Summary of Contents for Stanton T.12O
-
Page 1: Operating Instructions
FULL MANUAL OPERATING INSTRUCTIONS DIRECT DRIVE TURNTABLE T.12O WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. -
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. Read these Instructions – All the safety and operating instructions should be read before this product is operated. 2. Keep these Instructions – The safety and operating instructions should be retained for future reference. 3. Heed all Warnings – All warnings on the appliance and in the operating instructions should be adhered to. 4. - Page 3 IMPORTANT SAFETY INSTRUCTIONS 21. Lightning – For added protection for this product during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the product due to lightning and power-line surges.
- Page 4 For your convenience, some of these products can be purchased already mounted and pre-adjusted from your local Stanton dealer. If you are using these 1/2” mounted products with a headshell in a mobile application or you are doing heavy scratching, May want to use an extra shell weight. The Master series of products (Trackmaster, Groovemaster, etc.) are designed with their own mounting that eliminates the need for...
-
Page 5: Part Names And Functions
TONE ARM AND CARTRIDGE SETTINGS The third adjustment is the needle (or stylus) pressure. Start with the cartridge-headshell assembly mounted into the tone arm. Remove any needle protectors provided. With tone arm free, adjust the tone arm counterweight by rotating the rear section until the tone arm floats in a balanced condition above the record or mat. - Page 6 PART NAMES AND FUNCTIONS 5) STROBE DOTS The dots around the edge of the platter are used in conjunction with the light located inside the motor ON/OFF switch. While the platter is in rotation, the dots help to indicate the speed of rotation. The speed is lower than the displayed speed (33,45,78) when the dots are flowing to the right.
-
Page 7: Specifications
PART NAMES AND FUNCTIONS 20) EXTRA STYLUS HOLDER Place extra headshells here. 21 22 21) PHONO/LINE OUTPUT L & R This is the standard analog output (RCA jacks) which can be connected either to a phono or line input on any DJ mixer, depending on the setting of the phono / line selector. -
Page 8: Tonearm Section
SPECIFICATIONS TONEARM SECTION: Type Effective Arm Length Tracking Error Angle Applicable Cartridge Weight High of Cue (First Track) Descend of Cue AUDIO SECTION: Preamp Frequency Response Preamp Distortion Preamp Noise Floor GENERAL SECTION: Power Supply Power Consumption Dimensions Weight Static balanced straight shaped tone arm with cardan’ s suspension 194mm Less than 3 degree 13~18g... -
Page 9: Warranty
Any returns to a non-authorized dealer or to an authorized Stanton dealer not in the same country as the merchandise was intended to be sold or as set forth above will void this warranty. - Page 10 c u t a l o n g d o t t e d l i n e...
- Page 11 Stanton Magnetics, Inc. 3000 SW 42nd Street Hollywood, FL 33312 U.S.A. PLACE STAMP HERE...
