- Page 1 Speco Technologies 200 New Highway Amityville, NY 11701 800-645-5516 www.specotech.com EZVR4 User’s Manual...
-
Page 2: Safety Precautions
Safety Precautions CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insulated dangerous Voltage within the product’s enclosure that may be of sufficient magnitude to constitute risk of electrical shock to persons. -
Page 3: About This Document
2. Several chips on the main board of the unit and hard disk drive inside the unit generate heat which must be properly discharged. Do not place any objects adjacent to the ventilation openings on the sides of the unit. 3. Put the EZVR4 in a well-ventilated place and do not put heat-generating objects on the unit. - Page 4 FCC Statement: WARNING This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received including interference that may cause undesired operation."...
-
Page 5: Installation
4. Put on a flat desk 6. Connect your monitor cable to the BNC connector labeled “Monitor” on the rear. 7. Connect the power adaptor. 8. Turn on the “Power” switch after the cameras are installed. The EZVR4 will then “boot” up and begin recording. -
Page 6: Front Panel
FRONT PANEL : Quad screen mode button : Channel 1 full screen button CHANNEL 1 : Channel 2 full screen button CHANNEL 2 : Channel 3 full screen button CHANNEL 3 : Channel 4 full screen button CHANNEL 4 : 24 hour recording mode : 72 hour recording mode : 240 hour recording mode 240H... -
Page 7: Rear Panel
REAR PANEL Power cord in 12VDC / 5A, Power Switch (ON / OFF) Camera 1 ~ 4 input BNC type Main monitor output Audio channel input x 1 and output x 1 – RCA Type Alarm / Relay connector... - Page 8 Booting Up Indicator: Live: HDD installed Live mode Alarm Input Playback: Forward Detecting the hard disk Recording Overwrite Video loss Key lock Alarm Output Reverse Pause Live screen...
- Page 9 Remote controller The keys on the remote control have the same functions as the front keyboard of the unit.
- Page 10 Main MENU – Time Setup Press ENTER to select Time Set. Press ENTER again to display the cursor. Use the left or right buttons to select the item you wish to adjust, then press ENTER to change the value. Press MENU to return to the previous screen and move the cursor to Apply. Press ENTER to confirm.
- Page 11 Main MENU – Audio Record Use direction buttons to select Audio Record. Diagram Speaker Microphone Press ENTER to select On or Off. RCA Cable Audio Out (Line Level) Audio In (Line Level)
- Page 12 Main MENU – Alarm Input Main MENU – Alarm Output Use direction buttons to select Alarm Output. Press the Enter button to turn the output relay on or off. Use direction buttons to select Alarm Input. Press the Enter button to choose the type of sensor input (Normally Open - NO or Normally Closed - NC).
- Page 13 Alarm Input Alarm 1 + GND / Alarm 2 + GND / Alarm 3 + GND / Alarm 4 + GND The Alarm Signal type depends upon the Alarm Sensor polarity defined as NO (Normal Open) or NC (Normal Close). Alarm Output: Relay: NO + COM or NC + COM Relay: NO (Normal open)
- Page 14 Use direction buttons to select Overwrite Enable. Press the Enter button to choose Yes or No. When Auto Record is set to On, the EZVR4 will start recording again after 2 minutes of inactivity after being manually stopped. NO - Recording stops when the Hard Drive is full YES –...
- Page 15 Main MENU – Language Main MENU – Exit Use direction buttons to select Language. Press Enter button to choose a language. Supported Languages: English / French / Spanish Use direction buttons to select Exit. Press Enter button to leave the menu.
- Page 16 Playback mode – Note: Instructions appear on the screen after selecting “Search” Press SEARCH to enter the playback mode. Use the left or right arrows to select the item you wish to change, then press ENTER to change the value Press ENTER to start the searching.
- Page 17 Backup mode Note: Plug in a USB device before starting the backup You must first playback an event using instructions from the previous page. When the event you wish to backup appears on the screen, press the BACKUP button to select the start time.
- Page 18 Player Software Main Screen Click icon to select the file to play. It will be in .vvf format...
- Page 19 Starts to play; Open File Fast Reverse Play Reverse Previous Frame Pause Next Frame AVI Button: .vvf file export to .avi format Select export channel(s) and click audio if included. Percentage of the export AVI progress Play Fast Forward Still Capture (Save to C:\ Capture & Clipboard) Full Screen (manual switch) Quad Screen Browse for the source file...
- Page 20 Specifications EZVR4 Model Input 4 CH Inputs 1.0Vp-p, 75ohm (BNC Type) Output Main monitor composite video (BNC type) x 1 Horizontal Resolution 640x448 (NTSC) / 640x544 (PAL) S/N Ratio More than 40dB Color 6.7 Million Monitoring Method Channel Display Single / Quad channel 640(H)x 448(V) Active Pixels(NTSC);...
