- Page 1 OWNER’S MANUAL Instructions for Assembly, Testing, Operation, Servicing, and Storage DAKEN Sprayers: For outdoor use with agricultural and other liquids** SKU NUMBERS: D30SS,D60BS,D98BS SERIAL NUMBER:...
- Page 2 For example, spraying water or other liquids that are contaminated with residual pesticide may result in unforeseen hazards to plant or animal life. Any questions, comments or problems call Baclow Enterprises Pty Ltd (Authorised DAKEN Representative) on (03) 7037 6130.
-
Page 3: Table Of Contents
DAKEN SPRAYERS TABLE OF CONTENTS Intended Use ..............................4 Summary of Important Safety Information ....................5 During Assembly During Operation General Chemical Safety Chemical Application Safety ATV Vehicle Handling Safety Chemical Accident Procedures Warning Label Location............................. 7 Component Inventory Unpacking................................. 8 Unpacking the Manual Bag.......................... -
Page 4: Intended Use
OWNER’S MANUAL INTENDED USE The sprayer is intended for use in spraying agricultural pesticides and other non-flammable liquids. SPRAYING PESTICIDES: Pesticides are hazardous chemicals that must be handled with caution as directed throughout this manual and on the pesticide label. The sprayer is intended for use in spraying pesticides in liquid form only. -
Page 5: Summary Of Important Safety Information
DAKEN SPRAYERS SUMMARY OF IMPORTANT SAFETY INFORMATION WARNING Read and understand this owner’s manual completely before using the sprayer. Read each chemical label’s instructions before handling the chemical. Improper use of the sprayer or handling of chemicals could result in serious injury or illness for the operator or nearby persons/animals, or cause damage to the environment. -
Page 6: Atv Vehicle Handling Safety
OWNER’S MANUAL SUMMARY OF IMPORTANT INFORMATION During Spraying • DO NOT OVER-APPLY pesticide. Apply at rate recommended by chemical manufacturer. Excess pesticide can be dangerous to humans/animals, damage desirable plants, and contaminate soil and water sources. • DO NOT EAT, DRINK, SMOKE, RUB YOUR EYES, or TOUCH YOUR BARE SKIN while handling chemicals and spraying. •... -
Page 7: Warning Label Location
DAKEN SPRAYERS WARNING LABEL LOCATION WARNING READ and UNDERSTAND the Owner’s Manual completely before using this sprayer. Assemble, test, and use only in accordance with the Owner’s Manual instructions. READ and FOLLOW chemical label instructions. Pesticides are hazardous chemicals, which must be handled carefully. -
Page 8: Unpacking
OWNER’S MANUAL UNPACKING Closely inspect all content in the shipping carton. Note that some parts are shipped inside the tank. If you have missing or damaged components, please contact your point of purchase. Sprayer Manual Bag Spot Spray Gun Gun Hose (Qty 1) (Qty 1) SKU# D30SS - 792722... -
Page 9: Unpacking The Manual Bag
DAKEN SPRAYERS UNPACKING THE MANUAL BAG The following items are found in the D30SS manual bag. Lance Clip Drain Cap Rubber Washer Screw (Qty 2) (Qty 1) (Qty 1) (Qty 3) 778560 37680 5232 779779 Hose Guide Hose Clamp Tie Down Straps... -
Page 10: Assembly
OWNER’S MANUAL ASSEMBLY STEP ONE: ATTACH LANCE CLIPS TO TANK Fasten the two lance clips to the sprayer tank with screws. Lance clip Screw STEP TWO: ATTACH DRAIN CAP TO TANK 1. Press the rubber washer into the drain cap with your finger. 2. -
Page 11: Step Three: Attach Gun Hose To Pump
DAKEN SPRAYERS ASSEMBLY [continued] STEP THREE: ATTACH GUN HOSE TO PUMP 1. Slide hose clamp over one end of the gun hose. 2. Push the hose onto the pump hose barb. 3. Slide the hose clamp over the hose barb. -
Page 12: Step Five: Attach Gun Hose To Spray Gun
OWNER’S MANUAL ASSEMBLY [continued] STEP FIVE: ATTACH GUN HOSE TO SPRAY GUN 1. Slide hose clamp over the end of the gun hose. 2. Push the hose onto the gun hose barb. 3. Slide the hose clamp over the hose barb. 4. -
Page 13: Step Six: Unpack And Inspect Parts Fromd60Ss Andd98Sskit Bag
DAKEN SPRAYERS ASSEMBLY STEP SIX: UNPACK AND INSPECT PARTS FROMD60SS ANDD98SSKIT BAGS Broadcast Lance (Qty 1) 792670 60 cm Hose 10-24 x ½” (Qty1) Coarse Thread Screw 792744 (Qty 2) 82059 Broadcast Bracket Broadcast Nozzle Hose Clamp Broadcast Fitting (Qty 1) -
Page 14: Step Eight: Finish Broadcast Kit Assembly
