Summary of Contents for Logicor 1001
- Page 1 Clear Heater System Control Panel User Guide Logicor (CH) Ltd. Version / Issue Date: 12 Mar 2014...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ....................1 Control Panel ..................2 Clear Heater Units ................3 SECTION 1: HELP MODE ..................4 Help Mode ..................5 SECTION 2: CONTROL PANEL & TEMPERATURE SETTINGS ........6 Control Panel & Temperature Settings ......... 7 ... - Page 3 Load Original Settings ..............19 Clear Heater System Settings ............20 o Adjust Complete System ............. 21 o Adjust Zones ................22 Edit Zone Name & Temperature ......23 Add New Zone ............24 Assign Heater Units to Zone ........25 ...
- Page 4 Heat-up Mode ................. 38 Heater Surface Temperature ............39 SECTION 3: STATUS SCREEN ................40 Status Screen ................... 41 SECTION 4: COST & ENERGY SETTINGS ............. 42 Cost & Energy Settings ..............43 Adjust Cost & Energy Settings ............44 SECTION 5: TIMER SETTINGS ................
-
Page 5: Introduction
Section 5: MENU ► heading at the top of the page to go direct to Timer Settings……………....... (Page 45) that page. Check out our website www.clear-heater.co.uk product updates. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 1... -
Page 6: Control Panel
The control panel is also equipped with Wifi capability to Section 5: receive software updates via the internet. A new feature Timer Settings……………....... (Page 45) to be launched in 2014 will be the ability to connect via your Smartphone or iPad. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 2... -
Page 7: Clear Heater Units
Caution! Clear Heaters operate at a normal 70°C (158 °F). Please be careful when heating in the vicinity of young or vulnerable people. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 3... -
Page 8: Section 1: Help Mode
Help Mode………………………....(Page 4) Section 2: Control Panel & Temperature Settings (Page 6) Section 3: Status Screen……………......(Page 40) Section 4: Cost & Energy Settings…....... (Page 42) Section 5: Timer Settings……………....... (Page 45) © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 4... -
Page 9: Help Mode
This gives you an overview of your current screen (which is non selectable), and a descriptive help message at the top of the screen. Pressing ‘Exit Help’ takes you back to your original screen. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 5... -
Page 10: Section 2: Control Panel & Temperature Settings
Help Mode………………………....(Page 4) Section 2: Control Panel & Temperature Settings (Page 6) Section 3: Status Screen……………......(Page 40) Section 4: Cost & Energy Settings…....... (Page 42) Section 5: Timer Settings……………....... (Page 45) © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 6... -
Page 11: Control Panel & Temperature Settings
Loading the original factory settings will reset the control panel completely and delete all your preferences. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 7... -
Page 12: Main Settings
Fireguard (Page 18) Fireguard warns you if a heater unit detects a higher than expected temperature in the room. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 8... -
Page 13: Wifi Settings
Connecting to the internet also allows you to access your control panel via your Smartphone. Use the keypads to type in your settings and press the save button to store your settings. The INFO message displays the current Wifi status. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 9... -
Page 14: Time & Date
Once set, you should not need to adjust the time and date again if your control panel is connected to the internet. Time and date updates will then be automatic. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 10... -
Page 15: Tariff Settings
Your tariff settings can be found on your utilities bill, or by contacting your service provider. Please remember to amend your tariff rate on the control panel if and when your tariff changes. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 11... -
Page 16: Units Of Measurement
Press the save button to store your entry. The currency and temperature units are required to display your cost performance targets and the system temperature. You can change your preferred units from the available options. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 12... -
Page 17: Screen Options
Choose which performance data appears on the main status screen by selecting ‘Status screen options’. Change the screen brightness and energy saving settings by selecting ‘Brightness settings’. Touch recalibration allows you to fine tune the touch- screen sensitivity settings. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 13... -
Page 18: Status Screen Options: Choose A System
If you only have one heater system available only one option will be listed. Additional systems are proposed for the future that will be listed on this screen if available. Please check our website for product updates. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 14... -
Page 19: Status Screen Options: Choose Readings
Once your choice is selected it will display a tick next to the item and will be displayed on the main status screen. The status screen is reached by pressing the ‘Home’ Icon. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 15... -
