- Page 1 OWNER’S MANUAL Instructions for Assembly, Testing, Operation, Servicing, and Storage DAKEN Sprayers: For outdoor use with agricultural and other liquids** SKU NUMBERS: D200SS SERIAL NUMBER:...
- Page 2 OWNER’S MANUAL WARNING READ and UNDERSTAND the Owner’s Manual completely before using this sprayer. Assemble, test, and use only in accordance with the Owner’s Manual instructions. READ and FOLLOW chemical label instructions. Pesticides are hazardous chemicals. KNOW emergency procedures BEFORE handling chemicals. Sprayer leaks, bodily chemical contact, poisoning, and spills require immediate response.
-
Page 3: Table Of Contents
DAKEN SPRAYERS TABLE OF CONTENTS Intended Use ............................4 Summary of Important Safety Information.....................5 During Assembly ..........................5 During Operation ..........................5 • General Chemical Safety • Chemical Application Safety • UTV Vehicle Handling Safety • Chemical Accident Procedures Warning Label Location ...........................8... -
Page 4: Intended Use
OWNER’S MANUAL INTENDED USE The sprayer is intended for use in spraying agricultural pesticides and other non-flammable liquids. SPRAYING PESTICIDES: Pesticides are hazardous chemicals that must be handled with caution as directed throughout this manual and on the pesticide label. Pesticides are regulated by the United States Environmental Protection Agency (EPA) and defined as: Any substance or mixture of substances intended for preventing, destroying, repelling, or mitigating any pest. -
Page 5: Summary Of Important Safety Information
DAKEN SPRAYERS SUMMARY OF IMPORTANT SAFETY INFORMATION WARNING Read and understand this owner’s manual completely before using the sprayer. Read each chemical label’s instructions before handling the chemical. Improper use of the sprayer or handling of chemicals could result in serious injury or illness for the operator or nearby persons/animals, or cause damage to the environment. -
Page 6: Utv Vehicle Handling Safety
OWNER’S MANUAL SUMMARY OF IMPORTANT INFORMATION During Spraying • DO NOT OVER-APPLY pesticide. Apply at rate recommended by chemical manufacturer. Excess pesticide can be dangerous to humans/animals, damage desirable plants, and contaminate soil and water sources. • DO NOT EAT, DRINK, SMOKE, RUB YOUR EYES, or TOUCH YOUR BARE SKIN while handling chemicals and spraying. •... -
Page 7: Warning Label Location
DAKEN SPRAYERS WARNING LABEL LOCATION WARNING READ and UNDERSTAND the Owner’s Manual completely before using this sprayer. Assemble, test, and use only in accordance with the Owner’s Manual instructions. READ and FOLLOW chemical label instructions. Pesticides are hazardous chemicals, which must be handled carefully. -
Page 8: Unpacking
OWNER’S MANUAL UNPACKING Closely inspect all content in the shipping carton. Note that some parts are shipped inside the tank. • If you have damaged components: Contact the freight company that delivered the unit and file a claim. • If you have missing components: Contact your vendor. Sprayer Spray Gun Part # 792723... -
Page 9: Unpacking The Manual Bag
DAKEN SPRAYERS UNPACKING THE MANUAL BAG The following items are found in the 200L5 manual bag. 15mm Screw Part # 82658 (Qty 3) 1/2” Hose Lance Clip Hose Guide Clamp Part # Part # 798457 Part # 784564 792708 (Qty 2) -
Page 10: Assembly
OWNER’S MANUAL ASSEMBLY STEP ONE: ATTACH LANCE CLIPS TO TANK Fasten the (2) lance clips to the sprayer tank using (2) self-tapping screws. Lance clip Screw STEP TWO: ATTACH DRAIN PLUG TO TANK 1. Press the O-ring onto the drain plug with your finger. 2. -
Page 11: Step Three: Attach Gun Hose To Pump
DAKEN SPRAYERS ASSEMBLY [continued] STEP THREE: ATTACH GUN HOSE TO PUMP 1. Slide (1) hose clamp over one end of the gun hose. 2. Push the hose onto the pump hose barb. 3. Slide the hose clamp over the hose barb. -
Page 12: Step Five: Attach Gun Hose To Spray Gun
OWNER’S MANUAL ASSEMBLY [continued] STEP FIVE: ATTACH GUN HOSE TO SPRAY GUN 1. Slide (1) hose clamp over the end of the gun hose. 2. Push the hose onto the gun hose barb. 3. Slide the hose clamp over the hose barb. 4. -
Page 13: Step Seven: Connect Remote Switch To Vehicle Battery
DAKEN SPRAYERS ASSEMBLY [continued] STEP SEVEN: CONNECT REMOTE SWITCH TO VEHICLE BATTERY WARNING Batteries are hazardous because they contain caustic acid, can emit explosive gases, and can cause electric shock. Caution must be exercised when making connections to a battery to avoid shock and contact with the acid, and to prevent any sparking that could lead to an explosion. -
Page 14: Step Eight: Check And Test Completed Assembly
OWNER’S MANUAL ASSEMBLY [continued] 5. Disconnect after AFTER EACH USE, disconnect power to the sprayer by disconnecting the sprayer’s pump cord from the remote switch – the remote switch may remain connected to the battery. NOTE: It is important to disconnect power to the sprayer when not in use for safety reasons. ALWAYS verify that the power has been disconnected or the remote switch is in the OFF position before adding chemicals or servicing. -
Page 15: Machine Components
DAKEN SPRAYERS MACHINE COMPONENTS 1. Sprayer Tank. The sprayer tank holds the water. 2. Fill Cap. The fill cap has a vent to allow air to enter the tank as the chemical is dispensed. 3. Remote Switch. The remote switch connects the battery to the pump power cord and allows the operator to turn the sprayer pump on and off. - Page 16 DAKEN SPRAYERS OPERATION - IMPORTANT SAFETY INFORMATION Now that you have completed and tested your assembly, there is some important safety and health information you need to know with regard to handling and spraying chemicals, as well as vehicle handling with the sprayer attached.
