Page 2 Acknowledgment Welcome to the world of high security! You have purchased ULTRYS software; it will allow you to configure SPECTRE readers, encode user cards and vehicle tags. We would like to thank you for the confidence you place in us and we hope that this solution developed by STid will keep you satisfied.
Page 3: Table Of Contents
INFORMATION ............................6 ..............................6 REQUIREMENTS USB K ..............................6 ONTENT ............................... 6 ARDWARE REQUIRED ............................7 INDOWS NSTALLATION ULTRYS / R ....................7 OMPATIBILITY EADER ANGE ULTRYS / F ....................... 7 OMPATIBILITY IRMWARE READER ................................8 VERVIEW ..................................9 READERS CONFIGURABLE ........................11...
Page 4 Step 2- Configuration protection loaded into the reader ................221 Step 3- Reader configuration ........................222 Step 4- Antenna type selection ........................224 Step 5- Installation configuration ........................ 224 Step 6- Light indicator configuration ......................235 Step 7- Reading & communication parameters ................... 236 © STid – MU_ULTRYS_V3.0_EN...
Page 5 IEGAND Wiegand 3i ..............................293 WIEGAND 3Ca .............................. 294 WIEGAND 3Cb .............................. 294 WIEGAND 3La .............................. 295 WIEGAND 3Lb .............................. 295 Wiegand 3Eb ..............................296 Wiegand 3W ..............................296 Wiegand 3V ..............................296 REVISION ............................297 © STid – MU_ULTRYS_V3.0_EN...
Page 6: Information
• USB cable provided with SLA and SMA to directly configure the reader via USB link. • STid UHF 866-915 MHZ encoder to encode UHF SCB/OCB configuration card: Part number: ARC-Wx5-G/U04-5AA/1 STR-Wx5-E/U04-5AA/1 (v10 firmware version required*) GAD-Wx5-E/U04-5AA/1 (v08 firmware version required*) •...
Page 7: Windows Installation
Windows Installation 1. Insert the ULTRYS v2 USB stick on an USB port of your PC. 2. Wait for the automatic opening of the browser window. 3. Launch ULTRYS V2.x.x_setup.exe. 4. Follow the instructions on the screen. Compatibility ULTRYS / Reader Range / User IDs This ULTRYS version (3.x.x) allows you to configure SPECTRE, SPECTRE NANO, ATX and...
Page 8: Overview
❖ The software is divided into three distinct parts: ULTRYS settings Readers configuration User credentials ❖ On the Home page, you can select the language (English, Spanish, French) and click on the link for user manual. © STid – MU_ULTRYS_V3.0_EN...
Page 9: Open
At the first opening no file is loaded by default. ULTRYS is directly open on the home page. This mention indicates the current configuration. At the next opening, ULTRYS will automatically load the last loaded configuration file. Two possible cases: The loaded file is the one to use The loaded file is not the one to use ©...
Page 10 3. Enter the profile password if there is one. 4. Please confirm. 5. ULTRYS loads the file and opens the home page. case the loaded file is not the one to use Cancel. 2- ULTRYS is open on the...
Page 11: Readers Configurable
SNA-Rx2-A-BT4-5AB SPECTRE NANO READ ONLY SNA-Rx3-A-BT4-7AB SNA-Wx3-A-BT4-7OS SPECTRE NANO OSDP ATX-Rx1-A-U04-xx SPECTRE ATX READ ONLY ATX-Rx2-A-U04-5AB ATX-Rx3-A-U04-7AB SPECTRE ATX OSDP ATX -Wx3-A-U04-7OS ATX4-Rx1-A-U04-xx ATX4-Rx2-A-U04-5AB SPECTRE ATX 4 READ ONLY ATX4-Rx3-A-U04-7AB SPECTRE ATX 4 OSDP ATX4 -Wx3-A-U04-7OS © STid – MU_ULTRYS_V3.0_EN...
