- Page 1 PPK-3 KIT Perimeter Protection Kit DocRef# 0100601 PPK-3-Kit User Guide Revised 2016-8-2...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Section 1: PPK 3A Receiver Module A. Introduction Page 3 B. Product View C. Accessories Set Up Page 4 A. Accessories B. Power On/Off Alarm and Playback Page 4 A. Alarm B. Playback III. PPK-3A Troubleshooting Page 5 A. -
Page 3: Ppk 3A Receiver Module
The PPK-3A is a receiver module that will provide the operator with notification of a perimeter breach. IMPORTANT: The PPK-3A Receiver will only receive alarms from the PPK’s IR-301’s sensors and not with other standard Intellicam sensors. B. Product View 1. Power Slide Switch 2. -
Page 4: Accessories
I. PPK-3A Set Up A. Accessories 1. Batteries: Remove all 4 screws (2 in each end panel), remove bottom access panel, and slide cover down. Insert 3 each ‘AAA’ batteries. 2. Internal Dip Switches: Above the battery clips are two DIP switches to manually turn off the LEDs or the vibrator. -
Page 5: Ppk-3A Troubleshooting
III. PPK-3A Troubleshooting A. Low Batteries 1. System Reset: When the batteries get critically low, the system may reset and lose the previously stored Sensor ID Number. B. Limited RF Signal Reception 1. SMA Antenna, or other antennas, may not be securely attached to SMA connector. -
Page 6: Introduction
IR-301 Passive Infrared Sensors A. Introduction: The IR-301 Passive Infrared Sensor is capable of accurately detecting the movement of human and vehicular targets. The IR-301 is packaged in a rugged aluminum tube with integrated sensor, transmitter, and battery holder. The IR-301 is a non-programmable sensor designed for quick deployments with fixed Sensor ID’s of 1 through 4 and a fixed Sensor Sensitivity of “3”. - Page 7 Battery Compartment: The IR-301’s batteries are self-contained. Slide the rubber boot off the back of the sensor and replace the batteries with 2 each CR1225 Lithium Batteries. These should power the IR-301 for approximately 2-3 weeks depending on the number of sensor activations. When not using the sensor, you can disconnect the power by slipping a small piece of plastic between the + lead and the top battery.
-
Page 8: Using Passive Infrared Sensors
Chapter 3 - Using Passive Infrared Sensors Using Passive Infrared Sensors Narrow Beam Passive Infrared sensing offers many advantages over other sensor types. A. Introduction: This technology is the most advanced when used in an outdoor environment. Its versatility, small size, long range, precise targeting, and target classifying allow it to be used reliably in many diverse applications. -
Page 9: Infrared Signal
Chapter 6 - Using Passive Infrared Sensors B. Infrared Signal: The optimum signal produced by a human is at a distance of 20 feet for the IR-301, with the person walking at a casual pace (3 ft./sec). This is strictly a function of the sensor’s optics, which is fixed and determines the devices beam spread (4 ft. -
Page 10: Appendix
Appendix: A. Technical Specifications IR-301 Specifications: Power 2, CR1225 3 volt Lithium Operating 14 F to 122 F (-10 C to +50 C) Temperature Operational 21 days; based upon sensor activations Sensing Method Dual Element Pyroelectric Detector Max. Detection Range Human Targets: 30 feet @ 80 deg. -
Page 11: Rf Interference
WARNING: This device operates under Part 15 of the FCC Rules. Any modification not expressly approved by IntelliCam, LLC may void the warranty and the user’s authority to operate this device! C. Contact Information:...
