Summary of Contents for AAF COPPA 2
- Page 1 COPPA 2: INSTRUCTIONS FOR USE AND MAINTENANCE...
-
Page 2: Table Of Contents
CONTENTS Product components Cleaning features Cleaning technology Operator panel Display Air quality light indicator Cleaning and preventive maintenance Filter change Instructions Troubleshooting Technical data Electrical circuit diagram Notices Read the information in these operating instructions carefully and familiarize yourself with them. -
Page 3: Product Components
PRODUCT COMPONENTS Air quality light indicator (Di erent colours of light indicate di erent air quality) Operator panel Power switch Air intake Display panel (Digital PM2.5 concentration indicator, temperature, air humidity) Light sensor (The brightness of the operator panel adapts itself to the ambient brightness) Right-hand clip... -
Page 4: Cleaning Features
CLEANING FEATURES Highly effi cient cleaning of PM2.5 Cleaning technology particulate matter, smog, pollen and other harmful particles 1 – Prefi lter Filters contaminants larger than 20 µm, such • Formaldehyde removal as hair, skin particles or fi bres. • 3 fan speeds •... -
Page 5: Operator Panel
OPERATOR PANEL Power switch Connect the plug to the socket to enter Standby mode. The power switch takes you to Operation mode. When the device is in Operation mode, press the power switch to return to Standby mode. Rest mode When the device is in operation, turn the button until the Rest mode symbol lights up. -
Page 6: Display
OPERATOR PANEL Fan speed To set the fan speed, turn the button clockwise or anticlockwise. The indicator light shows the current fan speed. At low speed, one bar is displayed; at medium speed, 2 bars; at high speed, 3 bars. The indicators light up according to the level that has been set. -
Page 7: Cleaning And Preventive Maintenance
CLEANING AND PREVENTIVE MAINTENANCE The device must be disconnected from the Notice: If you switch the device off with the mains power supply before commencing power switch, the device merely switches preventive maintenance or cleaning work. to Standby mode. For this reason, unplug the mains •... - Page 8 NOTICES All notices are relevant to safety and must be Please do not use any components other observed as described below. The following than those approved by the manufacturer. notices are intended to ensure that the user Otherwise, the guarantee is voided in the uses the device correctly.
- Page 9 NOTICES Please do not insert your hands or foreign bodies into the air inlet and outlet. Please do not unplug the mains connector with wet hands. Please do not use the air purifi er in locations where hydrogen, natural gas, dimethyl methane and other fl...
- Page 10 NOTICES To move the device, it can either be pushed or held by both clips. Holding onto the air outlet to move the device can cause the air outlet or the device to fall down, potentially resulting in injuries. If the air purifi er causes interference to radio or television signals, please try one or more of the measures described below: •...
-
Page 11: Troubleshooting
TROUBLESHOOTING Problem Possible cause and solution • The device is not connected correctly; it must be connected again. Device does not start • Check whether the front panel is correctly installed. • The fi lter packaging has not been removed; remove the packaging and reinsert the fi... -
Page 12: Technical Data
TECHNICAL DATA Product name Time setting coppa 2 Child-lock Power supply rating 71 watts 350 x 341 x Rated voltage 220 V Dimensions (HxWxD) 750 mm Rated power input 71 watts net 9.5 kg / Weight Rated frequency 32 - 58 dB gross 11 kg Recommended fi... - Page 13 Filter Manufacture & Air Hygiene Solutions Manufactured in the UK... Delivered on time Service Division Production 5 Stratfi eld Park, Elettra Avenue, Waterlooville Head Offi ce Hampshire PO7 7XN Riverside House, Parrett Way, Bridgwater TA6 5LB T +44 (0) 1278 452277 E sales@jfi...
