iLive IHB23 User Manual

Wireless Speaker System with Subwoofer
User's Guide for Model IHB23 v2032-02
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with
the manufacturer's instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
• Do not defeat the safety purpose of the polarized or grounding -
type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your
safety. When the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over. Unplug this apparatus during lightning
storms or when unused for long periods of time.
• Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.
FCC WARNINGS
Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Features
• Bluetooth Wireless: range 60 ft.
• 2.1 channel stereo sound
• Built-in amplifier
• 3 speakers: left/right/subwoofer
• LED light effects
• RCA stereo audio inputs
• Analog volume control
• Bass/treble controls
• AC power: built-in AC power cable
Includes
• 3.5mm audio cable
Pairing
Indicator
Source
Press to switch between
Bluetooth and Line In modes.
Press and hold for 5 seconds to
turn voice prompts ON/OFF.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
ADDITIONAL WARNINGS
• The apparatus shall not be exposed to dripping or splashing and
that no objects filled with liquids, such as vases, shall be placed
on apparatus.
• Main plug is used as disconnect device and it should remain
readily operable during intended use. In order to disconnect the
apparatus from the mains completely, the mains plug should be
disconnected form the mains socket outlet completely.
• Caution marking is located at the rear or bottom of the apparatus.
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE
BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
• WARNING: To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
• CAUTION: Use of controls or adjustments or performance of
procedures other than those specified may result in hazardous
radiation exposure.
• WARNING: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user's authority to operate the equipment.
• WARNING: Do not place this unit directly onto furniture surfaces
TOP VIEW
SOURCE PAIR POWER
Power ON/OFF
Pair Bluetooth
Press to pair manually.
Overview
SIDE VIEW
– TREBLE +
– VOLUME +
– BASS +
REAR VIEW
120V~60Hz
with any type of soft, porous, or sensitive finish. As with any
rubber compound made with oils, the feet could cause marks or
staining where the feet reside. We recommend using a protective
barrier such as a cloth or a piece of glass between the unit and the
surface to reduce the risk of damage and/or staining.
• WARNING: Shock hazard - Do Not Open.
• This product meets and complies with all Federal regulations.
WARNING : This product can expose you to chemicals
including lead, which is known to the State of California
to cause cancer and birth defects or other reproductive
harm. For more information go to www.P65Warnings.
ca.gov. This product meets and complies with
required Federal product guidelines.
WARNING: TO REDUCE THE RISK OF
CAUTION
RISK OF ELECTRIC SHOCK
ELECTRIC SHOCK, DO NOT REMOVE COVER
DO NOT OPEN
(OR BACK). NO USER-SERVICEABLE PARTS
ATTENTION
INSIDE. REFER SERVICING TO QUALIFIED
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
This symbol indicates that this product incorporates double
insulation between hazardous mains voltage and user
accessible parts.
AUDIO INPUT
RCA Audio Input
R L
SPEAKER
OUTPUT
L
R
Treble
Volume
Bass
Stereo Speaker
Outputs
