Assembly and Operating Instructions for
Aurora 2 Flat Lid, Aurora 3 Flat Lid & Aurora 4 Flat Lid
TRG2213
Drawings are not to scale.
Specifications subject to change
without prior notice.
• For outdoor use only. Not for commercial use.
• Use only Propane regulator 37mbar .
• Read instructions before using the appliance. Failure to follow
instructions could result in death, serious bodily injury, and/or property
loss.
• Warning: accessible parts may be very hot. Keep young children away.
• Do not move the appliance during use.
• Turn off the gas supply at the gas bottle after use.
• Any modification of the appliance, misuse, or failure to follow the
instructions may be dangerous and will invalidate your warranty. This does not
affect your statutory rights.
• Retain these instructions for future reference.
WARNING
• Leak test your barbecue annually. Check the hose connections are tight and leak
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open barbecue lid or hood.
4. If odour continues, discontinue use and contact
your local dealer.
TRG3213
test them each time you reconnect the gas bottle.
FOR YOUR SAFETY
1. Do not store or use petrol or other flammable
vapours or liquids in the vicinity of this or any
other appliance.
2. A gas bottle not connected for use shall not be
stored in the vicinity of this or any other
appliance.
TRG4213
0359
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lifestyle Aurora 2
Summary of Contents for Lifestyle Aurora 2
- Page 1 Assembly and Operating Instructions for Aurora 2 Flat Lid, Aurora 3 Flat Lid & Aurora 4 Flat Lid TRG2213 TRG3213 TRG4213 Drawings are not to scale. Specifications subject to change 0359 without prior notice. • For outdoor use only. Not for commercial use.
-
Page 2: Parts List
A. Parts List Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see the corresponding Hardware Reference Diagram for your barbecue model. CODE PART 2 Burner Flat Lid 3 Burner Flat Lid 3 Burner Flat Lid Lid (Pre-assembled to Body) Lid Handle... -
Page 3: Parts Diagram
B. Parts Diagram Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on hardware, please see ‘Hardware Reference Diagram’. - Page 4 C. Hardware Reference Diagram Specifications subject to change without prior notice. D6 D7 Tools Required (not supplied) • Cross Head Screwdriver • Adjustable Spanner...
- Page 5 D. Assembly TOOLS NEEDED FOR ASSEMBLY: Medium size flat blade or Philips/crosspoint screwdriver, adjustable spanner or metric spanner set Please lay out all nuts and bolts and check lengths before assembling. Whilst every care is taken in the manufacture of this product, care must be taken during assembly in case sharp edges are present.
- Page 6 Lay the trolley assembly upside down. Unscrew the Locknuts (C13) from both end of Axle (C10). Thread the axle through the holes in Left Legs (C2,C3), then place a Wheel (C11) on each end of axle and secure with the locknuts. Note: The wheels should be placed outside of the left legs.
- Page 7 Lay the Trolley Base(C7) to the trolley assembly as shown. Insert M6x110 Bolts (D6) through legs, Spacers (D7). Don’t let the bolts over the spacers, it’s easy to assembly. Place the body in correct position and screw the bolts into the sidewalls of Barbecue Body (B1). (Two more people are required ) Lay Flame Tamers (B8), Cooking Grill (B6) and Cooking Griddle (B7) as shown.
- Page 8 Attach Drip Tray Right Bracket (B10) onto Barbecue Body (B1) using M5x15 Bolts (D3) , Ø5 Washers (D5) and M5 Nuts (D4) as shown. Repeat for Drip Tray Left Bracket (B9). Make sure that the tabs which stops drip tray are located at front. Slide the drip tray underneath the barbecue body completely.
- Page 9 Attach the Front Screen (C6) onto the rear of the front legs using the Velcro tabs as shown. IMPORTANT: Carefully screw the hex male fitting onto the threaded gas inlet assembly. IMPORTANT - Screw hand tight only. Then using the spanner (attached on the hose) turn the hex nut a further 1/8 of a turn to ensure tightened.
- Page 10 ASSEMBLY IS NOW COMPLETED. PROCEED TO THE NEXT PAGE FOR INSTRUCTIONS ON OPERATION AND MAINTENANCE. Important- Please ensure the gas hose is free of kinks, twists and from its transit position. IMPORTANT - LEAK TESTING BEFORE USE, FAILURE TO CHECK AND PERFORM THE LEAK TEST COULD CAUSE SERI- OUS INJURY, AND DAMAGE THE BARBECUE.
-
Page 11: Installation
Propane Minimum Bottle Size Bottle Size For outdoors use only – do not use indoors. Do Aurora 2 Flat Lid not use below ground level. 15kg For use with LPG bottled gas only. A regulator of Aurora 3 Flat Lid 13kg 37mbar must be used for propane. -
Page 12: Operation
G3. Connecting Hose/Regulator to Barbecue above procedure, turn all the knobs to the off position. Close the gas valve on the gas bottle. Connect the gas hose to the gas rail inlet on the valve/manifold assembly. Do not over tighten. Do Wait 5 minutes, then repeat the above steps. -
Page 13: Care And Maintenance
H7. Flare-Up Control removed and cleaned annually, or whenever heavy build-up is found, to ensure that there are no signs of Flare-ups occur when meat is barbecued, and its fat and juices fall upon the hot lava rock. Smoke helps blockage (debris, insects) in either the burner give food its barbecued flavour, but avoid excessive portholes or the venturi tubes. -
Page 14: Technical Specifications
J. Technical Specifications NOTE: Heat Injector Gas / Model Burners Approval Input Size Pressure Aurora 0359 8.8kW 2 Flat Lid 359BU944 Butane/ 28- 30mbar Aurora 0359 1.10mm 13.2kW 3 Flat Lid 359BU944 Propane/ 37mbar Aurora 0359 17.6kW 3 Flat Lid 359BU944 Countries of Use: GB, IE... -
Page 15: Troubleshooting
K. Troubleshooting Problem Possible Cause Solution Burners will not light using LP gas bottle is empty Replace with full bottle the ignition system Faulty regulator Have regulator checked or replace Obstructions in burners Clean burners Obstructions in gas jets or gas hose Clean jets and gas hose Electrode wire is loose or disconnected Reconnect wire...