Page 13: Reader Configuration Spectre Read Only
SPECTRE READ ONLY 3. Reader configuration SPECTRE READ ONLY 3-1 ULTRYS settings ➢ Connect the SPECTRE reader to the PC using the provided USB cable to load the configuration via serial link directly onto the reader. ➢ Connect an UHF encoder to the PC to load the configuration onto UHF SCB configuration card.
Page 14 Check the compatibility of the reader. Check the USB cable. Check the Baudrate reader: it must be fixed to 115200. Note: during the connectivity test on a UHF encoder, a sound and light signal (orange) will be emitted for 1 second. © STid – MU_ULTRYS_V3.0_EN...
Page 15: Create New Configuration
The reader configuration is done in 9 steps. To move from one stage to another, you must click on “Next”. UHF frequency band regulation Configuration protection loaded into the reader Reader configuration Antenna type selection Installation configuration Light indicator configuration Reading & communication parameters User Security Roles Configuration save and protect © STid – MU_ULTRYS_V3.0_EN...
Page 16: Step 1- Uhf Frequency Band Regulation
Type the first characters to display a country or select the country in which the installation will be done. For a country which is not in the list, please contact STid: support@stid.com. To approve the feasibility to install your reader in the selected country, you can check the compatibility.
Page 17 Check the USB cable Check the communication with reader With reader part number Enter the first 5 characters of the reader part number Example: SLAR41, SLAR51, SMAR43… Message: OK Message: the reference reader is not compatible with regulation selected. © STid – MU_ULTRYS_V3.0_EN...
Page 18: Step 2- Configuration Protection Loaded Into The Reader
If you lose this protection code, you won’t be able to reconfigure the reader again and the reader must be reset at the factory. To change the protection code, it will be necessary to know the current protection code. © STid – MU_ULTRYS_V3.0_EN...
Page 19: Step 3- Reader Configuration
You must select the firmware version that is compatible with your reader. To do so, you can manually select the reader and firmware version, or you can use the function "Auto detection – Connect and check my reader configuration". © STid – MU_ULTRYS_V3.0_EN...
Page 20 Message : NOK Check the USB cable Check the communication with reader With reader’s number reference Enter the first 6 characters of your reader’s reference number. Examples: SLAR41, SLAR51, SMAR41 Message: NOK Check your reader’s reference number. © STid – MU_ULTRYS_V3.0_EN...
Page 21: Step 4- Antenna Type Selection
SPECTRE READ ONLY Step 4- Antenna type selection The SPECTRE reader can be connected to new SPECTRE antennas (ANT-UHF2), or previous antennas (ANT_URD). Select the type of antenna used in the installation and compatible with the reader selected. © STid – MU_ULTRYS_V3.0_EN...
Page 22: Step 5- Installation Configuration With Spectre Antenna
Use ‘Add /Delete lane’ to configure the number of lanes you will use in your application. The default setting is one antenna on the first lane. For more information about the possible combination please refer to the document NA_SPECTRE. © STid – MU_ULTRYS_V3.0_EN...
Page 23 RF ports are assigned in order to add the antennas in the configuration wizard. When an antenna is removed from the configuration, the RF port connection for other antennas does not change. Example: Ant 2 deleted from lane 1 and added to lane 2. © STid – MU_ULTRYS_V3.0_EN...
Page 24 Select the cable length for each antenna For each antenna, select the cable length you would like to use between antenna and reader. Only the first Antenna of the lane 1 can be lean against the reader. © STid – MU_ULTRYS_V3.0_EN...
Page 25 Ex: RSSI filter= -49dBm + Reversal not selected A tag that will have a RSSI value of -20dBm will be sent back, A tag that will have a RSSI value of -60dBm will not be sent back. © STid – MU_ULTRYS_V3.0_EN...
Page 26 Scan time, EPC filter and RRSI filter settings are the same for antennas on the same lane. The cable length and RF power antenna are set for each antenna. Example 1: 4 antennas on lane 1. Example 2: 2 antennas on lane 1 et 2 antennes on lane 2. © STid – MU_ULTRYS_V3.0_EN...
