- Page 15 Option 1: Mounted with the Q Home system. Note: If mounted outside the Droplet should be Option 2: Option 3: enclosed in a suitable Mounted with the electrical Mounted within the home enclosure. switchboard. (ensure near the home internet router. installation complies with AS3000)
- Page 16 Option 1: Option 2: Connect the Micro USB power pack to the micro USB Connection via a switchboard DIN mounted 240vAC to port of the Droplet and plug the power pack into a 240v a 5vDC power supply using a micro USB connection GPO.
- Page 17 Connect the Droplet to the internet by ethernet to the home router Connect the Droplet to the Q Home System using a USB Ethernet adaptor. (USB adaptor included. Ethernet cables not included)
- Page 18 Connect the Droplet to the internet using an Ethernet cable to the home router. Connect the Droplet to the Q Home System using an Ethernet cable to the home router. (USB adaptor included. Ethernet cables not included)
- Page 19 Connect the Droplet to the internet by Wi-Fi to the home router. To do this you will need to down load the SwitchDin Installer App from Apple App Store or from Google Play. Connect the Droplet to the Q Home System using a USB Ethernet adaptor.
- Page 20 Connect the Droplet to the internet using a 3G / 4G Modem. Connect the Droplet to the Q Home System using a USB Ethernet adaptor. (USB adaptor included. Ethernet cables not included)
- Page 21 The Droplet comes Q Home configured and is simply plug and play. If you are a SwitchDin Trained Q Home Installer, you will be able to set up a new user unit within StormCloud. If you haven’t received SwitchDin training you will need to contact SwitchDin Customer Support for assistance.
