- Page 1 INSTRUCTION MANUAL THERMO-COOKER EKB110 1. OPERATION AND TECHNICAL CHARACTERISTICS 2. INSTALLATION GUIDE 3. ACTIVATION AND MAINTENANCE...
-
Page 2: Supplied Accessories
For installation, maintenance and the warranty, see the THERMO-COOKERS and THERMO- STOVES use and maintenance booklet supplied with thermo-cooker EKB110. 2.3 DESCRIPTION OF THERMO-COOKERS EKB110 a) radiant cast-iron hotplate b) height-adjustable grill c) oven with thermometer d) oven light switch... - Page 3 The INTEGRATED OPEN TANK allows the separate operation of two circuits, primary (Thermo- cooker) and secondary (Heating) by a coil heat exchanger with excellent heat transfer. The thermo-cooker EKB110 can be equipped with a second exchange coil for domestic hot water production.
-
Page 4: Technical Characteristics
1.2 TECHNICAL CHARACTERISTICS Supply Voltage: 230 Vac Pumps with one inch fittings, three speeds, centre distance of 130 mm Maximum operating temperature: 90 °C Power absorbed by each pump: 55 W Maximum operating pressure: 6 bar 3-way motorised diverter valve with fittings: G3/4"- male Heating hydraulic connection: Ø... -
Page 5: Switching On/Off
FDG ADJUSTABLE 3-THERMOSTAT ELECTRONIC CONTROL UNIT PROBE FLUX LINE PUMP VALVE LEV. 2 3 4 5 6 7 9 10 PROBE Thermo-cooker Probe: Temperature Range 0 – 100 °C FLUX Flow switch/Boiler - DHW Thermostat ON/OFF Consent INPUTS LEV. ON/OFF level switch PUMP System pump: Power supply 230 Vac... - Page 6 - AUX thermostat for gas boiler integration, solenoid valve control or other application - VALV thermostat to control diverter valve for domestic hot water Simply clicking the button P1 (MENU) you may scroll the set Thermostat values, signalled by the flashing associated PUMP / VALV / AUX LED To change it, go to the thermostat value that needs to be modified: - pressing button P2...
- Page 7 2 INSTALLATION GUIDE The appliance must be installed according to professional standard, following the instructions in this manual and in compliance with the laws and regulations of each country, by QUALIFIED PERSONNEL acting on behalf of Companies fit to assume full responsibility for the whole system. Before putting the thermo-cooker into service, it is mandatory to set up the connections of the heating system.
- Page 8 3 ACTIVATION AND MAINTENANCE Before installing the thermo-cooker, you must wash the pipes of the system it is connected to. The thermo-cooker could malfunction if the pipes are dirty inside. When the hydraulic installation and electric wiring have been set up, fill the system of the Thermo-cooker and of the Heating system with water.