Page 27 Tag 3: AA 02 AB CD 00 00 00 00 00 00 00 03 Tag 4: AA 02 FF FF 00 00 00 00 00 00 00 03 Tags 1, 2 and 3 are not transmitted. Only tag 4 is transmitted. © STid – MU_ULTRYS_V3.0_EN...
Page 28 Both types of output are « Pull up to V+ » or « Open drain ». Status of outputs: select for each output the default state ‘Open’ or ‘Closed’ and if the state is maintained during the detection process. © STid – MU_ULTRYS_V3.0_EN...
Page 29 SPECTRE READ ONLY Reading mode = Continuous reading without using inputs In this mode, the reader scan continuously. There is no action on input activation. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0_EN...
Page 30 If an Input is activated (In1, In2, In3 or In4), the reader scans on all lanes set. The duration of the reading is defined in ‘Advanced settings’. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0_EN...
Page 31 Reading mode = Trigger of the reading on the event lane If an Input is activated, the reader scans on the corresponding lane. The reading duration is defined in ‘Advanced settings’. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0_EN...
Page 32 On lane 2 there are four antennas, an action on Input2 activates the LED on each ▪ antenna during 250 ms. The LED ‘Customized event’ color is defined on step 6: Setting up light indicator. Nothing to do. © STid – MU_ULTRYS_V3.0_EN...
Page 33 SPECTRE READ ONLY Reading mode = Output activation (triggered on outputs) An action on Input toggles the corresponding output regardless of RF function of the reader. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0_EN...
Page 34 The output state is only activation Input toggles the linked to a user action on (triggered on corresponding the input. outputs) output. Note: as long as the action is detected on the input, the output remains toggled. © STid – MU_ULTRYS_V3.0_EN...
Page 35: Step 6- Light Indicator Configuration
This LED lights when a tag is detected by the antenna. Customized event*: By default, there is no color. LED brightness: The LED brightness can be adjusted by step of 10% (from 10% to 100%) LED color: © STid – MU_ULTRYS_V3.0_EN...
Page 36 SPECTRE READ ONLY * The LED ‘Customized event’ only appears if ‘Reading Mode’ = Continuous reading + custom LED lighting. Default display: © STid – MU_ULTRYS_V3.0_EN...
Page 37: Step 7- Reading & Communication Parameters
Note: After setting an EPC security key, if you return to step 5 with the Previous button, and you set an EPC filter, then returning to step 7, the "EPC ID Security" checkmark is displayed. in gray, the key field is still accessible but not taken into account. © STid – MU_ULTRYS_V3.0_EN...
Page 38 SPECTRE READ ONLY The displays depend on the Ultrys version chosen in step 3. Firmware =7.0 Firmware >=9.0 RS232 / RS485 Serial frame: 1 byte X bytes 1 byte 1 byte 1 byte 1 byte Data* *Doubled if the ASCII option is activated.
Page 39 SPECTRE READ ONLY Wiegand 26 bits- 3i Note: the graphic indicating the lanes, depends on the configuration of the number of antennas/lanes. Wiegand with LRC customized size Wiegand customized size Decimal Clock&Data – Iso 2B © STid – MU_ULTRYS_V3.0_EN...
Page 40 • : ID feedback = WW XX YY ZZ • : ID feedback = ZZ YY XX WW • : ID feedback = AA BB CC DD • : ID feedback = DD CC BB AA © STid – MU_ULTRYS_V3.0_EN...
Page 41 SPECTRE READ ONLY The reader emits the credential code present in the field only once during this time. This time is adjustable from 0 to 30 seconds. © STid – MU_ULTRYS_V3.0_EN...
Page 42: Step 8- User Security Roles
SPECTRE READ ONLY Step 8- User Security Roles ULTRYS allows to manage three different profiles by configuration file. Define an Administrator password to protect the configuration file. Define a User 1 password and select the corresponding rights. Define a User 2 password and select the corresponding rights.
Page 43: Step 9- Configuration Save And Protect
To protect the configuration file, you can define a password. This password is different from Administrator password. Select a directory and a file name to save. The name and location of ‘Configuration Loaded’ indicates now the chosen name and location. © STid – MU_ULTRYS_V3.0_EN...
