Realistic HTX-100 Service Manual page 38

REF.
DESCRIPTION
RS MFR'S
NO.
PART NO. PART NO.
S608
Push
SW-629 BSWY0629001
S609
-Not Used-
S610 Push
SW-629 BSWY0629001
S611 Tact
SW-560 SKHJAB BSWY0560001
S612 Tact
SW-560 SKHJAB BSWY0560001
S613 Rotary
SR-409 EC-S-06 BSRY0409001
PLL PCB ASS'V
REF.
DESCRIPTION
RS MFR'S
NO.
PART NO. PART NO.
ASSEMBLV,PCB,PLL AT553ZTBEC
Consists of the following:
PC BOARD
8301
PC BOARD PLL PB-133AA BPBY0133AAZ
CAPACITORS
The following codes indicate variations of capacitors against temperatures;
VA= ±5o/a, VB= ±10o/o, VD =+20-30o/o, VE =+20-50o/o (-25'V +85°C), ZF =+30-BOo/o
(-10
rv
+70°C), CH = 0±60ppmrC, RH = 220ppmrC±60ppmrC, TH = -470ppmrC±60ppmrC,
SL = +350ppmrC
rv
-1000ppmrC, UJ = -750ppmrC ± 120ppm/oC
C301 Electrolytic 4. 7 JlF 50 V +80/-20o/o BCEL814790Z
C302 Electrolytic 4. 7 JlF 50 V +B0/-20o/o BCEL814790Z
C303 Electrolytic 4. 7 f,lF 50 V +80/-20o/o BCEL814790Z
C304 Ceramic 39 pF 50 V ± 10o/o SL BCCG813905Z
C305 Ceramic
0.001 JlF 50 V ±20o/o YD(D)
BCKD811 026Z
C306 Ceramic 5 pF 50 V ± 0.25o/o CH BCCC815091 Z
C307 Electrolytic 4. 7 #F 25 V ± 20% C-095 BCER514796Z
C308 Ceramic 10 pF 50 V ±0.5o/o CH BCCC811 002Z
C309 Ceramic 0.01 #F 50 V +80/-20o/o YF(F) BCKG811 030Z
C310 -Not Used-
C311 Ceramic 5 pF 50 V ± 0.25o/o CH BCCC815091 Z
C312 Ceramic 33 pF 50 V ± 10o/o SL BCCG813305Z
C313 Ceramic 0.001 #F 50 V ± 20o/o YO( D) BCKD811 026Z
C314 Semi-conductor (SA) 0.047 JlF 25 V ± 10% BCGC514 735Z
C315 Electrolytic 1 f,lF 50 V +80/-20o/o BCEL811090Z
C316 Electrolytic 1 JlF 50 V +80/-20o/o BCEL811 090Z
C317 Semi-conductor (SA) 0.01 JlF 25 V ± 1 Oo/o BCGC511 035Z
C318 Ceramic 0.001 JlF 50 V ± 20o/o YO( D) BCKD811 026Z
C319 Ceramic 0.022 #F 25 V +80/-20o/o YF(F) BCKG512230Z
C320 -Not Used-
C321 Ceramic 0.001 JlF 50 V ± 20o/o YO( D) BCKD811 026Z
C322 Ceramic
0.001 #F 50 V ± 20o/o YO( D) BCKD811 026Z
C323 Ceramic 56 pF 50 V ± 10o/o SL BCCG815605Z
-39-
