uhlmann & zacher Clex Assembly Manual

Electronic door handle

Clex Electronic

door handle

Adapter for Scandinavian doors

Table of Contents

Need help?

Do you have a question about the Clex and is the answer not in the manual?

Page 1 Clex Electronic door handle Adapter for Scandinavian doors Assembly manual...
Page 2 LECTRONIC DOOR HANDLE SSEMBLY Imprint Clex Electronic door handle – Adapter for Scandinavian doors Assembly manual (original version) Document number: 12CD Version: 1.0 Status: 10.05.2022 Manufacturer Uhlmann & Zacher GmbH Gutenbergstr. 2–4 97297 Waldbuettelbrunn Germany Tel.: +49 931 40672-0 E-Mail: contact@UundZ.de http://www.UundZ.com...
Page 3 LECTRONIC DOOR HANDLE SSEMBLY Assembly This document does only cover the assembly in combination with the adapter plate for Scandinavian doors. It does not replace the regular operating and assembly manual. Please consult the regular operating manual for all other product related questions.
Page 4 LECTRONIC DOOR HANDLE SSEMBLY Assembling the square pin The square pin has to be assembled before installation on the electronic door handle (outside). This applies to all the versions and is shown here using an example of the circular rosette version. Electronic door handle (Scandinavian version different.
Page 5 LECTRONIC DOOR HANDLE SSEMBLY 1.2.1 Adapter adjustment Remove the two screws that hold the adapter in place  Remove adapter  Rotate adapter to adjust to required position  Available positions:...
Page 6 LECTRONIC DOOR HANDLE SSEMBLY Put adapter back and fix screws   Insert the square pin of the electronic door handle into the square nut of the lock. Insert the mechanical door handle from the other side keeping it in a ...