Page 44 SPECTRE READ ONLY Get a summary of the configuration created. Print: allows printing of configuration information on a network, local or virtual printer (PDF). © STid – MU_ULTRYS_V3.0_EN...
Page 45: Reader Configuration Spectre Osdp
SPECTRE OSDP 4. Reader configuration SPECTRE OSDP™ 4-1 ULTRYS settings ➢ Connect the SPECTRE reader to the PC using the provided USB cable to load the configuration via serial link directly onto the reader. ➢ Connect an UHF encoder to the PC to load the configuration onto UHF OCB configuration card.
Page 46 Check the compatibility of the reader. Check the USB cable. Check the Baudrate reader: it must be fixed to 115200. Note: during the connectivity test on a UHF encoder, a sound and light signal (orange) will be emitted for 1 second. © STid – MU_ULTRYS_V3.0_EN...
Page 47: Create New Configuration
UHF frequency band regulation Configuration protection loaded into the reader Reader configuration Step 4 does not exist in the SPECTRE OSDP setup wizard Installation configuration Light indicator configuration Reading & communication parameters User Security Roles Configuration save and protect © STid – MU_ULTRYS_V3.0_EN...
Page 48: Step 1- Uhf Frequency Band Regulation
Type the first characters to display a country or select the country in which the installation will be done. For a country which is not in the list, please contact STid: support@stid.com. To approve the feasibility to install your reader in the selected country, you can check the compatibility.
Page 49 Check the communication with reader With reader part number Enter the first 5 characters of the reader part number Example: SLAW43, SLAW53, SMAW43, SMAW53… Message: OK Message: the reference reader is not compatible with regulation selected. © STid – MU_ULTRYS_V3.0_EN...
Page 50: Step 2- Configuration Protection Loaded Into The Reader
If you lose this protection code, you won’t be able to reconfigure the reader again and the reader must be reset at the factory. To change the protection code, it will be necessary to know the current protection code. © STid – MU_ULTRYS_V3.0_EN...
Page 51: Step 3- Reader Configuration
You must select the firmware version that is compatible with your reader. To do so, you can manually select the reader and firmware version, or you can use the function "Auto detection – Connect and check my reader configuration". © STid – MU_ULTRYS_V3.0_EN...
Page 52 4- Click on Confirm. Message: NOK Check the USB cable Check the communication with reader With reader’s number reference Enter the first 6 characters of your reader’s reference number Examples: SLAW43, SLAW53 Message: NOK Check your reader’s reference number © STid – MU_ULTRYS_V3.0_EN...
Page 53: Step 4- Antenna Type Selection
Use ‘Add /Delete lane’ to configure the number of lanes you will use in your application. The default setting is one antenna on the first lane. For more information about the possible combination please refer to the document NA_SPECTRE. © STid – MU_ULTRYS_V3.0_EN...
Page 55 RF ports are assigned in order to add the antennas in the configuration wizard. When an antenna is removed from the configuration, the RF port connection for other antennas does not change. Example: Ant 2 deleted from lane 1 and added to lane 2. © STid – MU_ULTRYS_V3.0_EN...
Page 56 Select the cable length for each antenna For each antenna, select the cable length you would like to use between antenna and reader. Only the first Antenna of the lane 1 can be lean against the reader. © STid – MU_ULTRYS_V3.0_EN...
Page 57 A tag that will have a RSSI value of -60dBm will not be sent back. Scan time, EPC filter and RRSI filter settings are the same for antennas on the same lane. The cable length and RF power antenna are set for each antenna. © STid – MU_ULTRYS_V3.0_EN...
Page 58 SPECTRE OSDP Example 1: 4 antennas on lane 1. Example 2: 2 antennas on lane 1 et 2 antennes on lane 2. © STid – MU_ULTRYS_V3.0_EN...
Page 59 Tag 3: AA 02 AB CD 00 00 00 00 00 00 00 03 Tag 4: AA 02 FF FF 00 00 00 00 00 00 00 03 Tags 1, 2 and 3 are not transmitted. Only tag 4 is transmitted. © STid – MU_ULTRYS_V3.0_EN...
