Summary of Contents for Sony PCGA-HDX10
- Page 1 PCGA-HDX10 PCGA-HDX10 (U/C) SERVICE MANUAL US Model Canadian Model 10 GB Hard Disk Drive English 99XXXXX-1 Sony Corporation Printed in XXXXX Information Technology Company © 1999. X 9-872-026-11 VAIO CUSTOMER LINK (JAPAN) 9-872-026-11 —XX—...
- Page 2 Sony and VAIO are trademarks of Sony. Intel logo and Intel Inside logo are registered trademarks of Intel Corporation. CAUTION: Danger of explosion if battery is incorrectly replaced.
-
Page 3: Table Of Contents
(to 1-1) CHAPTER 2. SELF-DIAGNOSTICS 2-1. Note ......................2-1 2-2. Necessary Tools ..................2-1 2-3. Start-up of the Self-Diagnostics Program ..........2-1 (to 2-1) CHAPTER 3. EXPLODED VIEW AND PARTS LIST ........3-1 (to 3-1) — 3 — PCGA-HDX10 (U/C) -
Page 5: Chapter 1. Removal
CHAPTER 1. REMOVAL 1-1. HDD Cover Claws HDD Cover Claws Tapping (B 2X) (X5) 1-2. HDD (10GB), FPC (Bay HDD) FPC (Bay HDD) +Special Head Screws (M2X5) (X4) M3X4 (X2) M3X4 (X2) HDD (10GB) PCGA-HDX10 (U/C) (END) -
Page 7: Chapter 2. Self-Diagnostics
• To perform self-diagnosis, the operating system (OS) must be installed in the hard disk of the main unit. • When self-diagnosis is completed, the data on the subject (PCGA-HDX10) to be diagnosed will be erased. The data on the hard disk of the main unit, however, will not be erased. -
Page 9: Chapter 3. Exploded View And Parts List
4-642-777-01 HD BRACKET (A) A-8045-751-A HDD (10GB) ASSY (S) 4-643-543-01 HDD COVER 1-675-160-11 FPC (BAY HDD) 4-642-955-01 INSULATOR BAY FPC 4-642-229-11 TAPPING, 0 NUMBER SPECIAL HEAD 4-635-301-01 SCREW M3X4 4-644-546-01 FPC TAPE ACCESSORY *********** 3-867-282-02 MANUAL INSTRUCTION PCGA-HDX10 (U/C) (END)
