Chicago Gaming REDLINE GT Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200
Flat Panel Television and
Flight Controls Not Included
Display Requirements: 32" to
42" Television with HDMI Input
4616 W. 19th Street, Cicero, IL 60804 (800) 379-9776
Rev 0.3
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the REDLINE GT and is the answer not in the manual?

Questions and answers

Related Manuals for Chicago Gaming REDLINE GT

Summary of Contents for Chicago Gaming REDLINE GT

  • Page 1 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Flat Panel Television and Flight Controls Not Included Display Requirements: 32” to 42” Television with HDMI Input 4616 W. 19th Street, Cicero, IL 60804 (800) 379-9776 Rev 0.3...
  • Page 2 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Redline GT Thank you for purchasing Chicago Gaming Company’s Redline GT. We strongly recommend that you follow the instructions and procedures as presented in this Owner’s Manual and that it be read in its entirety before setting up your game.
  • Page 3 • Be sure to install it in a dry location. • Plug the machine into a three-prong A/C outlet. 2.2 SUPPORTED TELEVISIONS • Redline GT supports most 32” to 42” flat panel televisions, or those with VESA compliant mountings up to 400mm x 400mm.
  • Page 4 2.3 Key Features Sliding Steering Wheel Speakers Adjustable Racing Pedals Adjustable Racing Seat Storage Cabinet Main Power Switch Volume Control Seat Shaker Control Rotating Flight Control Mounts Collapsible Arm Rests For more details on the features of Redline GT, see page 19...
  • Page 5 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 3. How to Assemble Seat Cabinet Monitor Cabinet Cabinet Connector Brackets Foot Box Shifter Steering Wheel Shift Mounting Bracket Flight Control Arms Flight Control Mounting Brackets Tube Covers TV Support Brackets...
  • Page 6 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Hardware List Connector Bracket Hardware (12x) ¼-20 x 1-¾” Black Socket Head Cap Screws (12x) ¼” Black Flat Washers Foot Box Connect Hardware (4x) ¼-20 x 1-¾” Hex Head Bolts (4x) ¼”...
  • Page 7 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 3.1 Connecting the Cabinets Start by removing the lid of the Foot Box. Remove the four Phillips head screws to free the lid, and it will pull straight up.
  • Page 8 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Align the Seat Cabinet , Foot Box and Monitor Cabinet as shown here. NOTE: For the three components to align properly, this step must be performed on a level floor. Pull these four cables through and make sure they do not get pinched...
  • Page 9 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Pull these three cables through and make sure they Push the Seat Cabinet do not get pinched up to the Foot Box as shown, so that the Connector Brackets are resting on the bases of the Monitor Cabinet...
  • Page 10 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 3.2 Connecting the Shifter Align the Shifter Mounting Bracket with the mounting holes on the Seat Cabinet so the wood piece is facing up, as shown here. Secure the bracket in place using the four screws and washers in the bag marked Shifter Mounting Hardware.
  • Page 11 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 3.3 Connecting the Flight Control Arm Assembly NOTE: Flight Control Arm installation is optional. Install only if you intend to purchase flight controls. If you are not planning on installing flight controls, please skip to page 15. The image on the right shows an exploded image of the left Flight Control Arm.
  • Page 12 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Take the right Flight Control Arm and slide it through the mounted Flight Control Mounting Bracket. Reattach the screw and washer you removed from the bottom of the tube as shown.
  • Page 13 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Slide the Tube Cover over the Flight Control Mounting Bracket, aligning the mounting holes. Using the four screws and washers you removed; attach the Tube Cover to the bracket you mounted.
  • Page 14 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 3.4 Connecting Flight Controls The Flight Control Arms of Redline GT are designed to work with the Saitek X52 Flight System. Other flight control sticks will work, but you may have to measure and drill the correct mounting holes through the wooden mounting piece.
  • Page 15 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 3.5 Television Support Brackets The TV Support Brackets are designed to work with televisions that have VESA standard mounting holes from 200mm x 200mm to 400mm x 400mm. One end of the bracket connects to the back of your television, and the other connects to the Monitor Cabinet.
  • Page 16 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 You will now need to adjust the length of the TV Support Brackets so that the bottom mounting hole lines up with the pilot holes behind the television. Loosen, but do not remove, the two screws in the center of the bracket.
  • Page 17 Foot USB flight sticks, Box. These cables power cable F is unused. the strip lighting that runs underneath Redline GT. When you have finished connecting Connect the Shifter cable the cables, replace that you pulled through...
  • Page 18 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 4. Connecting Gaming Systems Slide your Playstation into the cabinet on the left side. Running the cables through the back of the cabinet, connect the HDMI cable to the Playstation and HDMI port on the television.
  • Page 19 So that the Logitech Racing Wheel will work with both a Playstation and computer, Redline GT has a USB Switcher. The USB Switcher lets you toggle the steering and flight controls between the Playstation and computer.
