3.2 Safeguard

When the video signal of your computer exceeds the frequency range of
monitor (refer to product specification),the micro-computer of monitor will
turn off the sync signal of horizontal and vertical for the purpose of monitor
protection,please refer to the illustration below.The monitor will enter saving
mode after few seconds, and the power indicator will light red.Please
set the output frequency of your computer
within the acceptable range of monitor
so thatthe monitor can work normally.
3.3 Setting of dispaly mode
With standard VESA and DDC function, the monitor will scan frequency, out-
put power, performance etc and transfer to PC after turning on when you use
the video card with VESA DDC1/2B function. And it will identify the connec-
tion mode of display and select the proper resolution.
The preset mode before leaving factory is as below:
Mode
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15 1280X1024
16
17
18 1680X1050
19 1920X108 0
Resolution
800X600
800X600
800X600
800X600
1024X768
1024X768
1024X768
1024X768
1024X768
1024X768
1152X864
1280X800
1280X800
1366X768
1440X900
1600X900
Vertical(Hz)Min
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
Vertical(Hz)Max
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
240Hz
