Weight Limit:
225
Lb /
102
Kg
L .J . - 2019.10.09
© 2014 Dorel Home Products All Rights Reserved
2231779CLUK(Pink Velvet),2231379CLUK(Ivory Velvet),
Thank you for purchasing from Dorel UK!
Date of Purchase
2231679CLUK(Bleached Teal Velvet)
DO NOT RETURN TO THE STORE !
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Call 01942 524100
Email cseurope@dorel.com
Lot Number
IMPORTANT - READ CAREFULLY - RETAIN FOR FUTURE REFERENCE
Modern Chair
B342231-779CL/379CL/679CL
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Cosmopolitan COSMO Living 2231779CLUK
Summary of Contents for Cosmopolitan COSMO Living 2231779CLUK
- Page 1 Modern Chair 2231779CLUK(Pink Velvet),2231379CLUK(Ivory Velvet), 2231679CLUK(Bleached Teal Velvet) Thank you for purchasing from Dorel UK! Weight Limit: Lb / DO NOT RETURN TO THE STORE ! If parts are missing or damaged, we will gladly ship your replacement parts free of charge. Call 01942 524100 Email cseurope@dorel.com Date of Purchase...
-
Page 2: Warranty Information
Warranty Information Read Before Beginning Assembly DHP warrants this product to be free from defects in material and workmanship and ● Call our Customer Care phone number if you need assistance. agrees to remedy any such defect. This warranty covers one year from the date of ●... - Page 3 Parts All in 1 big box! There are inner box(es) that include components required to complete this assembly. Before you throw the package, please use the Check Box to identify the parts and ensure that Back you have all the parts needed for the assembly. Seat Frame UK803760 UK803780...
-
Page 4: Hardware Pack
Hardware Pack Hardware Pack #: T2231779-00 M8x20mm M6x40mm M8x40mm Please do not completely tighten all the hardware, until the entire assembly is complete, unless otherwise indicated in the step-by-step instructions. The screw(s), bolt(s) to be used at each step are shown in actual size in the lower right corner of the page. - Page 5 Step 1 Attach C & D to E with ,as shown. Note:For ease of assembly, parts C and D are positioned downward.
- Page 6 Step 2 Turn over the frame and attach B to C & D with ,as shown.
- Page 7 Step 3 A to E Tighten up all the bolts and attach with ,as shown.
- Page 8 Step 4 Attach B to A with & ,as shown.
-
Page 9: Helpful Hints
Helpful Hints Weight Limit: Lb / ● Move your new furniture carefully, with two people lifting and carrying the unit to its new location. ● Your DHP furniture can be disassembled and reassembled to move. ● Clean the product with a soft damp cloth. DO NOT use harsh chemicals or abrasive cleaners.
