Technical Specifications; Jack Operating Instructions - Simplex SER10 Operational Manual

2.0 TECHNICAL SPECIFICATIONS

E
Left - Side View
Model Travel Screw
Length Diameter
(mm) (mm)
SER10 356 51
SER20 508 51
SER30 660 51
SER40 965 51

3.0 JACK OPERATING INSTRUCTIONS

Position load binder so it can be operated from the ground or in a manner where your footing is secure. Make sure that the jack is rigidly and se-
curely attached at the eyelet connection (1). The Ratchet Load Binder pawl has two positions for expansion or pulling application.
DANGER: These jacks are not equipped with safety stops. Do not exceed the maximum screw extensions shown in the table
(section 2.0). Exceeding travel length could cause thread failure and a personal injury hazard.
WARNING: Before exerting handle effort on the lever bar, check to make certain that the pawl is engaged into the full tooth depth of the
ratchet wheel.
G
A B
A B C
Eye to Eye Barrel Left/Right
Width Screw
Length
585 939 457
737 1244 610
889 1548 762
1194 2159 1067
Front View
1
••• 3 •••
F
C
D
Dimensions (mm)
D E
Left/Right Ratchet
Screw Eye Socket
Thickness Length
279 48
356 48
432 48
584 48
Right - Side View
H
F G
Inner Radius
Diameter
Left/Right
Screw Eye
19 33 44
19 33 44
19 33 44
19 33 44
1
E
Weight
(kg)
H
25,9
29,9
33,6
41,7
