Technical data

Nominal voltage
Nominal capacity
Nominal energy
Discharge logic
Dimensions
Protection class
Charging temperature
Operating temperature
Storage temperature
Weight
Tab. 1: Technical data - HPR Range Extender
50.4 V
2.8 Ah
160 Wh
When operating the e-bike, the Range Extender
is discharged first afterwards the battery.
∅ 76 mm, length 185 mm / ∅ 3", length 7.3"
IP66
0 °C bis 40 °C / 32 °F bis 104 °F
-10 °C bis 60 °C / 14 °F bis 140 °F
10 °C bis 20 °C / 50 °F bis 68 °F
approx. 950 g / 2.1 lbs
(without frame fastening like FIDLOCK®)
EN - 5
