- Page 1 HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com TECH SUPPORT VICI AG INTERNATIONAL Europe, Asia, Africa, Australia & New Zealand: Parkstrasse 2 techsupport@vicidbs.com CH-6214 Schenkon Switzerland USA, Canada, Central & South America: techsupportusa@vicidbs.com tel: +41 41 925-6200 fax: +41 41 925-6201 Italy web: www.vicidbs.com service@vicidbs.com Version 1.02.0000...
-
Page 2: Table Of Contents
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com TABLE OF CONTENTS 1. VERSION HISTORY ..........................2 2. INTRODUCTION ............................ 3 2.1 Symbol Definitions ..........................3 3. SAFETY ..............................4 3.1 Personal Safety Instructions .........................4 3.2 Instrument Safety Instructions ......................4 4. SPECIFICATIONS ..........................5-6 5. PRESENTATION OF THE DEVICE ......................7 5.1. -
Page 3: Version History
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 1. VERSION HISTORY VERSION DATE COMMENT/CHANGE 1.00.0100 01/10/2017 Layout and initial release, VICI DBS 1.01.0000 Update 1.02.0000 08/25/2020 New layout, images and graphics, VICI Gig Harbor Group Version 1.02.0000... -
Page 4: Introduction
USER MANUAL www.vicidbs.com 2. INTRODUCTION The VICI DBS HP Plus Tower produces nitrogen by utilizing a combination of filtration and pressure swing adsorption ® (PSA) technology. Standard compressed air is filtered by high efficiency coalescing filters to remove all contaminants down to 5 micron. -
Page 5: Safety
• The power supply main cable connector is the disconnect device in case of emergency. It must be easily accessible at any time. • If the HP Plus Tower/Rack is used in a way not specified by VICI DBS, the equipment warranty becomes void. -
Page 6: Specifications
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 4. SPECIFICATIONS MODELS & SPECS - HP PLUS HP PLUS HP PLUS HP PLUS HP PLUS Without Catalyst 1000 2000 4000 Flow mL/min 1000 2000 4000 Purity >99.999% Hydrocarbon purity (measured as methane) Dewpoint -50 (-58) Outlet pressure barg (psig) Up to 5 (75) - Page 7 HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com MODELS & SPECS - HP PLUS HP PLUS HP PLUS HP PLUS HP PLUS HP PLUS HP Plus Rack With Catalyst 200 HC 500 HC 750 HC 1000 HC 2000 HC 4000 HC Flow mL/min 1000 2000 4000...
-
Page 8: Presentation Of The Device
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 5. PRESENTATION OF THE DEVICE 5.1 Front View On the front of the device, there is a luminescent LED bar. When the unit is running properly, the line is illuminated. This line is blinking red when the HP Plus Tower/Rack is in alarm, and blinking blue (0.5 Hz) when catalytic oven is warming up. -
Page 9: Back View
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 5.2 Back View Cooling Fan N2 Gas Outlet Power Cord Socket Filter Inlet for Compressed Air Fuse Box and 230-115V Selector Filter Cartridge Cooling Fan Power Cord Socket Filter Inlet for Compressed Air Fuse Box and Filter Cartridge N2 Gas Outlet 230-115V Selector... -
Page 10: Installation
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 6. INSTALLATION The HP Plus Tower is designed to be placed in a vertical position. After unpacking, set the instrument on a table with the front panel facing forward and make sure that the back panel is not obstructed. The HP Plus Rack can be placed on a table or in a 19”... -
Page 11: Transport And Storage Conditions
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 6.2. Transport and Storage Conditions TEMPERATURE Minimum -10ºC (50ºF); Maximum 45ºC (113ºF) HUMIDITY 10-90% relative humidity SHOCKS & VIBRATIONS DURING TRANSPORT Shocks <1g; Vibrations <0.2g/5Hz INSTRUMENT POSITION Vertical on a flat surface The above-mentioned values are considered for an instrument transported in its original new packaging. The HP Plus Tower could be elevated from any points under the chassis base. -
Page 12: Schematics
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 7. SCHEMATICS 7.1. Fluidics System: HP PLUS / HP PLUS HC Date: THIS DOCUMENT AND THE INFORMATION WHICH Rev.: IT CONTAINS SHALL NOT BE USED, EXPLOITED Description: fluid diagram Created: 15. Jun. 2020 OR SOLD, AND SHALL NOT BE REVEALED OR ECN no: DISCLOSED TO OTHERS WITHOUT THE EXPRESS WRITTEN PERMISSION OF VICI. -
Page 13: Electronics
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 7.2. Electronics Date: THIS DOCUMENT AND THE INFORMATION WHICH Rev.: IT CONTAINS SHALL NOT BE USED, EXPLOITED Created: 25.06.20 OR SOLD, AND SHALL NOT BE REVEALED OR ECN no DISCLOSED TO OTHERS WITHOUT THE EXPRESS WRITTEN PERMISSION OF VICI. -
Page 14: Operation
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 8. OPERATION 8.1. Starting the Generator Read the Operating Manual carefully. • Connect the HP Plus Tower/Rack to the power supply • Connect compressed air to the coalescent filter and release the pressure (P≥7bar, Tdp≤-40°C) •... - Page 15 HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com Outlet Pressure Outlet Pressure Regulator Manometer Pressure Gauge Pressure Regulator Version 1.02.0000...
-
Page 16: Maintenance
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 8.3. Maintenance WARNING: Before servicing, make sure that the system shutdown has been performed according to instructions above. 1. Supply air pressure has been shut off with an in-line valve 2. Line pressure has been released with an in-line relief valve 3. -
Page 17: Three Year Catalyst Replacement Kit
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 1. Remove the filter bowl by pressing on the lever and turning the bowl counterclockwise until the arrows are aligned (Diagram 1 and 2). 2. Unscrew the base element of the filter and remove the element (Diagram 3). 3. -
Page 18: Led Light Band
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 8.4. LED Light Band The light band indicates the state of the device. LIGHT STATE DEVICE STATE Device is off, gas is blocked Green - Solid Startup check is okay Blue - Solid Device runs normally and the optional catalyst has reached the operating temperature 650ºC +/- 40ºC (1202ºF +/ - 104ºF). -
Page 19: Alarms & Warnings
HP PLUS TOWER/RACK USER MANUAL www.vicidbs.com 9. ALARMS AND WARNINGS When an alarm or a warning occurs, the LED band blinks in red. When the device works properly, the LED band remains at a steady state. When the light is turned off the generator is switched off. 9.1. -
Page 20: Troubleshooting
• Please refer to the service manual before making any changes to the instrument. • Please contact our service department before doing any repairs. • If the device is open without agreement of the VICI DBS Service department, the warranty will be void.