OWNER’S MANUAL ASSEMBLY STEP EIGHT: FINISH BROADCAST KIT ASSEMBLY Push broadcast lance into broadcast bracket. Note orientation. Install hose barb into open port on pump. Hand tighten, then one-half turn with a wrench. Connect 60 cm hose from pump to broadcast lance using two hose clamps. Follow hose clamp instructions below. Thread broadcast nozzle hand tight onto the end of the lance. -
Page 15: Step Ten: Connect Remote Switch To Vehicle Battery
DAKEN SPRAYERS ASSEMBLY [continued] STEP TEN: CONNECT REMOTE SWITCH TO VEHICLE BATTERY WARNING Batteries are hazardous because they contain caustic acid, can emit explosive gases, and can cause electric shock. Caution must be exercised when making connections to a battery to avoid shock and contact with the acid, and to prevent any sparking that could lead to an explosion. -
Page 16: Step Eleven: Check And Test Completed Assembly
OWNER’S MANUAL ASSEMBLY [continued] 6. Disconnect after AFTER EACH USE, disconnect power to the sprayer by disconnecting the sprayer’s pump cord from the remote switch – the remote switch may remain connected to the battery. NOTE: It is important to disconnect power to the sprayer when not in use for safety reasons. ALWAYS verify that the power has been disconnected or the remote switch is in the OFF position before adding chemicals or servicing. -
Page 17: Machine Components
DAKEN SPRAYERS MACHINE COMPONENTS: SKU# D30SS 1. Hose Wrap. The hose wrap is built into the tank and provides a storage location for the gun hose 2. Gun Hose. The gun hose transfers chemical from the pump to the spray gun. - Page 18 OWNER’S MANUAL MACHINE COMPONENTS: SKU#D60BS & D98BS 1. Hose Wrap. The built-in hose wrap provides a storage location for the gun hose on the tank. 2. Gun Hose. The 4.57 meter gun hose transfers chemical from the pump to the spray gun. 3.
-
Page 19: Important Safety Information - Operation
DAKEN SPRAYERS OPERATION - IMPORTANT SAFETY INFORMATION Now that you have completed and tested your assembly, there is some important safety and health information you need to know with regard to handling and spraying chemicals, as well as vehicle handling with the sprayer attached. -
Page 20: Chemical Application Safety
OWNER’S MANUAL OPERATION - IMPORTANT SAFETY INFORMATION [continued] CHEMICAL APPLICATION SAFETY: WARNING Caution must be used when spraying chemicals to avoid unsafe exposure to humans and the environment. Heed the warnings below and follow all instructions carefully. Before Spraying • Sprayer prep. -
Page 21: Atv Vehicle Handling Safety
DAKEN SPRAYERS OPERATION - IMPORTANT SAFETY INFORMATION [continued] ATV VEHICLE HANDLING SAFETY WARNING Serious injury can occur if the ATV on which the sprayer is mounted is driven unsafely. • Driver age. You must be 16 years of age or older to operate the ATV with the sprayer attached. - Page 22 OWNER’S MANUAL OPERATION - IMPORTANT SAFETY INFORMATION [continued] Poisoning by In case of poisoning from ingestion or inhalation: ingestion or IF THE VICTIM HAS COLLAPSED OR IS NOT BREATHING, CALL 000. Otherwise: inhalation If you are the victim, immediately seek assistance from nearby personnel because you may become incapacitated.
-
Page 23: Preparing The Sprayer For Each Use
DAKEN SPRAYERS OPERATION - PREPARING THE SPRAYER FOR EACH USE If the sprayer has been used previously, it must be prepared BEFORE EACH SUBSEQUENT USE. WARNING Read instructions below carefully for inspecting and preparing the sprayer. Damaged or clogged equipment could result in leaks or uncontrolled spray. -
Page 24: Step One: Assess Wind Conditions And Clear Work Area
OWNER’S MANUAL OPERATION - USING THE SPRAYER STEP ONE: ASSESS WIND CONDITIONS AND CLEAR WORK AREA Before you decide to spray, you must determine whether wind conditions are suitable. You must also restrict access to the work area to ensure the safety of bystanders. WARNING Do not spray if wind speeds are greater than 6.45 KM/H or if there are bystanders in the intended spray area. - Page 25 DAKEN SPRAYERS OPERATION - USING THE SPRAYER [continued] 6. Ensure tank Ensure tank is flushed of all chemicals from prior uses. flushed Chemicals can interact dangerously when mixed, and residue chemicals are also a health hazard. 7. Check drain cap Before filling tank, ensure drain cap is securely tightened.