Page 20: Brightness Settings
Sleep mode is the energy saving function of the control panel. In sleep mode the main display screen dims to black. You can change how long (in seconds) the display is active before switching off into sleep mode. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 16... -
Page 21: Recalibration
13) to start the recalibration process where you’ll be asked to touch a dot at the top-left, bottom-right and middle of the screen to automatically adjust to your settings. When completed, the confirmation screen will display the results. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 17... -
Page 22: Fireguard Settings
You can set the preferred warning temperature to any value above 50°C (122 °F). We recommend 51°C (124 °F). The Fireguard function can be turned on or off. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 18... -
Page 23: Load Original Settings
Load the original settings if you want to reset the system back to the original factory settings. Once reset, you will have to re-enter all your settings and preferences again. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 19... -
Page 24: Clear Heater System Settings
The normal surface temperature of a heater unit during operation is 90°C (194 °F). You can change this for your own heating environment; a lower temperature in a child's bedroom for example. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 20... -
Page 25: Adjust Complete System
You can also turn the system on and off. Leave the system on if you want the control panel to optimise your heating for you. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 21... -
Page 26: Adjust Zones
Scroll through the list to select an existing zone to adjust or press 'Add new zone' to add a new zone to the system. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 22... -
Page 27: Edit Zone Name & Temperature
Give each zone a unique name and temperature by entering the details with the keypad. Heater units can also be assigned to a zone or the zone can be deleted from the system. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 23... -
Page 28: Add New Zone
Give each zone a unique name and temperature by entering the details with the keypad. Heater units can also be assigned to a zone or the zone can be deleted from the system. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 24... -
Page 29: Assign Heater Units To Zone
All heater units assigned to a zone then use the zone settings. Assigned heater units will display a tick next to the name. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 25... -
Page 30: Delete Zone
Choose NO to cancel this action and return to the previous screen. Zones can be deleted from the system. Only the zone will be deleted and not the individual heater units. Confirm your choice with yes or no. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 26... -
Page 31: Adjust Heaters
Select this option to manually add a new heater to or linked together with other heaters to work as one unit. the system. Adjust the individual settings here to give each heater unit a unique setting. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 27... -
Page 32: Add New Heater
Each heater unit has a unique identification number on the underside of the base. Plug in your new heater unit and enter the heater ID number here to automatically add it to the system. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 28... -
Page 33: Add New Heater: Waiting
Each heater unit has a unique identification number on the underside of the base. Once you enter this number on the previous screen (Page 28), the control panel attempts to connect the new heater unit automatically. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 29... -
Page 34: Add New Heater: Confirmation
The results are shown on this screen. If successful you can adjust its individual settings or repeat the process to add an additional new heater unit. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 30... -
Page 35: Edit Heater Name & Temperature
Give each heater unit a unique name and temperature by entering the details with the keypad. Heater units can also be assigned to a zone or deleted from the system. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 31... -
Page 36: Delete Heater Unit
YES or NO. If you make a mistake, a heater unit can always be added again by selecting the 'add new heater' option on page © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 32... -
Page 37: Link Heaters
This can be useful when you have a large room that Select this option to manually add a new link to the has a higher heating requirement. system and connect several heater units together to operate as one unit. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 33... -
Page 38: Edit Name & Temperature Of Link
Give linked heaters a unique name and temperature by entering the details with the keypad. Linked heaters can also be modified by adding or removing heater units or a link can be deleted from the system completely. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 34... -
Page 39: Add New Link
Give your new link a unique name and temperature by entering the details with the keypad. Linked heaters can also be modified by adding or removing heater units or a link can be deleted from the system. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 35... -
