Summary of Contents for JB Systems ROTOGOBO ZOOM

  • Page 3: Before Use

    ENGLISH USER MANUAL OPERATION MANUAL ® Thank you for buying this JB SYSTEMS product. To take full advantage of all possibilities and for your own safety, please read these operating instructions very carefully before you start using this unit. FEATURES •...

  • Page 4: Safety Instructions

    Please use the original packing when the device is to be transported. • Due to safety reasons it is prohibited to make unauthorized modifications to the unit. Important: Never look directly into the light source! JB SYSTEMS ROTOGOBO ZOOM ®...

  • Page 5: Overhead Rigging

    + DMX XLR-cables are optionally available) 3. Safety eye: here you can attach an optional safety cable when you are rigging the ROTOGOBO ZOOM in a light bridge. 4. DMX INPUT: 3pin male XLR-connector used to connect the projector with the DMX controller or with the previous unit in the DMX chain.

  • Page 6: Setup Menu

    • Connect the DMX output of the master unit to the input of the first Slave unit. • Connect the DMX output of the first Slave unit to the input of the second Slave unit, etc. • Make the desired settings in the master unit (dimming, rotation speed, etc…) JB SYSTEMS ROTOGOBO ZOOM ®...
  • Page 7 128-159 Pulse effect (slow to fast) 160-191 Led ON 192-223 Random Strobe (slow to fast) 224-255 Led ON Note: rotation on/off, rotation speed and direction of the rotation can be adapted in the setup menu. JB SYSTEMS ROTOGOBO ZOOM ®...
  • Page 8 • Press the GOBO HOLDER (14) gently back in the housing • Turn the GOBO LOCK knob (13) over 90° clockwise. • Done! Note: if you want to print the gobos yourself, please download the instructions from the product page on our website. (www.jb-systems.eu JB SYSTEMS ROTOGOBO ZOOM ®...

  • Page 9: Maintenance

    External diameter = 25.7mm / image = 19mm / thickness = max 1mm Size: 500x150x100mm Weight: 3 kg Every information is subject to change without prior notice You can download the latest version of this user manual on our website: www.jb-systems.eu JB SYSTEMS ROTOGOBO ZOOM ®...
