Hot Runner System Installation Guide
Service and Maintenance / Actuator HB Series
8.1.1 Actuator HB Series
8.1.1.1 Technical Data
Parameters
Valve Pin Diameter
Nozzle Series
Pin Adjustment
MIn/Max Close Forces
Min/Max Open Forces
Min/Max. Hydraulic Pressure
Valve Pin Stroke
Hydraulic Connections
Cooling Temperature
Cooling Connections
Thermocouple and Position Sensor optional on all models.
Maximum 3 Actuators per cooling zone on all models.
NOTICE
To ensure long life and continued flawless operation of the actuator, we recommend using a service
medium that complies with the requirements of classification 21/18/13 pursuant to ISO 4406.
The coolant should be properly modified e.g. filtered water with an anti-corrosion and frost proof agent.
After switching off the Hot Runner heater, the cooling for the actuator should remain on for at least
15 minutes, to avoid damage to the Actuator seals and the position sensor.
Master Language is English
RESTRICTED: Property of Synventive.
For limited third party distribution based on need and intended use.
T
R
U
N
N
HB2508#
3 mm, 3.8 mm
06E, 09E
+/- 1 mm
1963/2945N
443/2267N
40/60 bar (600/870 psi)
8 mm
M10x1.0
30-60°C
M10x1.0
Hot Runner System Installation Guide
E
R
T
E
C
5 mm, 6 mm, 8 mm, 12 mm
12E, 16E, 22E
+/- 1.5 mm
5027/7540N
3506/5259N
40/60 bar (600/870 psi)
16 mm
M10x1.0
30-60°C
M12x1.5
Recommended HB4016 Actuator Pressure
Settings when Hydraulic Manifold Block
Diameter
EN
- 85 -
All rights reserved. Errors and omissions excepted
H
N
O
L
O
G
HB4016#
is not Supplied on Hot Runner
Pin
Actuator Pressure
PSI
(mm)
5
300
6
450
8 & 12
600
SVC-17-0001_EN-Rev13
© 2021 Synventive Molding Solutions
Y
Bar
20
30
40
