2014 RDX – ALL
Applies To:
2014 RDX: TQI Information
INTRODUCTION
This service bulletin explains many of the procedures
needed to do a Total Quality Inspection (TQI) on the
2014 RDX. For more new model information, refer to
training module WB 13-01, 2013 RDX New Model
Introduction.
NOTE: For the TQI of the navigation system, refer to
Service Bulletin 13-018, 2014 RDX: TQI of the
Navigation System.
The 2014 RDX is available in these trim levels:
• 2WD (Base)
• 2WD with Technology Package
• AWD (Base)
• AWD with Technology Package
This service bulletin includes these TQI
procedures:
• Install the Fuses
• Check the Battery
• Battery Management System
• Install the Shift Lock Release Cover
• Set the Radio Anti-Theft Code
• Set the Compass Zone (Models without Navigation)
• Check/Refresh the XM Satellite Radio Dealer Demo
Service (All Except Alaskan & Hawaiian Models)
• Check the HandsFreeLink System
• Check the Moonroof One-Touch Feature
• Initialize the Driver's Window Up/Down Feature
• Remove the Interior Protective Coverings
• Install the Floor Mats
• Remove the Exterior Protective Coverings
• Set the Tire Pressures
• Install the Front License Plate Holder and the Rear
License Plate Bolts
• Do the Idle Learn Procedure
• Do the CKP-Pattern Learn Procedure
• Complete the Personalized Settings Check Sheet
(To Be Done by Sales Staff)
 2013 American Honda Motor Co., Inc. – All Rights Reserved
CLIENT INFORMATION:
The information in this bulletin is intended for use only by skilled technicians who have the proper tools, equipment, and
training to correctly and safely maintain your vehicle. These procedures should not be attempted by "do-it-yourselfers," and you should not assume this
bulletin applies to your vehicle, or that your vehicle has the condition described. To determine whether this information applies, contact an authorized
Acura automobile dealer.
Service Bulletin
WARRANTY CLAIM INFORMATION
None. These procedures are considered part of the
normal TQI.
TQI PROCEDURES
Before doing the TQI, review these items:
• Perfect Delivery documents, especially the
information on battery maintenance and tire
pressures
• TQI checklist in the maintenance journal
Make sure you complete the TQI checklist in the front
section of the Maintenance Journal. The TQI
procedure is not finished until this bulletin and the TQI
checklist are both completed.
BTB 49375 (1304)
13-017
April 4, 2013
1 of 8

Advertisement

loading

Related Manuals for Acura 2014 RDX

Summary of Contents for Acura 2014 RDX

  • Page 1 None. These procedures are considered part of the needed to do a Total Quality Inspection (TQI) on the normal TQI. 2014 RDX. For more new model information, refer to training module WB 13-01, 2013 RDX New Model TQI PROCEDURES Introduction.
  • Page 2 Install the Fuses Battery Management System To prevent battery drain during shipping, the No. 28 The battery management system includes a sensor on (7.5 A Interior Light) and the No. 29 (10 A Backup) the battery negative cable and a system message that fuses are removed and stored in the technology pocket may appear on the instrument panel if a battery where the USB cable is located.
  • Page 3 Set the Radio Anti-Theft Code Set the Compass Zone (Models without Navigation) The anti-theft code is automatically checked between In most areas, there is a variation between magnetic the PCM and the audio unit; there is no longer a need north and true north.
  • Page 4 Check/Refresh the XM Radio Dealer Demo Service 8. From the iN main menu, click on SERVICE, click on (All Except Alaskan and Hawaiian Models) Service Bay, and then click on XM Radio. This brings up the DEALER ACTIVATION REFRESH The audio system comes from the factory activated screen.
  • Page 5 NOTE: Check the HandsFreeLink System • The dealer demo service lasts for 7 months or until To confirm that the HFL (HandsFreeLink) system is the vehicle’s RDR (retail delivery registration) is working and ready to use, start the engine and hold the submitted.
  • Page 6 Remove the coverings with clean hands so you don’t soil the fabric. If any of the interior is dirty, clean it with mild soap or an Acura cleaning product such as Leather & Vinyl Cleaner (P/N 08700-9214A) or Carpet Spot Remover (P/N 08700-9215A).
  • Page 7 Install the Floor Mats Install the Front License Plate Holder and the Rear License Plate Bolts The floor mats are in the cargo area. Install them in the appropriate positions. Place the driver’s and front The front license plate holder and mounting hardware passenger’s floor mat eyelets over the anchors on the are in the TQI plastic bag in the rear cargo area.
  • Page 8 Do the Idle Learn Procedure To avoid an erratic idle, do the idle learn procedure after you install the No. 29 fuse. NOTE: Idle speed adjustment is done by the PCM; there is no adjustment screw. 1. Make sure all electrical items (A/C, radio, rear window defogger, lights, etc.) are off.
