- Page 1 STM-4D: ARC Solo Digital Temperature Module & Sensors Installation and Operation Manual...
-
Page 2: Table Of Contents
Cable Orientation and Pinouts ....................6 Daisy-Chain Connection of Digital Sensors ................7 Specifications ..........................8 Connectors: ..........................8 Temperature Range: ......................8 Cables: ........................... 8 Getting Help ..........................9 Warranty ............................ 9 STM-4D Installation and Operation Manual Rev B... -
Page 3: Introduction
Introduction The STM-4D ARC Solo Digital Temperature Module connects up to four digital temperature sensors to the ARC Solo remote control system utilizing the rear panel SENSORS port and a supplied 4-way RJ11 Splitter. Temperature output is user selectable to Fahrenheit or Celsius, based on the user setting in the setup section of the ARC Solo web page. -
Page 4: Temp-Outdoor Sensor
TEMP–OUTDOOR Sensor The TEMP-OUTDOOR digital outdoor temperature sensor is included with the STM-4D, and is intended for general purpose monitoring of equipment or ambient temperatures. The TEMP-OUTDOOR sensor is attached to 25’ of cable with an RJ-12 connector on the end. The sensor has a mounting ring and gasket to accommodate #6 or #8 hardware. -
Page 5: Installation
1. Position the back half of the enclosure against the surface where the TEMP-WALLMOUNT will mount. 2. Using the enclosure as a template, mark reference circles at each of the two mounting slots and the cable entry point. STM-4D Installation and Operation Manual Rev B... -
Page 6: Temp-Stack Sensor
Use the provided drop-down boxes to assign each active temperature sensor to an ARC Solo meter channel. No calibration is necessary. Please refer to your ARC Solo manual for detailed instructions on meter setup. STM-4D Installation and Operation Manual Rev B... -
Page 7: Cable Orientation And Pinouts
SENSOR CABLE with an RJ12 COUPLER. Since each of these has crossover wiring, they provide a straight-through connection from end to end when connected together. STM-4D Installation and Operation Manual Rev B... -
Page 8: Daisy-Chain Connection Of Digital Sensors
Multiple digital temperature sensors can be connected to ARC Solo using a daisy-chain arrangement. This can be accomplished by first plugging one RJ12 SPLITTER into each TEMP- INDOOR as shown below: Plug one RJ12 Splitter into each Temp-Indoor Sensor STM-4D Installation and Operation Manual Rev B... -
Page 9: Specifications
Sensors: -55°C to +125°C, ± 0.5C from –10C to 85C Cables: TEMP-INDOOR: Requires Burk SENSOR CABLE, not included TEMP-WALLMOUNT: Includes 14’ prewired cable TEMP-OUTDOOR: Includes 25’ prewired cable TEMP-STACK: includes 25’ prewired cable STM-4D Installation and Operation Manual Rev B... -
Page 10: Getting Help
TEMP-STACK to be free of defects in materials and workmanship for a period of 24 months from the date of purchase. Equipment will be repaired or replaced at the option of Burk Technology and returned freight prepaid to the customer. Damage due to abuse or improper operation or installation of the equipment or caused by fire or flood or harsh environment is not to be covered by this warranty.
