  • Page 1 User manual © STid – MU_SWEDGE_V1.11_EN...

  • Page 2: Acknowledgment

    Welcome in the world of the identification! You have just purchased SWEDGE software. We thank you for your trust and hope that this solution developed by STid will be to your entire satisfaction. We remain at your disposal for any question.

  • Page 3: Table Of Contents

    STR-W45-E/U04-5AA STR-W55-E/U04-5AA STR-R35-E/PH5-5AB, STR-R32-E/PH5-5AB, ARC-R35-G/PH5-5AB, ARCS-R35-G/PH5-5AB ARCS-R35-G/BT1-5AB ARC-R35-L/L 2-5AB ARC-W55-G/U04-5AA ARC-W45-G/U04-5AA 4. FORMAT SETTINGS APPENDIX: COMMUNICATION PROTOCOL ISO2 C &D LOCK ATA PROTOCOLS ISO 2B ISO 2H IEGAND PROTOCOLS IEGAND IEGAND IEGAND IEGAND IEGAND HISTORY REVISIONS © STid – MU_SWEDGE_V1.11_EN...

  • Page 4: Informations

    • 50 Mo of free memory on hard disk USB Key Content • USB FTDI driver for Windows 7, 8 or 10. • Swedge Version 1.4.x Required hardware • STid Desktop reader ✓ STR-R35-E/Ph5-5AB (13.56 MHz) Or STR-R35-B/x03-5X (13.56 MHz) Or ARC-R35-G/PH5-5AB (13.56 MHz)
  • Page 5 © STid – MU_SWEDGE_V1.11_EN...

  • Page 6: Installation

    Installation Insert the SWEDGE USB Key on an USB port of your PC. Wait for the automatic opening of the browser window. Launch SWedgeV14x_setup.exe . Follow the instructions on the screen. Connect the reader: In case of STR-W1x-A/E01-5G: the green LED will be lighted at the moment •...

  • Page 7: Starting Software

    If you do not have administrator rights, you must execute SWEDGE with ”Run as administrator”. SWEDGE allows keyboard emulation when a tag is presented to the reader and a formatting of it according the parameters of the software. Caution The Caps Lock key must be enabled.

  • Page 8: Settings

    STR-W45-E/U04-5AA STR-R35-B/x03-5X STR-W55-E/U04-5AA ARC-R35-G/PH5-5AB ARC-W55-G/U04-5AA ARC-R35-L/Le2-5AB ARC-W45-G/U04-5AA ARCS-R35-G/PH5-5AB ARCS-R35-G/BT1-5AB STR-W15-A/E01-5G STR-W12-A/E01-5G STR-R32-E/Ph5-5AB STR-R32-B/x03-5X Caution It is important to install the USB driver provided with the software in the CD. You can download new driver on http://www.ftdichip.com/Drivers/VCP.htm. © STid – MU_SWEDGE_V1.11_EN...
  • Page 9 Beep after every Activate beep after each identifier reading. read event Caps Lock Activate caps locks. UserProfile Unchecked box: The settings file Swedge.ini is saved in the directory containing the executable, by default: C:\Program Files (x86)\STid\SWedge v1.3.x.File content: [SWEDGE] UserProfile=0 ComPort=COM10 ComBaudrate=115200...
  • Page 10 Checked box: Warning: SWEDGE must be run in administrator mode to activate this option. The settings file Swedge.ini is save in the user: C:\Users\username\STid\Swedge\Swedge.ini. File content: [SWEDGE] ComPort=COM10 ComBaudrate=115200 ReaderType=0 HexDec=0 Truncate=0 Size=32 CRLF=0 MSB=0 AntiRep=0 AntiRepTimeout=0 AutoStart=0 AutoRun=0 HideWhenWorking=0...

  • Page 11: Reader Configuration

    3. Reader Configuration If the reader was not purchased in a kit SWEDGE, it is necessary to configure it to work with the software. STR-R35-B/x03-5X and STR-R32-B/x03-5X These readers require no special configuration before use with SWEDGE. The reader reads the chip serial number in hexadecimal and sends it to SWEDGE on UID tag format.

