Yamaha CD-S303 Owner's Manual
Compact disc player
Hide thumbs
Also See for CD-S303:
- Owner's manual (180 pages) ,
- Update manual (2 pages) ,
- Owner's manual (92 pages)
Related Manuals for Yamaha CD-S303
Summary of Contents for Yamaha CD-S303
- Page 1 English Français Compact Disc Player Lecteur Compact Disc CD-S303 Owner’s Manual Mode d’emploi...
- Page 2 Otherwise, fire, burns or damage to the product - Turn off the power to this product. • Please note that Yamaha cannot accept any may be caused. - Disconnect the power cord plug from the AC liability for any losses resulting from improper •...
- Page 3 power switch is turned off, as long as the power Vision loss • Do not use batteries other than the specified cord is not unplugged from the wall AC outlet, type. • Do not look into the laser beam. the product is not disconnected from the power •...
- Page 4 Make sure that there is adequate space around Otherwise, hearing loss or damage to the the product at least 2.5 cm (1 in) above, 2.5 cm product may be caused. CAUTION (1 in) at the sides and 2.5 cm (1 in) behind. •...
- Page 5 Precautions for use COMPLIANCE INFORMATION STATEMENT (Supplier’s declaration of conformity procedure) • Do not place any vinyl, plastic or rubber Responsible Party : Yamaha Corporation of America products on this product. Otherwise, the panel NOTICE Address : 6600 Orangethorpe Ave., may be discolored or deteriorate.
- Page 6 This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by Yamaha may void your authority, granted by the FCC, to use the product. 2. IMPORTANT: When connecting this product to accessories and/ or another product use only high quality shielded cables.
-
Page 7: Table Of Contents
CONTENTS BEFORE USING THE UNIT APPENDIX Features ............8 Part names . -
Page 8: Features
BEFORE USING THE UNIT Features About this manual • Optical digital output • This manual explains operations performed primarily on the supplied remote control. • Coaxial digital output • All illustrations in this manual are provided for the purpose of operational instruction. •... -
Page 9: Accessories
Accessories • Remote control • Power cord • RCA stereo cable • Batteries (AA, R6, UM-3) (x2) • Owner’s Manual (this manual) Inserting batteries into the remote control Insert the batteries in the proper orientation. Batteries (AA, R6, UM-3) Remote control operating range Point the remote control toward the remote control sensor on... -
Page 10: Connecting To An Amplifier
PREPARATION Connecting to an amplifier Connecting the power cord After all the connections are complete, connect the supplied power cord to the AC IN connector on this unit, and then plug the other end into an AC outlet. CAUTION • Do not plug the power cord of this unit and other connected devices into AC outlets until all non- power connections are complete. -
Page 11: Turning On The Power
Turning on the power To turn on the power to the unit, press A (Power) on the front panel. Power indicator A (Power) Note • If you press A (Power) on the remote control while the power to the unit is on, the unit will enter Standby mode. -
Page 12: Playing An Audio Cd
PLAYING AUDIO OPEN/CLOSE Playing an audio CD This unit enables you to play data CDs as well as audio CDs. For Use the following remote control keys to navigate the operation. information on the type of CDs that can be played on this unit, please Available keys Function refer to “Supported file formats/discs/USB flash drives”... -
Page 13: Playing Music Files Stored On Your Usb Flash Drive
Playing music files stored on your USB flash drive You can play music files (stored on your USB flash drive) on this Notice unit. For information on the supported USB flash drives, please • Do not remove the USB flash drive during playback, or while the information refer to “Supported file formats/discs/USB flash drives”... -
Page 14: Advanced Functions
Advanced functions You can configure playback mode and display settings using Playing tracks in the specified order PROGRAM advanced functions. (Program playback) RANDOM Random-sequence playback You can play audio CD tracks in the specified order. REPEAT Press RANDOM to play tracks in random order. Pressing RANDOM Press PROGRAM while playback is stopped. -
Page 15: Playing A Specified Part Repeatedly (A-B Repeat Playback)