Page 40: Modify Link
All linked heater units then operate as if they were one unit. Selected heater units will display a tick next to the name. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 36... -
Page 41: Delete Link
Named links can be deleted from the system. Only the link between heater units will be deleted and not the individual heater units. Confirm your choice with yes or no. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 37... -
Page 42: Heat-Up Mode
Decrease the normal surface temperature during heat- up where it may be considered safer to have lower surface temperatures; in a child’s bedroom or with elderly or vulnerable people for example. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 38... -
Page 43: Heater Surface Temperature
Increase the normal surface temperature in a particularly cold environment. Decrease the normal surface temperature where it may be considered safer to have lower surface temperatures; in a child’s bedroom or with elderly or vulnerable people for example. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 39... -
Page 44: Section 3: Status Screen
Help Mode………………………....(Page 4) Section 2: Control Panel & Temperature Settings (Page 6) Section 3: Status Screen……………......(Page 40) Section 4: Cost & Energy Settings…....... (Page 42) Section 5: Timer Settings……………....... (Page 45) © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 40... -
Page 45: Status Screen
You can choose which status readings are displayed here by pressing the ‘Control Panel & Temperature Settings’ Icon then choosing Main Settings / Screen Options / Status Screen Options (See page 13). © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 41... -
Page 46: Section 4: Cost & Energy Settings
Help Mode………………………....(Page 4) Section 2: Control Panel & Temperature Settings (Page 6) Section 3: Status Screen……………......(Page 40) Section 4: Cost & Energy Settings…....... (Page 42) Section 5: Timer Settings……………....... (Page 45) © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 42... -
Page 47: Cost & Energy Settings
Additional systems are proposed for the future that will be listed on this screen if available. Please check our website for product updates. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 43... -
Page 48: Adjust Cost & Energy Settings
Press the save button to energy use target with the keypad. store your entry. As you change one reading, all other readings automatically update and adjust to your chosen target. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 44... -
Page 49: Section 5: Timer Settings
Help Mode………………………....(Page 4) Section 2: Control Panel & Temperature Settings (Page 6) Section 3: Status Screen……………......(Page 40) Section 4: Cost & Energy Settings…....... (Page 42) Section 5: Timer Settings……………....... (Page 45) © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 45... -
Page 50: Timer Settings
INFO message at the top of the until your room environment cools down by 9°C. At that screen. point the heater system will resume heating to retain the new lower temperature. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 46... -
Page 51: Weekly Settings
9°C. At that point the heater system will resume heating to retain the new lower temperature. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 47... -
Page 52: Add Event
An event of -9°C for example will in effect switch the heater system off until the room environment cools down by 9°C. At that point heating will resume at the new lower temperature. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 48... -
Page 53: Adjust Event
An event of -9°C for example will in effect switch the heater system off until the room environment cools down by 9°C. At that point heating will resume at the new lower temperature. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 49... -
Page 54: Graphical View
A reduction in temperature will be shown below the blue line. Your current day and time is displayed below the graph, together with the status of your weekly scheduling; either enabled or disabled. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 50... -
Page 55: Enable / Disable Scheduling
INFO message at the top of the until your room environment cools down by 9°C. At that screen. point the heater system will resume heating to retain the new lower temperature. © 2014 Logicor (CH) Ltd clear-heater.co.uk Page 51... -
Page 56: Specification: Control Panel
Logicor Model No. 1001 Base: Chrome plated Aluminium Performance Rating <5W (<0.005kW/h) Electric Supply: Located on the rear of the control panel, connection via CAT5 or CAT6 patch lead to a Logicor bespoke power supply unit. Voltage 110v to 330v TECHNOLOGY Width... -
Page 57: Specification: Clear Heater Units
Safety Glass Heat Form: Radiant and Convection; Width 1100mm 550mm Maximum effective range: 8m; 4~9um wavelength range. Height 600mm 600mm Internal: Logicor proprietary computer controlled software Depth 11mm 11mm TEMPERATURE CONTROL Programmable via Control Panel. Weight 19kg 10kg... - Page 58 MANUFACTURER: Logicor (CH) Ltd Unit 7 Thornes Office Park Monckton Road Wakefield WF2 7AN West Yorkshire UK www.logicor.co.uk www.clear-heater.co.uk...
