- Page 1 USER MANUAL Part List and Assembly Instructions Including: 1.75mm Bowden Setup Direct Drive Setup Bowden Setup Additional Part Fan Nozzle Changing...
- Page 2 Small Phillips Screwdriver 0.9mm and 2mm 7mm and 11mm Small Parts Bowden Coupler Bowden Clip Direct Drive Plug PTFE Tubing Pico Hybrid Assembly 1.75mm and 3.00mm 2x4mm and 3x4mm Fan Voltage Regulator Voltage Regulator Wiring Harnesses Heat Break Cooling Fan Thermistor...
- Page 3 IMPORTANT NOTES Wire Length Shortened Wire Length Cutoff Connected Terminals - Sizing of parts may vary across illustrations to enhance relevant details. - Wiring length is not reflective of the actual wire length and is shortened for simplicity. - Previous assembly steps may not be visible for each stage of setup. Step 1 Using the 2mm Allen wrench, thread the 1.75mm Bowden coupler into the top of the groove mount.
- Page 4 When inserting the filament guide tube, you may feel resistance near the top of the coupler. Keep pushing until the tube bottoms out. Please refer to the wiring diagrams on the User Guides page of the Metaform website for wiring the hotend to the printer.