Playing a specified part repeatedly Note (A-B Repeat playback) • To use the PURE DIRECT function, connect the ANALOG OUT jacks on the rear panel to the amplifier. The DIGITAL OUT jacks will not output any signals. You can specify the start and end points of a track during audio CD •... -
Page 16: Part Names
APPENDIX Part names Front panel A (Power) (page 11) Remote control sensor (page 9) Power indicator (page 11) (Skip backward/Search backward) (pages 12, 13) USB jack (page 13) (Skip forward/Search forward) (pages 12, 13) USB indicator (page 13) (Play) (pages 12, 13, 14) CD/USB (pages 12, 13) (Pause) (pages 12, 13) PURE DIRECT (page 15) -
Page 17: Display
Display CD TEXT AAC WAV FLAC RESUM RDY TRACK TOTAL REMAIN PROG RNDM REP FOLDER ALL A - B (Play/Pause) indicator (pages 12, 13) Time indicator (page 15) Playback media indicator (pages 12, 13) Playback mode indicator (pages 14, 15) Advanced setting indicator (page 19) Information display (pages 14, 15, 19) Rear panel... -
Page 18: Remote Control
Remote control A (Power) (page 11) Remote control signal transmitter (page 9) OPEN/CLOSE (page 12) PROGRAM (page 14) REPEAT (page 14) DIMMER (page 15) RANDOM (page 14) A/B (page 15) DISPLAY (page 15) Numeric keys (pages 12, 14) CLEAR (page 14) ENTER (page 14) (Search backward), (Search forward) (pages 12, 13) -
Page 19: Advanced Settings
Advanced settings This section explains how to configure various advanced functions. You can configure Playback Mode Memory (PLAY MEM) most of these settings from the front panel. (Some settings require remote control operation.) With this function enabled, the unit retains the Repeat playback and Random-sequence playback settings even after the power to the unit is turned off. -
Page 20: Supported File Formats/Discs/Usb Flash Drives
Supported file formats/discs/USB flash drives ❑ ❑ Supported file formats Supported discs Please use discs with the following logos. Bit depth Bitrate Number of File Sampling frequency (kHz) Compact discs (audio CDs) (bit) (kbps) channels 32/44.1/48 — 32-320 32/44.1/48 — 48-192 CD-R and CD-RW discs 32/44.1/48... -
Page 21: Specifications
Europe and U.K. models ..............AC 230 V, 50 Hz • Yamaha and its dealers are not responsible for the loss of any data stored on a USB flash drive that Asia and General models ............AC 110-240 V, 50/60 Hz is connected to this unit. -
Page 22: Troubleshooting
Refer to the table below if the unit fails to function properly. If your problem is not listed below, or if the symptoms persist after you follow the instructions below, turn off the power to the unit by pressing A (Power) on the front panel, disconnect the power cord, and contact your nearest authorized Yamaha dealer or service center. - Page 23 Problem Cause Solution Page Connect the RCA stereo cable firmly. If the symptom does not improve, Buzzing or hum noise is heard. The RCA stereo cable is not connected firmly. check to see whether the cable itself is defective. Relocate the unit farther away from the tuner, or turn off the power to Noise in the tuner The unit is located close to the tuner.
- Page 24 Software licenses This product uses the following software. Licences de logiciel Ce produit utilise le logiciel suivant. FLAC Copyright © 2000–2009 Josh Coalson Copyright © 2011–2021 Xiph.Org Foundation Redistribution and use in source and binary forms, with or without modification, are permitted provided that the following conditions are met: - Redistributions of source code must retain the above copyright notice, this list of conditions and the following disclaimer.
- Page 25 Yamaha Global Site https://www.yamaha.com/ Yamaha Downloads https://download.yamaha.com/ Manual Development Group © 2021 Yamaha Corporation Published 09/2021 IPOD-B0 VFG4170 10-1 Nakazawa-cho, Naka-ku, Hamamatsu, 430-8650 Japan...
- Page 26 Download the firmware. Check the version number of the latest firmware uploaded on the product pages of Yamaha website. Download the firmware to update only if it is newer than that of the unit. Save the firmware data file to the USB flash drive.
- Page 27 Updating the firmware Troubleshooting Operate the unit to update the firmware. If the “UPGRADE” stays on the information display for Press CD/USB to switch to USB mode. one minute or longer Connect the USB flash drive to the USB jack on the front panel. The update process might have failed.