- Page 17 OWNER’S MANUAL OPERATION - IMPORTANT SAFETY INFORMATION [continued] CHEMICAL APPLICATION SAFETY: WARNING Caution must be used when spraying chemicals to avoid unsafe exposure to humans and the environment. Heed the warnings below and follow all instructions carefully. Before Spraying • Sprayer prep.
- Page 18 DAKEN SPRAYERS OPERATION - IMPORTANT SAFETY INFORMATION [continued] TRANSPORTING SAFETY: WARNING Serious injury can occur if the vehicle on which the sprayer is mounted is driven unsafely. • Read vehicle instructions. Review safety instructions in your vehicle manual with regard to carrying heavy cargo loads.
- Page 19 OWNER’S MANUAL OPERATION - IMPORTANT SAFETY INFORMATION [continued] Poisoning by In case of poisoning from ingestion or inhalation: ingestion or IF THE VICTIM HAS COLLAPSED OR IS NOT BREATHING, CALL 000. Otherwise: inhalation If you are the victim, immediately seek assistance from nearby personnel because you may become incapacitated.
-
Page 20: Preparing The Sprayer For Each Use
DAKEN SPRAYERS OPERATION - PREPARING THE SPRAYER FOR EACH USE If the sprayer has been used previously, it must be prepared BEFORE EACH SUBSEQUENT USE. WARNING Read instructions below carefully for inspecting and preparing the sprayer. Damaged or clogged equipment could result in leaks or uncontrolled spray. -
Page 21: Step One: Assess Wind Conditions And Clear Work Area
OWNER’S MANUAL OPERATION - USING THE SPRAYER STEP ONE: ASSESS WIND CONDITIONS AND CLEAR WORK AREA Before you decide to spray, you must determine whether wind conditions are suitable. You must also restrict access to the work area to ensure the safety of bystanders. WARNING Do not spray if wind speeds are greater than 6.4 KM/H or if there are bystanders in the intended spray area. - Page 22 DAKEN SPRAYERS OPERATION - USING THE SPRAYER [continued] 6. Ensure tank Ensure tank is flushed of all chemicals from prior uses. flushed - Chemicals can interact dangerously when mixed, and residue chemicals are also a health hazard. 7. Fill tank Add pesticide to tank through fill cap: a) Confirm the chemical/water dilution ratios specified on the chemical label.
- Page 23 OWNER’S MANUAL OPERATION - USING THE SPRAYER [continued] STEP 3: OPERATE THE SPRAYER (SKU# STA38SS) WARNING ALWAYS wear personal protective equipment as directed on the chemical label when spraying. Long pants and sleeves, chemical-resistant gloves, and eye protection are strongly recommended. Additional protective gear may be required depending on the particular pesticide.
-
Page 24: Step Four: Clean Sprayer And Decontaminate After Use
OWNER’S MANUAL OPERATION - USING THE SPRAYER [continued] STEP FOUR: CLEAN THE SPRAYER AND DECONTAMINATE AFTER USE When done using the sprayer, it is important to clean the sprayer and decontaminate yourself. Do not store the sprayer with chemicals in the tank, as it is unsafe and could also result in damage to the equipment. WARNING Cleanup and decontamination procedures must be followed after each use. -
Page 25: Storage
DAKEN SPRAYERS STORAGE Prepare the sprayer for end-of-season storage by running RV antifreeze through the system. This will keep internal parts lubricated, protect against corrosion, and keep the unit from freezing. CAUTION The sprayer will be damaged if it freezes. -
Page 26: Troubleshooting
OWNER’S MANUAL TROUBLESHOOTING WARNING Before troubleshooting or attempting to service, read the following safety rules to avoid accidental exposure to chemical and also risk of electric shock. Note: A reserve, clean container capable of holding at least 200 Litres should be kept for use when the sprayer tank needs to be emptied temporarily for repairs. -
Page 27: Specifications
DAKEN SPRAYERS SPECIFICATIONS Electrical System Requirements Electrical connection 12 VDC Amp draw from pump 10.5 Amps (max) Sprayer Specifications Maximum GPM (NU3062Q) 3.0GPM (11.4 Litres/min) 60 PSI (4.8 Bar) Maximum Pressure (NU3062Q) Tank Maximum Capacity 53 Gallons (200 Litres) Overall Dimensions (L X W X H) 39.5”... - Page 28 OWNER’S MANUAL EXPLODED VIEW – D200SS Ref# Part# Description 792708 Hose clamp 1/2” 792723 Spray gun 82658 15mm self-tapping screw 798457 Lance clip 799319 200 Litre tank 792701 Fill cap w/tether 787199 Inlet fitting 792706 Inlet hose 789811 Suction tube...
- Page 29 DAKEN SPRAYERS EXPLODED VIEW – D11BP NU3062Q Ref# Part# Description 787996 Base plate assembly 788017 Diaphragm assembly 788015 Valve plate assembly 792664 Quick connect clip 792677 Upper housing assembly 792674 Pressure switch assembly A2683062 Complete pump head assembly 787381 Replacement fuse...
-
Page 30: Limited Warranty
Please fill in the following information and have it on hand when you call in a warranty claim. Customer Number: Date of Purchase: DAKEN Serial Number: Item Number: Sales & Product Enquiries: Call us on (Toll Free) 1800 648 384, or email sales@clarkfarmequipment.com.au Operating 8:30am - 5pm...