Page 60 Both types of output are « Pull up to V+ » or « Open drain ». Status of outputs: select for each output the default state ‘Open’ or ‘Closed’ and if the state is maintained during the detection process. © STid – MU_ULTRYS_V3.0_EN...
Page 61 SPECTRE OSDP Reading mode = Continuous reading without using inputs In this mode, the reader scan continuously. There is no action on input activation. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0_EN...
Page 62 If an Input is activated (In1, In2, In3 or In4), the reader scans on all lanes set. The duration of the reading is defined in ‘Advanced settings’. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0_EN...
Page 63 Reading mode = Trigger of the reading on the event lane If an Input is activated, the reader scans on the corresponding lane. The reading duration is defined in ‘Advanced settings’. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0_EN...
Page 64 (physically on the BUS + 200ms Trigger of the An action on Input reading on the activates the scan by lane event lane on lane © STid – MU_ULTRYS_V3.0_EN...
Page 65: Step 6- Light Indicator Configuration
SPECTRE OSDP Step 6- Light indicator configuration Detecting user ID: This LED lights when a tag is detected by the antenna. Warning: An osdp_LED command cancels this color. LED color: © STid – MU_ULTRYS_V3.0_EN...
Page 66: Step 7- Reading & Communication Parameters
Note: After setting an EPC security key, if you return to step 5 with the Previous button, and you set an EPC filter, then returning to step 7, the "EPC ID Security" checkmark is displayed. in gray, the key field is still accessible but not taken into account. © STid – MU_ULTRYS_V3.0_EN...
Page 67 • : ID feedback = WW XX YY ZZ • : ID feedback = ZZ YY XX WW • : ID feedback = AA BB CC DD • : ID feedback = DD CC BB AA © STid – MU_ULTRYS_V3.0_EN...
Page 68 SPECTRE OSDP The reader emits the credential code present in the field only once during this time. This time is adjustable from 0 to 30 seconds. © STid – MU_ULTRYS_V3.0_EN...
Page 69: Step 8- User Security Roles
SPECTRE OSDP Step 8- User Security Roles ULTRYS allows to manage three different profiles by configuration file. Define an Administrator password to protect the configuration file. Define a User 1 password and select the corresponding rights. Define a User 2 password and select the corresponding rights.
Page 70 To protect the configuration file, you can define a password. This password is different from Administrator password. Select a directory and a file name to save. The name and location of ‘Configuration Loaded’ indicates now the chosen name and location. © STid – MU_ULTRYS_V3.0_EN...
Page 71 SPECTRE OSDP Get a summary of the configuration created. Print: allows printing of configuration information on a network, local or virtual printer (PDF). © STid – MU_ULTRYS_V3.0_EN...
Page 72: Spectre Nano Reader
SPECTRE NANO READER SPECTRE NANO READ ONLY SPECTRE NANO OSDP © STid – MU_ULTRYS_V3.0.1_EN...
Page 73: Reader Configuration Spectre Nano Read Only
SPECTRE NANO READ ONLY 5. Reader configuration SPECTRE NANO READ ONLY 5-1 ULTRYS settings ➢ Connect the SPECTRE NANO reader to the PC using the provided USB cable to load the configuration via serial link directly onto the reader. ➢ Connect an UHF encoder to the PC to load the configuration onto UHF SCB configuration card.
Page 74 Check the compatibility of the reader. Check the USB cable. Check the Baudrate reader: it must be fixed to 115200. Note: during the connectivity test on a UHF encoder, a sound and light signal (orange) will be emitted for 1 second. © STid – MU_ULTRYS_V3.0.1_EN...
Page 75: Create New Configuration
Configuration protection loaded into the reader Reader configuration Step 4 does not exist in the SPECTER NANO configuration wizard Installation configuration Light and sound indicator configuration Reading & communication parameters User Security Roles Configuration save and protect © STid – MU_ULTRYS_V3.0.1_EN...
