Summary of Contents for BURK Technology Plus-X IIU
- Page 1 Plus-X IIU Installation and Operation Manual...
-
Page 2: Table Of Contents
Initial Connection Without DHCP ....................3 Set a Static IP Address ......................4 Complete the Network Settings ....................5 Connecting the Plus-X IIU to the ARC Plus .................. 5 Connecting Analog and Status Inputs ................... 6 Using Metering Inputs for Additional Status .................. 7 Input Diagnostics .......................... -
Page 3: Introduction
X IIU connects up to 16 metering and 32 status channels. 16 inputs are dedicated to status. 16 inputs may be used as meter or status, for a total of up to 32 status channels. Plus-X IIU units are connected to the ARC Plus via LAN or WAN. Up to 32 Plus-X devices can be connected to each ARC Plus. -
Page 4: Network Settings
* Hostnames can be used in either upper or lower case. Initial Connection Using DHCP Connect the Plus-X IIU to your LAN and apply power. If this is the first power-up for a new unit or the first network connection after execution of a master-initialization, the Plus-X IIU will issue a DHCP request for an IP address. -
Page 5: Initial Connection Without Dhcp
If your network does not support the DHCP protocol, the Plus-X IIU’s request for a dynamic IP address will fail. If this happens, the Plus-X IIU will assign itself the default static IP address of 192.168.0.100. To access the unit, it will be necessary to connect your PC directly to the Plus-X device using a crossover LAN cable or using a simple Ethernet switch. -
Page 6: Set A Static Ip Address
Enter a static IP address for this unit as assigned by your network administrator in the IP Address box and click Save. Note: It is important that the assigned static IP address be outside the DHCP address range used by the router to avoid potential conflicts with other DHCP devices. Plus-X IIU Installation Guide Rev B... -
Page 7: Complete The Network Settings
Connecting the Plus-X IIU to the ARC Plus If you have not already done so, install the Plus-X IIU in the equipment rack. If you wish, you may distribute Plus-X units in multiple racks, or at different locations. To add the channels from... -
Page 8: Connecting Analog And Status Inputs
9. Select File>Save to save the changes to the ARC Plus. Connecting Analog and Status Inputs Each Plus-X IIU connects up to 16 metering inputs (±10VDC) and 16 status inputs (0-28VDC or switch closure). Meter inputs may be used as status channels by setting the high and low voltage thresholds (see below). -
Page 9: Using Metering Inputs For Additional Status
Using Metering Inputs for Additional Status Each of the 16 metering inputs on the Plus-X IIU can be used as a status input (either as an alternative to the metering input or in addition to it). To configure the metering input behavior, use a web browser to connect to the Plus-X IIU. -
Page 10: Input Diagnostics
Meter inputs 1 through 16 on the Plus-X IIU are identified as status inputs 17 through 32. For example, to map meter input 1 on the Plus-X IIU to a status channel on the ARC Plus, select Plus-X IIU status input 17 from the source selector drop-down box in AutoLoad Plus. -
Page 11: Warranty
Warranty Burk Technology, Inc. warrants the Plus-X IIU to be free of defects in materials and workmanship for a period of 24 months from the date of purchase. Equipment will be repaired or replaced at the option of Burk Technology and returned freight prepaid to the customer. -
Page 12: Appendix A: Specifications
Metering channels may be used as status inputs for a total of 32 status channels. Metering Input Range: -10 to +10VDC Metering Input Accuracy: > 99.75% accuracy, full scale Status Input Range: > 0 to +28VDC or switch closure Plus-X IIU Installation Guide Rev B...
