Summary of Contents for Nordmende RTL398WH

  • Page 1 Fridge / User Manual RTL398WH...
  • Page 2 Thank you for choosing this product. This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance. Please take the time to read this user manual before using your appliance and keep this book for future reference.

  • Page 3: Table Of Contents

    CONTENTS 1 SAFETY INSTRUCTIONS ................4 1.1 General Safety Warnings ....................4 1.2 Installation warnings .......................8 1.3 Electrical information (For UK type plug) ................8 1.4 During Usage........................9 2 DESCRIPTION OF THE APPLIANCE ............10 2.1 Dimensions ........................11 3 USING THE APPLIANCE ................12 3.1 Information on No-Frost technology ................12 3.2 Display and Control Panel ....................12 3.3 Operating Your Fridge ....................12...

  • Page 4: Safety Instructions

    1 SAFETY INSTRUCTIONS 1.1 General Safety Warnings Read this user manual carefully. WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
  • Page 5 natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your fridge away from open flames or heat sources and ventilate the room where the appliance is located for a few minutes.
  • Page 6 • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Page 7 To avoid contamination of food, please respect the following instructions: • Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance. • Clean regularly surfaces that can come in contact with food and accessible drainage systems •...

  • Page 8: Installation Warnings

    1.2 Installation warnings at the top of your appliance. Do not place anything on top of your appliance. Before using your fridge for the first time, • Do not place heavy items on the please pay attention to the following points: appliance.

  • Page 9: During Usage

    Old and Out-of-order Fridges • If your old fridge or freezer has a lock, break or remove the lock before discarding it, because children may The mains lead of this appliance has been get trapped inside it and may cause an fitted with a BS 1363A 13A fused plug.

  • Page 10: Description Of The Appliance

    2 DESCRIPTION OF THE Packaging and the Environment Packaging materials protect APPLIANCE your machine from damage that may occur during transportation. This appliance is not intended to be used The packaging materials are as a built-in appliance. environmentally friendly as they are recyclable.

  • Page 11: Dimensions

    2.1 Dimensions Overall dimensions 1860,0 595,0 650,0 the height, width and depth of the appliance without the handle. Overall space required in use 981,6 Space required in use 1243,5 2010,0 the height, width and depth of the 695,0 appliance including the handle, plus the space necessary for free 744,1 circulation of the cooling air, plus...

  • Page 12: Using The Appliance

    3 USING THE APPLIANCE 3.2 Display and Control Panel 3.1 Information on No-Frost technology No-frost refrigerators differ from other static refrigerators in their operating principle. In normal refrigerators the humidity entering the refrigerators due to opening the door and the humidity inherent in the food causes freezing in the backside of air duct.

  • Page 13: Fridge Temperature Adjustment

    3.3.1 Fridge Temperature Adjustment • The cooler temperature segment will show “SC”. • The initial temperature value for the During Super Cooling Mode cooler setting indicator is +4 °C. Economy mode cannot be selected. • Press the "Set" button once. Super cooling mode can be cancelled in the same way it is selected.

  • Page 14: The Child Lock Function

    • If you press any button while the control class stated in the information label. It panel lights are off, the current settings is not recommended that your fridge is will appear on the screen, then you can operated in the environments which are make any adjustment you want.

  • Page 15: Accessories

    3.5 Accessories 3.5.3 The Fresh Dial (In some models) (The images are representative) Visual and text descriptions in the accessories section may vary according to the model of your appliance. 3.5.1 The Bottle Holder (In some models) Use the bottle holder to prevent bottles from slipping or falling over.

  • Page 16: Adjustable Door Shelf (In Some Models)

    3.5.4 Adjustable Door Shelf (In some 3.5.5 Adjustable Glass Shelf (In some models) models) Six different height adjustments can be Adjustable glass shelf mechanism provides made to provide storage areas that you higher storage spaces with a simple need by adjustable door shelf. movement.

  • Page 17: Food Storage

    4 FOOD STORAGE products and clean any leakages on the shelves. • Do not put food in front of the air flow 4.1 Refrigerator Compartment passage. For normal operating conditions, set the • Consume packaged foods before the temperature of the cooler compartment to recommended expiry date.

  • Page 18: Cleaning And Maintenance

    5 CLEANING AND Maximum How and where to Food MAINTENANCE storage time store Fresh On the designated 3 - 4 days Disconnect the unit from the power cheese door shelf supply before cleaning. Butter and On the designated 1 week margarine door shelf Do not wash your appliance by...

  • Page 19: Defrosting

    6 SHIPMENT AND 5.1 Defrosting REPOSITIONING 6.1 Transportation and Changing Positioning • The original packaging and foam may be kept for re-transportation (optional). • Fasten your appliance with thick water tray packaging, bands or strong cords and follow the instructions for transportation •...

  • Page 20: Before Calling After-Sales Service

    7 BEFORE CALLING AFTER-SALES SERVICE Errors If you are experiencing problems with your refrigerator, please check the following before contacting the after-sales service. ERROR TYPE MEANING REASON REMEDY Appears when one or more of the refrigerator Call a service agent for assistance as Failure warnings parts fail or there is a soon as possible.
  • Page 21 container. This noise is normal during Recommendations defrosting. • If the appliance is switched off or Air blowing noise occurs: In some unplugged, wait at least 5 minutes before models during normal operation of the plugging the appliance in or restarting system due to the circulation of air.

  • Page 22: Tips For Saving Energy

    8 TIPS FOR SAVING ENERGY 9 TECHNICAL DATA 1. Install the appliance in a cool, well- The technical information is situated in ventilated room, but not in direct sunlight the rating plate on the internal side of the and not near a heat source (such as a appliance and on the energy label.

  • Page 23: Information For Test Institutes

    7 or 10 years, based on the type of component, from the placing on the market of the last unit of the model. Visit our website to: Republic of Ireland & Northern Ireland www.nordmende.ie Great Britain www.nordmende.co EN - 23...
  • Page 24 52369043...