-
Page 26: Step Three: Operate The Sprayer
OWNER’S MANUAL OPERATION - USING THE SPRAYER [continued] **ATTENTION** SKU# D30SS continue with Step 3.1 SKU#D60SS andD98SScontinue with Step 3.2 STEP 3.1: OPERATE THE SPRAYER (SKU# D30SS) WARNING ALWAYS wear personal protective equipment as directed on the chemical label when spraying. Long pants and sleeves, chemical-resistant gloves, and eye protection are strongly recommended. -
Page 27: Step 3.2 Modelsd60Ss Andd98Ss
DAKEN SPRAYERS OPERATION - USING THE SPRAYER [continued] **ATTENTION** SKU# D30SS continue with Step 3.1 SKU#D60SS andD98SScontinue with Step 3.2 STEP 3.2: OPERATE THE SPRAYER (SKU#D60BS & D98BS) WARNING ALWAYS wear personal protective equipment as directed on the chemical label when spraying. - Page 28 OWNER’S MANUAL OPERATION - IMPORTANT SAFETY INFORMATION [continued] 7. Operate a) Move broadcast lance into the broadcast position broadcast Ensure power to the pump is off, then lift the broadcast lance out of its stored position and click the spraying system lance into its broadcast position.
- Page 29 DAKEN SPRAYERS OPERATION - IMPORTANT SAFETY INFORMATION [continued] D) Begin to spray Turn the power ON, turn broadcast lance valve to the on position. On position e) Ensure uniform coverage To ensure proper coverage, overlap the ends of the spray pattern 30 cm.
-
Page 30: Step Four: Clean Sprayer And Decontaminate After Use
OWNER’S MANUAL OPERATION - USING THE SPRAYER [continued] STEP FOUR: CLEAN THE SPRAYER AND DECONTAMINATE AFTER USE When done using the sprayer, it is important to clean the sprayer and decontaminate yourself. Do not store the sprayer with chemicals in the tank, as it is unsafe and could also result in damage to the equipment. WARNING Cleanup and decontamination procedures must be followed after each use. -
Page 31: Storage
DAKEN SPRAYERS STORAGE Prepare the sprayer for end-of-season storage by running RV antifreeze through the system. This will keep internal parts lubricated, protect against corrosion, and keep the unit from freezing. CAUTION The sprayer will be damaged if it freezes. -
Page 32: Troubleshooting
OWNER’S MANUAL TROUBLESHOOTING WARNING Before troubleshooting or attempting to service, read the following safety rules to avoid accidental exposure to chemical and also risk of electric shock. Note: A reserve, clean container capable of holding at least 38 Litres (SKU # D30SS) or 60 Litres (SKU #D60SS) or 98 Litres (SKU # D98SS) should be kept for use when the sprayer tank needs to be emptied temporarily for repairs. -
Page 33: Specifications
DAKEN SPRAYERS SPECIFICATIONS Electrical System Requirements Electrical connection 12 VDC Amp draw from pump SKU#D60BS,D98BS SKU 8.0 Amps (max) #D30SS 4.0 Amps (max) Sprayer Specifications Maximum GPM SKU#D60BS,D98BS SKU 8.3 Litres/min. #D30SS 3.8 Litres/min. Maximum Pressure SKU #D60BS,D98BS SKU 70 PSI (4.8 Bar) #D30SS 40 PSI (2.76 Bar) -
Page 34: Parts Breakdown - Exploded View
OWNER’S MANUAL EXPLODED VIEW - D30SS,D60BS,D98BS- REV A Part# Description Model Part# Description Model Ref# Ref# 792722 D30SS 5232 Rubber washer Spray gun 792723 D60BS, D98BS 792769 38 Litre tank D30SS 792707 D30SS, 792770 60 Litre tank D60BS Hose clamp... -
Page 35: D3Bp Pump Parts Breakdown - Exploded View
DAKEN SPRAYERS EXPLODED VIEW & PARTS LIST - D3BP - REV A Ref# Part# Description 791634 Base plate assembly 790576 Diaphragm assembly 790584 Valve plate assembly 790589 Upper housing assembly 792672 Pressure switch assembly 788429 Quick connect clip D3BP Complete pump head assembly... -
Page 36: D8Bp Pump Parts Breakdown - Exploded View
OWNER’S MANUAL EXPLODED VIEW & PARTS LIST - D8BP - REV A FIG05281 Ref# Part# Description 788028 Base plate assembly 786981 Diaphragm assembly 778279 Valve plate assembly 792664 Quick connect clip 792675 Upper housing assembly 792673 Pressure switch assembly A2272 Complete pump head assembly 787380 Replacement fuse... -
Page 37: Accessories
DAKEN SPRAYERS ACCESSORIES D30SS D60BS D98BS Pressure regulator/agitator kit - 37 -... -
Page 38: Appendix A: Broadcast Spray Calibration Tables
OWNER’S MANUAL APPENDIX A - BROADCAST SPRAY CALIBRATION TABLES Below are some guidelines to help you calibrate your broadcast sprayer. This is a very important step in operating the broadcast sprayer such that too much or too little chemical may be applied. Using Table 1, find a table that corresponds with the chemical manufacturer’s suggested application rate (litres per hectare, litres per 100 sq.m or litres per 10 sq.m). -
Page 39: Limited Warranty
DAKEN SPRAYERS LIMITED WARRANTY WARRANTY POLICY This product is covered by a 2 year manufactures warranty, from the date of purchase. The warranty covers manufacturer’s defects in material and workmanship. The warranty does not cover malfunctions due to misuse or due to failure to follow the instructions in the instruction manual. Any alterations to the product are to be performed by an approved service agent.