  • Page 12: Str-W45-E/U04-5Aa And Str-W55-E/U04-5Aa

    • Checking: present an EPC1 GEN2 card on the reader, it must read continuously (beeps). The reader reads the chip serial number in hexadecimal and sends it to SWEDGE on a 96 bits frame (12 bytes). © STid – MU_SWEDGE_V1.11_EN...
  • Page 13 © STid – MU_SWEDGE_V1.11_EN...

  • Page 14: Arcs-R35-G/Bt1-5Ab

    These readers are configurable with configuration card create with SECard. Below are the parameters to select in SECard to configure the reader for operation with SWEDGE: Select the type of reader R32 or R35 • Serial settings • © STid – MU_SWEDGE_V1.11_EN...
  • Page 15 Configuring chip data to read: either UID in this case select for all chips UID and MSB First, • either Private ID. © STid – MU_SWEDGE_V1.11_EN...

  • Page 16: Arc-R35-L/Le2-5Ab

    ARC-R35-L/Le2-5AB These readers are configurable by serial link with SEGiC. Below are the parameters to select in SEGIC to configure the reader for operation with SWEDGE: Select the type of reader R35 • Reader communication protocol • © STid – MU_SWEDGE_V1.11_EN...

  • Page 17: Arc-W55-G/U04-5Aa Arc-W45-G/U04-5Aa

    Make sure there are no tags near the reader during the setup phase. SWEDGE Enroller mode is the main mode of use with SWEDGE software. The " Encoder " mode allows to switch the reader to write mode for use with STid's SESPRO and ULTRYS v2 softwares.

  • Page 18: Format Settings

    Choose the data type decimal or hexadecimal. If activated, SWEDGE will do a return after each reading. If activated, SWEDGE not return the read code as it will be identical to the preceding and during the timing sets. Selects if the SWEDGE truncates the data before decimal conversion or after (only available if the data type selected is DEC).
  • Page 19 For Wiegand 3i, Clock&Data 2H and 2B, the field Truncate is configurable to the needs. Supplement by Left or Right Used to force character(s) before or after the data to read. Previous example with forced AA before: © STid – MU_SWEDGE_V1.11_EN...

  • Page 20: Appendix: Communication Protocol

    0000 1 1000 0 0000 1 1010 1 ..0110 1 0100 0 1110 0 1000 0 1111 1 0010 1 000... Zeros Car.1 Car.2 Car.3 Car.4 Car…. Car.7 Car.8 Car.9 Car.10 Zeros © STid – MU_SWEDGE_V1.11_EN...

  • Page 21: Wiegand Protocols

    1 control character (XOR of all digits) ➢ For a hexadecimal ID”0x01001950C3”, the frame sent by the reader will be: 0000 0001 0000 0000 0001 1001 0101 0000 1100 0011 0011 Car.1 Car.2 Car.3 Car.4 Car.5 Car.6 Car.7 Car.8 Car.9 Car.10 © STid – MU_SWEDGE_V1.11_EN...

  • Page 22: Wiegand 3La

    ➢ Odd parity: 1 bit of odd parity on the 12 previous bits For a hexadecimal ID”0x0FC350”: The frame sent by the reader will be: 0000 1111 1100 0011 0101 0000 Parity Car.1 Car.2 Car.3 Car.4 Car.5 Car.6 Parity The data formatted is: 01550000. © STid – MU_SWEDGE_V1.11_EN...

  • Page 23: History Revisions

    Defaut Configuration changed 7bytes instead 5 bytes for STR R35 E & ARC R35 G. ARC-R35L/Le2-5AB added, In Settings User Profile added, Predefined protocols added, 24/04/2015 Supplement by added. 15/10/2018 1.10 ARCS-R35G/PH5-5AB & ARCS-R35G/BT1-5AB added, USB key instead of CD ROM 26/102020 1.11 ARC-W55-G/U04-5AA, ARC-W45-G/U04-5AA added © STid – MU_SWEDGE_V1.11_EN...
