WARNINGS:
• FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN PERSONAL INJURY! PLEASE READ THESE
INSTRUCTIONS IN ITS ENTIRETY BEFORE ATTEMPTING TO COMPLETE THIS PROCESS.
• IF WEATHER CONDITIONS PRESENT RISK OF HIGH WINDS, RAIN, OR SNOW, ENSURE THAT THE AWNING
REMAINS CLOSED.
• BE SURE THAT NO OBJECT OR PERSONS CAN COME ON CONTACT WITH THE AWNING AS IT CLOSES OR OPENS,
WHILE UNATTENDED.

TABLE OF CONTENTS

I.
INSTALLATION ...............................................................................................................................................................2
II.
SET UP ............................................................................................................................................................................5
Account Creation
•
Connect Via WI-FI
•
•
Connect Via Ethernet
III.
COMMISSIONING ..........................................................................................................................................................8
•
•
•
•
•
IV.
SETTINGS ......................................................................................................................................................................14
•
•
•
•
•
APPENDIX ....................................................................................................................................................................................17
E. Change WI-FI Network
F. Delete an RTS Product
For Technical Support visit us at http://ownerscorner.sunsetter.com or
Call Toll Free 800-670-7071 • Fax 877-224-4944
Somfy® TaHoma®
Installation and Operation Instructions
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Somfy TaHoma and is the answer not in the manual?

Questions and answers

Related Manuals for SunSetter Somfy TaHoma

Summary of Contents for SunSetter Somfy TaHoma

  • Page 1: Table Of Contents

    For Technical Support visit us at http://ownerscorner.sunsetter.com or Call Toll Free 800-670-7071 • Fax 877-224-4944 Somfy® TaHoma® Installation and Operation Instructions WARNINGS: • FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN PERSONAL INJURY! PLEASE READ THESE INSTRUCTIONS IN ITS ENTIRETY BEFORE ATTEMPTING TO COMPLETE THIS PROCESS.

  • Page 2: Installation

    Select indoor location best suited for TaHoma® device. Figure 1 For best performance, TaHoma® must be placed within 25-35' of the SunSetter product. TaHoma® Connect micro USB end of power cord to Tahoma®. (See Figure 1) Plug power cord into standard AC wall outlet.

  • Page 3: Set Up

    II. SET UP Set Up TaHoma® North America App 3. Select “create an account”. Figure 4 4. Select country and preferred language. 5. Select "start activation". Figure 5 6. Select "Activate TaHoma®". 7. Enter the TaHoma® PIN code and select "OK". Figure 6 The PIN code is 3 series of digits on the TaHoma®...
  • Page 4 Figure 7 8. Enter and confirm the account email address and password, select "Continue". 9. Enter all fields, select "Save and Continue". 10. Review the information in the summary page and read all documents: Check all boxes to accept the “Terms and Conditions”, select “Confirm”.
  • Page 5 Connect Tahoma to Active Internet Connection Via Wi-Fi Figure 10 12. Connect the mobile device or tablet to the same Wi-Fi network that TaHoma® will be connecting to. 13. Login to the Somfy® TaHoma® North America App. 14. Select location. select "Click Here to Update Timezone”.
  • Page 6 22. Select “Join”. • Allow TaHoma® to connect to devices on your local network. • LED indicator will change from RED to GREEN. 23. After the “Congratulations, your Wi-Fi is now configured…” note appears, select “Finish”. Figure 13 Wi-Fi is now connected. To change the Wi-Fi network, refer to “Change Wi-Fi Network”...
  • Page 7 Connect Tahoma® to Active Internet Connection Via Ethernet (Adapter Sold Separately) NOTE: An internet connection is required. TaHoma® does not support local control to operate any RTS products without an internet connection. Follow the steps below to connect TaHoma® using the TaHoma® Ethernet Adaptor: An Ethernet connection method provides more reliability and stability when compared to a Wi-Fi connection.

  • Page 8: Commissioning

    32. Select the RTS product from the list: • Select the proper device to be programmed. SunSetter products will be “Awning” or “Exterior Shade” on the “Shades” tab; or “Dimmable Light” on the “Other” tab. 33. Enter a name for your device, then select “Next”.
  • Page 9 34. Find the remote that controls your SunSetter product. Confirm that your remote is on the channel that operates your • SunSetter product. Awnings and EasyShades are preset to operate on Channel 1. LED Lights are set to operate on Channel 2.

  • Page 10: Add A Scene

    Add a Scene A TaHoma® system can support a maximum of 40 scenes with schedules. Creating a scene will provide a specific setup for your products at your desired time of day. For example, you may want to create a scene called “Wake Up”, which tells your Awning(s) and/or EasyShade(s) to extend at 8:00 am to begin keeping the hot summer sun at bay.

  • Page 11: Add A Schedule To A Scene

    Add a Schedule to a Scene A TaHoma® system can support a maximum of 40 scenes with schedules. NOTE: Scheduled scenes will continue to operate at the scheduled time even after internet connection has been lost. Figure 27 48. Select the “Scene” icon from the bottom menu. 49.

  • Page 12: Create A Room

    Create a Room Create rooms to organize RTS products. A maximum of 50 rooms can be created. Figure 29 54. Select the “Home” icon from the bottom menu. 55. Select the “Gear” icon in the top right corner. 56. Select “Create room”. 57.

  • Page 13: Add Additional Tahoma® Devices

    Add Additional TaHoma® Devices Add additional TaHoma® Devices for whole home control or single room control. Figure 31 60. From the TaHoma® app home page, select the Menu icon in the bottom right corner. 61. Select “My Setup”. 62. Select “Add Gateway”. Figure 32 63.

  • Page 14: Settings

    IV. SETTINGS My Product: Used to add, delete, and edit RTS products Figure 33 From the TaHoma® app home page, select the Menu icon in the bottom right corner. Select “My Products”. • Add RTS product (+ icon) • “Favorite” an RTS product (star icon) •...

  • Page 15: Activity History

    Activity History: Used to view all commands sent from Android or IOS devices and any schedules that have launched. Figure 35 From the TaHoma® app home page, select the Menu icon in the bottom right corner. Select “Activity History” • History of all commands •...

  • Page 16: Third-Party Integration

    Optional: Third-Party Integration TaHoma® is compatible with various third-party systems. Figure 37 From the TaHoma® app home page, select the Menu icon in the bottom right corner. Select “Third-Party Integration” • Amazon Alexa – Control devices with Alexa • Google Home – Control devices with Google Assistant IFTTT –...

  • Page 17: Appendix

    APPENDIX [Appendix A] Available Commands & Actions TaHoma® RTS Product Open/Raise/Extend Moves EasyShade to up position. Moves Awning to open/extended position. Close/Lower/Retract Moves EasyShade to down position. Moves Awning to closed/retracted position. On/Off Turns LED Lights on or off. Dims or brightens LED Lights. [Appendix B] Share TaHoma®...
  • Page 18 Thank you for Choosing SunSetter July 22, 2022 SunSetter Products, 184 Charles Street, Malden, MA 02148 INS206-Somfy-TaHoma...
