Wireless Headphones
User's Guide for Model IAHB239 v2847-01
Features
• Bluetooth Wireless:
range - 33 ft.
• Built-in microphone
• Aux in (3.5mm audio
input)
• Folding adjustable
headband
• On-ear controls
• Voice prompts
announce headphone
operations
• Built-in rechargeable
lithium ion battery
• Battery life - approx. 6
hrs at 50% volume
• Micro-USB port for
battery recharge
Press to adjust volume.
Press and hold to skip tracks.
Play / Pause / Speakerphone
Press to play or pause audio.
Press to answer incoming phone call.
To manually pair Bluetooth, press and hold
until the indicator light begins rapidly
Battery Charging
Initial charge time is approximately 2 hours. Charge
fully before use. The low battery indicator will flash for
3 minutes, then the unit will automatically power OFF.
Using a Micro-USB to USB cable (included), connect to
the USB port of a powered on computer or USB power
adaptor (not included) to charge the unit.
Includes
• 3.5mm audio cable
• Micro-USB to USB
charging cable
Power
Press and hold to
power ON or OFF
Volume/Skip
Pair
flashing red and blue
DC Power Input
(3.5mm audio input)
Aux In
Microphone/
Indicator LED
STATUS
Power On
Flashing red / blue light
Charging
Charging Complete
Pairing
Flashing red / blue light
Pairing Complete
INDICATOR
Solid red light
Light OFF
Flashing blue light
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for iLive IAHB239
Summary of Contents for iLive IAHB239
- Page 1 Wireless Headphones User’s Guide for Model IAHB239 v2847-01 Features Includes • Bluetooth Wireless: • 3.5mm audio cable range - 33 ft. • Micro-USB to USB • Built-in microphone charging cable • Aux in (3.5mm audio input) • Folding adjustable headband • On-ear controls • Voice prompts announce headphone operations Power • Built-in rechargeable lithium ion battery Press and hold to • Battery life - approx. 6 power ON or OFF hrs at 50% volume • Micro-USB port for...
- Page 2 To download this User’s Guide in English, Spanish, or French, 1. Power on the headphones by pressing and or to get answers to frequently asked questions, visit the holding the button. The headphones will support section at: www.iLiveElectronics.com power ON in Bluetooth Mode and are ready to Para descargar este Manual del Usuario en inglés, español y francés, o para obtener respuestas a preguntas frecuentes, pair automatically. When pairing, remain within 3 visite la sección de apoyo en: www.iLiveElectronics.com feet of the Bluetooth device. Pour télécharger ce guide de l’utilisateur en anglais, espagnol 2. Using the controls on your Bluetooth device, ou français, ou pour obtenir des réponses à des questions select IAHB239 in the Bluetooth Settings to pair. fréquemment posées, consultez la rubrique d’assistance sur: If need be, refer to the user’s manual for your www.iLiveElectronics.com specific device for more information. Copyright © 2019 Digital Products International (DPI, Inc.). 3. When successfully paired, a voice will announce, All other trademarks appearing herein are the property of their respective owners. “Bluetooth is connected.” Your Bluetooth device Specifications are subject to change without notice. will now be heard through the headphones. 4. Use the controls on the connected Bluetooth FCC Warnings device to select and play audio. Use the WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the...
- Page 3 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement.
