- Page 1 Radio-controlled vibration detector Installation Guide FU5125...
- Page 2 Fig. 1 Fig. 2...
- Page 3 Preface Dear Customer, Thank you for purchasing this radio-controlled vibration detector. You made the right decision in choosing this state-of-the-art technology, which complies with the current standards of domestic and European regulations. The CE has been proven and all related certifications are available from the manufacturer upon request.
- Page 4 Fig. 1 Number Name Screw Battery Potentiometer Tamper protection, lid LED – calibration mode Tamper protection, wall Jumper contacts A–D Do NOT install the detector: • Near the floor • Near large metal structures • Within 1 metre from power or gas lines •...
- Page 5 3. Fig. 1, Pos. 1: Positions of screws for fixing the housing 3.1. Hold the bottom of the housing at a suitable position. 3.2. Mark the screw positions for fixing. 4. Fix the housing rear to the marked position with two screws. The rear of the housing must lie flat on the surface so that the wall removal contact is closed.
- Page 6 Setting the vibration detector There are various options for setting the vibration detector. Jumper A Sensitivity: The detector can be set to high or low sensitivity with jumper A. high You can set the sensitivity range with the potentiometer (Fig.1, 4). Jumper B XXX: Multiple vibration mode If XXX is activated, the vibration detector sends an...
- Page 7 Adjusting sensitivity Connect jumper C. Note: If the detector battery is almost empty, the LED flashes continuously for calibration mode (Fig.1, 6). In this case, replace the battery. 1. Turn the potentiometer (Fig.1, 4) anticlockwise until it stops. The detector is now at the lowest sensitivity level. 2.
- Page 8 Changing the battery 1. Switch your radio alarm equipment to installer mode. 2. Open the housing of the vibration detector. 3. Replace the battery with one of the same type (CR 2 Lithium, 3V). Closing the case Place the cover on the base and fix it with the screw. Technical Data Power supply: 3V, CR2 Li/MnO2...
