Summary of Contents for BURK Technology BTU-4

  • Page 1 BTU-4 & Sensors Installation and Operation Manual...
  • Page 2: Table Of Contents

    Outputs: ............................. 5 Sensor Temperature: ........................ 5 Cable Length: ..........................5 BTO Outdoor Sensor: ........................ 5 BTI Indoor Sensor: ........................5 BTS Stack Sensor: ........................5 Getting Help ..........................6 Warranty ............................6 Copyright © 2017 Burk Technology, Inc. Rev. D...
  • Page 3: Introduction

    This allows the installer to locate the sensor up to 9 1/2” from the equipment wall, well within the airflow being monitored. BTU-4 Installation and Operation Manual Rev D...
  • Page 4: Installation

    4. Plug the connector of the BTO into one of the four available input jacks on the BTU‐4. 5. Connect the output sample pin associated with the appropriate input jack from the BTU‐4 to the remote control equipment. 6. Plug the AC adapter into the BTU‐4. BTU-4 Installation and Operation Manual Rev D...
  • Page 5: Bti – Indoor Sensor

    7. Plug the connector of the BTS into one of the four available input jacks on the BTU‐4. 8. Connect the output sample pin associated with the appropriate input jack from the BTU‐4 to the remote control equipment. 9. Plug the AC adapter into the BTU‐4. BTU-4 Installation and Operation Manual Rev D...
  • Page 6: Remote Control Setup

    Calibrate the desired channel(s) to read the actual temperature (if true input value = 0.70 [Volts], calibrate value = 70 [Degs]). The displayed value must be static (no fluctuations) during calibration. Please refer to your GSC300 or VRC2500 manual for detailed instructions on calibrating metering channels. BTU-4 Installation and Operation Manual Rev D...
  • Page 7: Specifications

    15’ shielded 1/4” phono cable; Mount with #6 or #8 hardware BTI Indoor Sensor: 2 5/8” x 5” enclosure BTS Stack Sensor: 15’ shielded 1/4” phono cable; 3/8” chrome tube; Mounting depth up to 9 1/2” BTU-4 Installation and Operation Manual Rev D...
  • Page 8: Getting Help

    5PM Eastern Time. Warranty Burk Technology, Inc. warrants the BTU‐4, BTO, BTI, and BTS to be free of defects in materials and workmanship for a period of 24 months from the date of purchase. Equipment will be repaired or replaced at the option of Burk Technology and returned freight prepaid to the customer.
