Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.

For any assistance with assembly or for missing parts please phone

Amart Furniture, Customer Service Free call 1800 351 084

ASSEMBLY INSTRUCTION

QUINN DESK

ITEM CODE 65499

Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.

For any assistance with assembly or for missing parts please phone

Amart Furniture, Customer Service Free call 1800 351 084

65499

Table of Contents

Need help?

Do you have a question about the 65499 and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTION QUINN DESK ITEM CODE 65499 Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia. For any assistance with assembly or for missing parts please phone Amart Furniture, Customer Service Free call 1800 351 084 Imported by Amart Furniture Pty Ltd, Qld, Brisbane Australia.
Page 2 Ensure that you have all required contents for complete assembly. Always read the assembly instruc ons carefully before beginning assembly. Keep all hardware parts and packaging out of reach of small children. Do not over ghten the screws and bolts as this may damage the threads. 65499...
Page 3 PARTS LIST M6x30mm M6x12mm M4x20x60mm 964x600x18mm 725x600x18mm 16x16x964mm 46x16x964mm 65499...
Page 4 EXPLODED VIEW C2 x2 C4 x2 65499...
Page 5 Fix C3 to square frame C2 using Bolt A and tighten using Allen Key D. C2 x2 C4 x2 STEP 2: Fix desk panel C1 to desk frame Using Bolt B and tighten using Allen Key D. C4 x2 65499...
Page 6 Screw lever C to desk frame. STEP 3 Assembly Complete 65499...
Page 7 4. Make sure that the Moun ng Plates are ﬁrmly a ached to the wall and furniture and that the Wall Strap is snug. HARDWARE Moun ng Plate x 2 Wall Strap x 1 Large Screw x2 Small Screw x2 65499...
Page 8 • Avoid placing sharp or rough objects on the surface of your furniture. These may scratch the surface of the product • When moving your furniture, do not drag it across the ﬂoor. This may damage the product. Instead use two (2) people to li carefully from either end 65499...