  • Page 20 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 The electronics case is located in the back of the Monitor Cabinet. This contains the power supply and amp for the speaker system. The 3.5mm audio jack is on the top right side of the electronics case.
  • Page 21 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Pull the armrests up and they will lock in place. To release the armrests pull the release handle. To move the pedal forward or back, lift the locking bar in front of the pedal and slide the pedal in the direction you need.
  • Page 22 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 4. Compatible Games PC driving games supporting the six-speed shifter, 900-degree steering, and force feedback of the Logitech G27 Racing Wheel: DiRT 2 by Codemasters GTR2 by SimBin Live for Speed by Scawen Roberts, Eric Bailey, Victor van Vlaardingen...
  • Page 23 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 PLAYSTATION®3 Continued Need for Speed™: Carbon by Electronic Arts Need for Speed™: ProStreet by Electronic Arts Need for Speed™: SHIFT by Electonic Arts Need for Speed™: Undercover by Electronic Arts PLAYSTATION 3 driving games supporting the 900-degree steering and force feedback of the Logitech G27 and Driving Force GT wheels:...
  • Page 24 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 PLAYSTATION®3 Continued NASCAR® 09 by Electronic Arts Need for Speed™: Undercover by Electronic Arts Ridge Racer 7 by Namco Sega Rally Revo™ by Sega Stuntman: Ignition by THQ PlayStation®2 PlayStation 2 driving games compatible with the 900-degree steering of the...
  • Page 25 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 PlayStation®2 Continued Burnout 3 Takedown™ by Electronic Arts Burnout™ Revenge by Electronic Arts Burnout™ Dominator by Electronic Arts Colin McRae™ 3 by Codemasters Colin McRae™ Rally 4 by Codemasters Colin McRae™...
  • Page 26 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 PlayStation®2 Continued Grand Prix Challenge by Atari Hot Wheels ™ Velocity X by THQ Initial D: Special Stage by Sega Juiced™ by THQ Knight Rider™ by Universal Interactive Lotus Challenge™...
  • Page 27 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 PlayStation®2 Continued NHRA™ Championship Drag Racing™ by VSE Games Pro Race Driver by Codemasters R: Racing Evolution by Namco Rally Championship by Codemasters Rally Fusion: Race of Champions by Activision Richard Burns Rally™...
  • Page 28 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 5. Playstation Button Layout This section shows the button configuration for the Logitech G27 Racing Wheel when used with the Playstation 3. Select Start Right Stick Up Left Stick Up...
  • Page 29 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 5. Recommended Settings for Playstation 3 Games Here we will recommend settings for Playstation 3 games that are compatible with the G27 Racing Wheel. You can use this as a guide when adjusting the settings to your preference. Burnout™...
  • Page 30 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Ferrari Challenge: Trofeo Pirelli Assists Wheel Sensitivity: Medium Pedal Sensitivity: High Force Feedback: High F1 2010 Advanced Settings Steering Deadzone: 0% Steering Saturation: 100% Steering Linearity: 40% Accel.
  • Page 31 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Gran Turismo™ 5 We recommend using the default settings. Force Feedback Strength can be adjusted. Buttons can be reassigned. Gran Turismo 5 Prologue™ We recommend using the default settings.
  • Page 32 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 NASCAR ® You can adjust the steering wheel linearity and responsiveness. Set Linearity to 60. Set Responsiveness to 80. Buttons can be reassigned. NASCAR ® You can adjust the steering wheel linearity.
  • Page 33 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Need for Speed™: Hot Pursuit We recommend using the default settings. There are no advanced wheel settings. Buttons can be reassigned. Need for Speed™: ProStreet We recommend using the default settings.
  • Page 34 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Need for Speed™: SHIFT 2 Unleashed Force Feedback Strength: 100% Steering Deadzone: 0% Steering Sensitivity: 85% Throttle Deadzone: 0% Throttle Sensitivity: 100% Brake Deadzone: 0% Brake Sensitivity: 100% Clutch Deadzone: 0% Clutch Sensitivity: 50% Speed Sensitivity: 0%...
  • Page 35 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Race Driver: GRID™ Wheel Advanced Steering Deadzone: 0% Steering Saturation: 100% Steering Linearity: 8 Accel. Pedal Deadzone: 0% Accel. Pedal Saturation : 100% Brake Pedal Deadzone: 0% Brake Pedal Saturation: 90% 900 Degree Wheel: Off Force Feedback...
  • Page 36 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 Split Second: Velocity There are no advanced wheel settings. Buttons cannot be reassigned. Stuntman: Ignition Gameplay Steering: 85 Force Feedback: 85 Buttons can be reassigned...
  • Page 37 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 6. AC Wiring Television Control To Wall Outlet Switch Electronic Case Playstation Computer Surge Protector Steering Foot Wheel Pedal Shifter...
  • Page 38 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 7. USB/Audio/Video Wiring HDMI Television Control Switch Audio Volume Knob Cables Electronic Case Audio Playstation Computer Surge Protector Steering Foot Wheel Pedal Shifter Serial Cable Serial Cable...
  • Page 39 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200 8. TECHNICAL SUPPORT Free telephone support is provided for the Redline GT system. Technical Support is available from 9:00-5:00 Central Time, Monday through Friday. Call (800)379-9776. Select technical support in phone system menu.
  • Page 40 To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | (800) 746-2255 | +1.561.391.7200...
