- Page 1 Microwave Linear Intrusion Sensor «FORTEZA-300», «FORTEZA-500» «FORTEZA-300T», «FORTEZA-500T» User manual Document Part Number 4372-43071246-003 2003...
-
Page 2: Table Of Contents
CONTENTS Introduction ......................3 Purpose ........................ 3 Specifications ...................... 3 Sensor components ....................5 Sensor structure & operation ................5 5.1. Sensor principle of operation ................5 5.2. Control and indication parts ................6 5.3. Sensor operation ....................7 Sensor construction ..................... 8 6.1. -
Page 3: Introduction
«FORTEZA-300T», «FORTEZA-500T» from -50˚ up to +60˚C and relative humidity up to 98% at the temperature +35С. 3. SPECIFICATIONS There are four modifications of the sensor: «FORTEZA-300», «FORTEZA-300T», 3.1. «FORTEZA-500» and «FORTEZA-500T». The recommended length of a sector for modifications: «FORTEZA-300», «FORTEZA-300T»... - Page 4 Table 3.1. Sector length, Detection zone width, m 3.4. The sensor generates an alarm when: an intruder crosses the detection zone (perpendicularly to the axis) at a speed from 0,1 up to 10 m/sec standing up straight or bended (crawling through) with the minimum detection probability of 98 %;...
-
Page 5: Sensor Components
3.12. The sensor adapts to the environment and doesn’t generate the false alarm at: rain, snow, thick fog; solar radiation; wind speed up to 30 m/sec.; moving of objects with the linear dimensions up to 0,2 m (birds or small animals)not closer than 3m from Rx or Tx;... -
Page 6: Control And Indication Parts
The sensor principle of operation is based on generate an electromagnetic field between Tx and Rx. This field forms a volumetric detection zone in the form of a long ellipsoid of rotation. The sensor registers changes of the field when an intruder crosses the protected zone. -
Page 7: Sensor Operation
small time constant by pressing the button «AGC» (automatic gain control) on Rx. In this case an express setup of the amplifier takes place in the standby state. 5.2.5. On the Rx unit the blocking button is placed in order to prevent unauthorized openings of the back panel. -
Page 8: Sensor Construction
6. SENSOR CONSTRUCTION The sensor consists of separate units (Rx, Tx) placed in dust- and splash-proof enclosures. 6.1. Rx construction 6.1.1. Rx construction and its fastening elements to the support are shown in fig. 6.1. The bearing structure of Rx 1is a parabolic antenna. The exciter is fixed inside of this antenna (in the focus of parabola). - Page 9 1-receiver (transmitter) 1 item; 8-screw M12 1 item; 2-aiming plate 1 item; 9-bent washer 12 1 item; 3-plug 2 items; 10- washer 12 1 item; 4-buckle 2 items; 11- corrugated pipe 1 item; 5-buckle lock 2 items; 12-cable 1item; 6- round support (tube) 1 item;...
- Page 10 1 – indicator «PROTECTION» 4 – «AGC» button 2 – thresholding «MIN-MAX» 5 – blocking button 3 – socket «TEST» 6 – marking of cable cords Fig.6.2 Note. Dear user! The manufacturer of the sensor constantly improves their quality and reliability. That’s why in some lots of the sensors there are can be design modifications unspecified in the documents delivered with the sensors.
-
Page 11: Safety Measures
7. SAFETY MEASURES 7.1. The current safety standards for the operation with electrical facilities with the voltage up to1000 V should be observed during mounting, preventive maintenance and repair of the sensor. The sensor is supplied by a dc source of the voltage 9…30 V or by an alternating- 7.2. -
Page 12: Mounting Procedure
Besides, in some cases the sensors interference immunity can reduce. It can be detected while the trial operation; the sector’s length is: «Forteza-300» - from 10 up to 300m; «Forteza-500» - from 10 up to 500m; the sector bias isn’t restricted. 8.2. - Page 13 Other variants of the sensor installation (for example on the fence or wall) can be applied according to the protection tactics. As the fence deforms the detection zone configuration, the sensor operation depends on the place of its mounting. The example of the support installation is shown in fig.
