- Page 1 TBSR-92 TBSR-72 TBSR-60 instruction sheet Assembly Recommended Tools: Open Wrench （1pcs) Size=19mm...
- Page 2 Assembly Diagram Item# Description Quantity Item# Description Quantity M12x75 right longitudinal beam outer hexagonal bolt full thread left longitudinal beam 12 Spring washer U-type mounting plate 12 large flat washer Part List...
- Page 3 STEP 1. Place the left and right longitudinal beams (1, 2) on the right side of the pickup bucket, as shown in figure I, to see if drilling is needed, if you need to drill,confirm the drilling position first, remove the left and right longitudinal beam (1, 2) .Drill the diameter of 13 hole with the hand electric drill,then assemble right longitudinal beam(1),With the outer hexagonal bolt full thread (4)into the 12 Spring washer (5), 12 large flat washer (6), the right longitudinal beam (1) on the U-type mounting plate (3) in...
- Page 4 STEP 2. Assembly completed as shown in Fig.2. Fig.2...
