- Page 1 56” CEILING FAN Owner’s Manual Model #51637, 51638 RATED FOR WET LOCATION To obtain service, please contact the Service Department: 1-877-706-3267, 8 a.m. - 5 p.m. Central, Monday - Friday. 9711• 022621...
-
Page 2: Package Contents
PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: PACKAGE CONTENTS 1. Canopy 11. Motor Assembly 2. Canopy Cover 12. Fitter Plate 13. Fitter Plate Screw (x3) 3. Mounting Bracket Screw (x4) 14. Switch Housing 4. -
Page 3: Mounting Options
DIMENSION REFERENCE A. 15.9 in. B. 12.7 in. C. 7.4 in. D. 5.13 in. MOUNTING OPTIONS Two Mounting Options Downrod Mount Angle Ceiling Mount (Up to 16 degrees) Choose one of the following mounting options: Downrod Mount is best suited for ceilings 8 ft. or higher. For taller ceilings you may want to use a longer downrod (not included). -
Page 4: Safety Instructions
--Consult the dealer or an experienced radio/TV technician for help. Please note changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. HKC-US 3350 Player’s Club Parkway, #225 Memphis, TN 38125... - Page 5 SAFETY INSTRUCTIONS WARNING: To avoid risk of electric shock, be sure to shut off power at the main fuse or circuit breaker box before installing or servicing this fixture. Turning off the electrical power by using the light switch is not sufficient to prevent electrical shock.
- Page 6 ASSEMBLY INSTRUCTIONS 1. Turn OFF the electrical power at the main fuse or circuit breaker. DANGER: Failure to disconnect the power supply prior to installation may result in serious injury or death. Mounting Bracket Screw 2. Loosen all four mounting bracket screws located on the mounting bracket and completely remove the two screws from the round holes in the canopy.
- Page 7 ASSEMBLY INSTRUCTIONS Braided 5. Insert the downrod through the canopy and yoke cover. Cable Feed the wires and braided cable from the fan through the downrod. Canopy Yoke Cover Downrod Yoke 6. Slide the downrod into the yoke of the motor assembly, align the holes, then re-install the downrod pin and Downrod downrod clip.
- Page 8 ASSEMBLY INSTRUCTIONS Braided Cable SECONDARY HANGING SYSTEM For installation in the United States: Building codes in the U.S.A. do not require installation of a Secondary Brace Hanging System. If desired, the braided cable can be cut and removed using wire cutters (sold separately). Skip to Step 11.
- Page 9 ASSEMBLY INSTRUCTIONS 11. Use wire connectors to connect the fan wires to the Black (Hot) power supply wires according to the wiring diagram and White (Neutral) the following instructions: Bare/Green (Ground) • Connect the green wire from the downrod and mounting bracket to the bare/green (ground) supply wire.
- Page 10 ASSEMBLY INSTRUCTIONS 15. Remove the three switch housing screws from the switch housing cap. Align the holes in the switch housing cap with the holes in the switch housing. Then secure the switch housing cap using the three previously removed Switch switch housing screws.
- Page 11 OPERATING INSTRUCTIONS 1. Using a ceiling fan will allow you to raise your thermostat setting in summer and lower your thermostat setting in winter without feeling a difference in your comfort. In warmer weather, push the reverse switch left which will result in downward airflow creating a wind chill effect.
-
Page 12: Troubleshooting
TROUBLESHOOTING If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check the Troubleshooting section below. If a problem cannot be remedied or you are experiencing difficulty in installation, please contact the Service Department: 1-877-706-3267, 8 a.m. -
Page 13: Limited Lifetime Warranty
HKC’s sole responsibility shall be to repair or replace the motor, parts, or product within the terms stated above. HKC shall not be liable for any loss or damage of any kind, including any incidental or consequential damages resulting directly or indirectly, from any breach of warranty, express or implied, or any other failure of this product.