-
Page 14: Sensor Connection
1- support; 2- dowel; 3- ground; 4-concrete; 5-holes for main cable connection Notes. For A size the ground should be laid after installation works. Dimensions are given in millimeters. Fig. 8.1 8.3. Sensor connection 8.3.1. Connect the necessary power, signal and remote control circuits. Rx and Tx units are connected with its own cables. - Page 15 Table 8.1 Marking Colour Purpose Marking Colour Purpose «+» «+» white white Supply Supply voltage voltage 9…30 V 9…30 V «-» «-» brown brown Remote control Normally «NC» «RC» yellow green +5…30 closed contacts of actuating «NC» pink relay «TAMPER» green Contacts of blocking...
- Page 16 when an additional button is installed at the post. It is possible to install one button for several sensors. In this case the button pressing checks the operation of all sensors. The scheme of the sensor connection using the lightning guard unit «LGU-4» is shown in Figure 8.3.
- Page 17 Fig.8.3...
-
Page 18: Preparation Of The Sensor For Operation
Fig.8.4 9. PREPARATION OF THE SENSOR FOR THE OPERATION AND ALIGNMENT 9.1. Sensor preparation for its operation 9.1.1. Check the correctness of supply and output circuits connection. 9.2. Alignment of Tx and Rx 9.2.1 . Align Tx and Rx antennas at the height of 0,5m.The height is measured from the lower antenna edge to the ground (fig.6.1). -
Page 19: Rx Threshold Adjustment
small angle so the voltage does not exceed 4,5 V. Don’t desalign Rx and Tx down or aside. The sensor is operable at the «TEST» voltage from 0,1 up to 4,8 V. The boundary values of 1,2V and 4, 5V are recommended to create the signal level margin and provide long-term stable operation;... -
Page 20: Check Of Technical State
10. CHECK OF TECHNICAL STATE 10.1. Check of sensor operation 10.1.1. During the exploitation it is recommended to test the sensor operability transmitting the remote control signal («RC») 1-3 times a day. 10.2. Servicing 10.2.1. The sensor maintenance should be conducted by people, who underwent special safety trainings. -
Page 21: Troubleshooting Guide
11. TROUBLESHOOTING GUIDE List of possible troubles is given in Table 11.1. Table 11.1 Trouble Possible Cause Repair 1. The receiving- Check the cable integrity control device 1. Communication line is and the accuracy of its constantly generates broken. connection. Restore the an alarm. -
Page 22: Storage
12. STORAGE 12.1. The sensors should be warehoused in the package at an ambient temperature from +5С up to +30 С and relative humidity 85% maximum. During storage the influence of hostile environment should be prevented. 13. TRANSPORTATION 13.1. Packaged sensors can be transported by any transport (if by air transport – in pressurized modules) if they are transported in covered cars, holds or covered bodies at the distance up to 10 000 km. -
Page 23: Certificate
1 item. 2. ACCEPTANCE CERTIFICATE «FORTEZA-300», «FORTEZA-500» sensor («FORTEZA-300T», «FORTEZA-500T») № ________________meets performance specifications of the Document Part Number 4372-43071246-003 and it is considered as operable. Date of issue _________201 . Quality department 3. MANUFACTURER’S WARRANTIES 3.1. The manufacturer guarantees the conformity of the sensor specifications to the... - Page 24 JSC «Okhrannaya Technika» Manufacturer Postal address Russia, 442960, Zarechnyj, Penza region, post office box 45. Contacts Tel. +7 8412 655316 Fax. +7 8412 655316 E-mail: info@forteza-eu.com The detailed information you can find at www.FORTEZA-EU.com...
