX Cloud Alpha S Headset Installation Guide . . . . . . . . . . . . For instructions in English .
- Page 2 HyperX Cloud Alpha S Part Numbers HX-HSCAS-BL/WW Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™ Page 1 of 15...
-
Page 3: Table Of Contents
Game/Chat balance buttons ..........................7 Using with PC ..........................8 Connecting Headset to PC ............................. 8 Windows Setup ............................... 9 Discord Setup ................................ 13 Using with Console & Mobile ....................14 Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™ Page 2 of 15... -
Page 4: Overview
E. Mic mute / mic monitoring button F. 7.1 surround sound button G. Headphone volume buttons H. Game Balance button Chat Balance button J. Cloth ear cushions K. Travel bag Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™ Page 3 of 15... -
Page 5: Specifications
Sensitivity: -38dBV (0dB=1V/Pa at 1kHz) USB Audio Control Mixer Controls: Headset volume buttons, Game/Chat balance buttons, 7.1 surround sound button, mic mute / mic monitoring button Weight: 57g Cable length: 2m Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™ Page 4 of 15... -
Page 6: Usage
Move the bass adjustment sliders up or down to change the amount of bass in the headset. Move the sliders up for more bass. Move the sliders down for less bass. Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™ Page 5 of 15... -
Page 7: Usb Audio Control Mixer
Hold the button for 3 seconds to toggle mic monitoring on or off. Headset volume buttons Volume + Volume - Press the volume +/- buttons to adjust headset master volume up or down. Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™ Page 6 of 15... -
Page 8: 7.1 Surround Sound Button
Game balance Chat balance Press the game/chat balance buttons to adjust mix between game audio and chat audio. The game/chat balance functionality operates independently from the overall headset audio volume. Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™ Page 7 of 15... -
Page 9: Using With Pc
Connecting Headset to PC 1. Connect the headset into the USB audio control mixer with the 3.5mm 4-pole cable. 2. Connect the USB audio control mixer into the PC’s USB port. Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™ Page 8 of 15... -
Page 10: Windows Setup
Windows Setup 1. Right click speaker icon in system tray, then select Open Sound settings. In Sound settings window, select Sound Control Panel. Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™ Page 9 of 15... - Page 11 3. Under the Playback tab, select Speakers (HyperX Cloud Alpha S Game). Then click on the arrow next to Set Default and select Default Device. 4. Select Headset Earphone (HyperX Cloud Alpha S Chat). Then click on the arrow next to the Set Default button and select Default Communication Device.
- Page 12 5. Check that Speakers (HyperX Cloud Alpha S Game) is set as Default Device and Headset Earphone (HyperX Cloud Alpha S Chat) is set as Default Communications Device. 6. Under the Recording tab, select Microphone (HyperX Cloud Alpha S Chat). Then click on the Set Default button.
- Page 13 7. Check that Microphone (HyperX Cloud Alpha S Chat) is set as Default Device. Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™ Page 12 of 15...
-
Page 14: Discord Setup
Discord Setup 1. Under Discord settings, select Voice & Video. 2. Under Voice Settings, select Input Device to Microphone (HyperX Cloud Alpha S Chat). 3. Select Output Device to Headset Earphone (HyperX Cloud Alpha S Chat). Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™... -
Page 15: Using With Console & Mobile
Using with Console & Mobile Xbox One Nintendo Switch Mobile Connect the headset to the device’s 3.5mm port with the 3.5mm (4-pole) cable. Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™ Page 14 of 15... - Page 16 Questions or Setup Issues? Contact the HyperX support team at: hyperxgaming.com/support/ Document No. 480HX-HSCAS.A01 HyperX Cloud Alpha S™ Page 15 of 15...
