Installation guide DDE 2000 eco DDE 2000 eco order no.: 09.730.008 Do not use this product unless you have read the installation instructions and understood them. Original operating instructions 09730008-08-02...
Pass these and other supplementary documents on to any subsequent owners or users. Add all changes to the documents that they obtain. Check the completeness of the documents and pay attention to their content. DDE 2000 eco 0973008-52-02...
Outlet Rear 1.000 Production year See model plate * using the enveloping surface method DIN EN ISO 3744, measured at minimum volume flow; noise measurement margin of error approx. 4 dBA ** Custom voltage on request 0973008-52-02 DDE 2000 eco...
As a central extraction system on chip-generating machinery. As a central extraction system on machines which generate grinding dust and chips. Other applications are considered unintended use. ESTA is not liable for damages due to unintended use! 2.2.3 Improper use The product has been manufactured according to the state of the art and recognized safety regulations.
Product Description 3. Product Description 3.1 Product presentation of DDE 2000 fan unit Mains power supply Filter unit Outlet element Disposal unit Compressed air connection Intake port Fan Unit 0973008-52-02 DDE 2000 eco...
When so doing, you must ensure that The minimum airflow volume sucked away is not undershot. The minimum airflow volume depends on the diameter of the intake port of the extraction element and the requisite conveying velocity. DDE 2000 eco 0973008-52-02...
Failure to comply can lead to severe injury or death, and can destroy the product or parts thereof. CAUTION Instruction about a hazard. Failure to comply can lead to mild injury and to damage to the product. Symbol explanation Reference to legal regulations 0973008-52-02 DDE 2000 eco...
Page 10
1. Switch off the product. 2. Wait 5 minutes. 3. Then pull out the collection drawer or open the product. Do not take in glowing dust or other sources of ignition. Do not use in conjunction with spark-generating machinery. DDE 2000 eco 0973008-52-02...
If there is a fire, alert the fire department immediately, and contain the fire by appropriate means. Therefore keep a suitable extinguishing agent near the product before start-up and during operation. 0973008-52-02 DDE 2000 eco...
The lifting device protrudes from the product when at rest. Do not stand on the lifting device. All movable machine parts driven by electric motors must be covered by fixed, securely fastened protective covers that can be removed only with tools. DDE 2000 eco 0973008-52-02...
Any work on the electrical grid and on voltage-conducting parts may only be performed by an electrical specialist. Use only original ESTA replacement parts. DANGER High-voltage electric shock when working on the running product. Switch product off via the main system and secure against being switched back on! ...
The people assigned to cleaning work must be instructed on the aspirated toxic materials. Harm to bystanders and the environment must be prevented by all means. Clean the maintenance area thoroughly once maintenance is complete. DDE 2000 eco 0973008-52-02...
Pay attention to the weight of the product and its centre of gravity during all transport work. Use the attached rollers for further transport to its installation location. 0973008-52-02 DDE 2000 eco...
Any work on the electrical grid and on voltage-conducting parts may only be performed by an electrical specialist. Use only original ESTA replacement parts. Before establishing cable connections between the product and the available mains, check whether the operating voltage specified on the rating plate matches that of the mains.
Page 17
Compressed air quality (ISO 8573- Class 3.2.2 1:2010-04) Pressure [bar] 4 - 6 2 x 1/4 (ø 9 Connection-ø [''] Compressed air consumption * [l/pulse] * at 4 bar with a valve opening time of 0.12 sec. 0973008-52-02 DDE 2000 eco...
Page 18
If the pipe diameter is increased or the pipeline lengthened, it cannot be guaranteed that no dust deposits will collect in the pipeline. Observe the minimum air speed for your application. Regularly check the pipeline for dust deposits. DDE 2000 eco 0973008-52-02...
2. Check the clockwise field of rotation of the product. 3. In the event of incorrect direction of rotation get an electrician to switch phases. 4. Switch the connected main system back on. 5. The product is ready for operation. 0973008-52-02 DDE 2000 eco...
4. Switch the product back on via the connected main system. 5. Connect the compressed air. 5.4.1 Preparing the dust collection containers Dust collection containers are inserted in the dust collection drawer. Prepare this as follows: DDE 2000 eco 0973008-52-02...
