HOMCOM 370-006 Owner's Manual page 7

Assembly Steps
2. Fender assembly
Front
Fender
5x25
Ø
screw
3. Front wheel assembly
4 Handle bar assembly
Iron bush
Ø8 nut
5x25
Ø
screw
Ø10nut
Bush
Front axle
Front wheel
Bush
Ø10nut
M8x140 bolt
Iron bush
● Remove the front axle, bush, 2*Ø10 nut
from the handle bar.
● Fit the fender into the handle bar.
● Secure it with a Ø5x25 screw. Repeat for
the other side.
● Insert the front wheel into the handle bar.
● Place a bush on the hole in the middle of
the front wheel ,repeat for the other side.
● Insert the front axle through the handle bar,
bush*2, and front wheel.
● Tighten a Ø10 nut(do not over tighten).
Repeat for the other side.
● Remove the M8x140 bolt , Iron bush *2 ,
and Ø8 nut from the handle bar.
● Fit the handle bar into the vehicle body.
● Slide a iron bush onto the M8x140 bolt.
● Insert the M8x140 bolt into the hole on
vehicle body.
● Slide another iron bush and tighten the Ø8
nut on downside.
