Sony XS-GS120L Specifications

XS-GS120L
The XS-GS120L SVC subwoofer cone is constructed using a Mica
Reinforced Cellular composite for reduced weight and increase rigidity,
delivering deep bass response.

Bullets

• 12" Single Voice Coil subwoofer
• Mica Reinforced Cellular Glass Fiber Composite Cone
• Single 4 Ohm voicecoil
• Gold plated 5-way binding posts
• 1300W Peak (380W Rated)
• 500 Watts CEA 2031 RMS Power
• 3 year warranty

Features

Subwoofer design
The XS-GS120L SVC subwoofer cone is constructed using a Mica Reinforced Cellular composite
for reduced weight and increase rigidity, delivering deep bass response. The 5-way gold plated
binding post provide secure wire connections for high power handling.
High energy magnets
The XS-GS120L woofer uses a powerful, high energy Ferrite magnet to control cone travel and
deliver big power handling.
Power handling
The XS-GS120L subwoofer is rated for 380 Watts, 500 Watts RMS (CEA 2031 rated) and can handle
peak power of 1300 Watts.
Warranty
The Sony® GS series subwoofers come with a 3 year warranty.

Specifications

Audio

Frequency Response
Impedance
Sensitivity (db)

General

Magnet
Material

Power

Power Handling Capacity
Rated Input
Weights and Measurements
Depth (Approx.)
Diameter (Approx.)
Dimensions (Approx.)
Dimensions (Approx) Depth
30 - 1000 Hz
4 Ohms
84 +/-2dB (1W, 1m)
Ferrite
Mica Reinforced Cellullar Glass Fiber Cone
500 Watts CEA2031 RMS
380 Watts
5 1/2"
12"
Woofer 12" (30cm) Cone
5 1/2"
12" GS series SVC subwoofer