Page 21
If no disposal carton is required in the collection drawer due to the nature of the material collected, the device can also be operated without this. In such an instance, take out the disposal carton and the inlay from the collection drawer. 0973008-52-02 DDE 2000 eco...
During operation, do not change the product’s location. When finishing the processing operation: 1. End the processing operation. 2. Switch off processing machine / extraction element. 3. Take the product out of service by switching off the connected main system. DDE 2000 eco 0973008-52-02...
Page 23
5 minutes until the cleaning cycle has finished and the compressed air beam no longer rotates. When the fan is at a standstill during the rotation cleaning, dust may escape from the extraction points due to the compressed air introduced. 0973008-52-02 DDE 2000 eco...
When there is a malfunction, switch the product off immediately and contact the responsible maintenance service! Detailed descriptions of the maintenance work are contained in the supplementary maintenance instructions. Please consult them! DDE 2000 eco 0973008-52-02...
Compressed air butterfly Replace Clean Trails of dust or deposits on air Visual inspection outlet openings Volume flow Measurement Negative pressure Measurement Power consumption Measurement Visual inspection Filter Replace Airtightness of the whole Function check product 0973008-52-02 DDE 2000 eco...
11. Insert the fastening screws of the cover and tighten them. 12. Re-attach the compressed air supply. 13. Switch the product back on via the connected main system. 14. The product is now ready to operate again. DDE 2000 eco 0973008-52-02...
Depending on the type of application, a weekly check of the external and internal sides of the air guide plate is necessary. If adhesions are detected in this process, these must be removed. 0973008-52-02 DDE 2000 eco...
Page 28
13. Insert the fastening nuts around the air guide plate and screw these in tightly. 14. Push the pipe or hose line onto the intake connection piece and fix this firmly. 15. Re-attach the compressed air supply. => The product is now ready to operate again. . DDE 2000 eco 0973008-52-02...
Filters must be replaced with new ones. This work should be done only by an expert. If possible, filter replacement must be done when there is no work going on. This process requires 2 people with personal protective gear. 0973008-52-02 DDE 2000 eco...
Page 30
9. Fasten the end of the bag securely with a cable tie. 10. Remove remaining filter cartridges as described. 11. Clean the rim around the opening for inserting the filter cartridge. Avoid raising dust DDE 2000 eco 0973008-52-02...
2. Empty the collection drawer and dispose of the collected material according to local regulations. 3. Clean the product inside and out. With a damp disposable cloth. With an industrial vacuum cleaner. Do not spray down with a water jet! 0973008-52-02 DDE 2000 eco...
Motor protection trips. Motor was switched on/off Please consult the "Activation too often within a short operations for motors" table. period of time. DDE 2000 eco 0973008-52-02...
Page 33
(filter cartridges, filter mats, etc.). Smoke development or Imbalance in the fan. Turn the product off load running noises of the immediately and have ESTA fan. customer service inspect the fan. Rotor is scraping on the Switch product...
3. Take the removable parts (e.g. motor, fan, cover, etc.) out of the product. 4. Package and dispose of the product and removable parts according to local regulations. Due to contamination of the product with toxic dusts, ESTA cannot take the product or individual parts of it back. DDE 2000 eco...
The product can be fitted with different equipment options. The following optional equipment is available for this product. Control filter Optionally, a control filter positioned downstream of the main filters can be used. When so doing, observe the supplementary instructions on this optional equipment. 0973008-52-02 DDE 2000 eco...
Declaration of incorporation 10. Declaration of incorporation Name of manufacturer: ESTA Apparatebau GmbH & Co. KG Address of manufacturer: Gotenstraße 2 - 6 89250 Senden Name of the authorised document representative: ESTA Apparatebau GmbH & Co. KG Gotenstraße 2 - 6...
Page 37
Technical documentation was created according to Appendix VII Part B of this guideline. We agree to provide the responsible authorities with this documentation in electronic form upon justified request. Senden, 29/07/2016 Dr. Peter Kulitz Managing Director 0973008-52-02 DDE 2000 eco...