Page 76: Step 1- Uhf Frequency Band Regulation Uhf
Type the first characters to display a country or select the country in which the installation will be done. For a country which is not in the list, please contact STid: support@stid.com. To approve the feasibility to install your reader in the selected country, you can check the compatibility.
Page 77 Check the USB cable Check the communication with reader With reader part number Enter the first 5 characters of the reader part number Example: SNAR41, SNAR51, SNAR42… Message: OK Message: the reference reader is not compatible with regulation selected. © STid – MU_ULTRYS_V3.0.1_EN...
Page 78: Step 2- Configuration Protection Loaded Into The Reader
If you lose this protection code, you won’t be able to reconfigure the reader again and the reader must be reset at the factory. To change the protection code, it will be necessary to know the current protection code. © STid – MU_ULTRYS_V3.0.1_EN...
Page 79: Step 3- Reader Configuration
You must select the firmware version that is compatible with your reader. To do so, you can manually select the reader and firmware version, or you can use the function "Auto detection – Connect and check my reader configuration". © STid – MU_ULTRYS_V3.0.1_EN...
Page 80: Step 4- Antenna Type Selection
Examples: SNAR41, SNAR51, Message: NOK Check your reader’s reference number. Step 4- Antenna type selection The SPECTER NANO reader works with an integrated antenna. Step 4 does not exist in the SPECTER NANO configuration wizard. © STid – MU_ULTRYS_V3.0.1_EN...
Page 81: Step 5- Installation Configuration
SPECTRE NANO READ ONLY Step 5- Installation configuration Name the lane Maximum 10 characters. For example, Entry1.… © STid – MU_ULTRYS_V3.0.1_EN...
Page 82 There are two possible displays of Step 1, depending on whether a Bluetooth® configuration is already defined or not: No existing configuration: The Step 1 screen is as follows Existing configuration: The Step 1 screen is as follows: © STid – MU_ULTRYS_V3.0.1_EN...
Page 83 Virtual access card parameters ® Step 1: Load a Bluetooth configuration (.pse) Warning: if a Bluetooth® configuration is already defined, loading a SECard (.pse) file will erase the current settings. 1- Click on ‘Load a Bluetooth ® configuration’ © STid – MU_ULTRYS_V3.0.1_EN...
Page 84 2- A window opens to select the desired configuration file. 3- Enter the passwords used when saving the SECard (.pse) file. Check the entry of the administrator Check the password entry password from the pse file © STid – MU_ULTRYS_V3.0.1_EN...
Page 85 SPECTRE NANO READ ONLY ® Step 2: Bluetooth configuration Some parameters are inherited from the .pse SECard configuration file and therefore cannot be changed. Modifiable parameters Non-modifiable inherited parameters © STid – MU_ULTRYS_V3.0.1_EN...
Page 86 SPECTRE NANO READ ONLY These parameters must be those used for encoding the Bluetooth ® virtual badge. © STid – MU_ULTRYS_V3.0.1_EN...
Page 87 SPECTRE NANO READ ONLY Name Configuration name: enter the name of the configuration Mobile ID. The name must be a maximum of 14 characters. The configuration name "Conf Mobile ID" is reserved for the STid Mobile ID configuration. ® Reading mode UHF or Reader configured to read UHF identifiers or Bluetooth®...
Page 88 SPECTRE NANO READ ONLY ® Bluetooth reading mode STid Mobile ID® can store 3 types of cards: Private ID Reader configured for private code reading only. Reader configured for private code reading. Private ID otherwise If this is not found or if the security settings are incorrect, then the reader will read and return the CSN.
Page 89 Two keys (R et W) Allows you to define the security keys used for Bluetooth data. ® The default keys are 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00. © STid – MU_ULTRYS_V3.0.1_EN...
Page 91 Remote control button active: If the "Remote" identification mode has been activated, allows you to associate the current configuration with the Remote 1 or Remote 2 button. Possibility to use the fields to name the buttons. © STid – MU_ULTRYS_V3.0.1_EN...
Page 92 If checked: the smartphone must be unlocked (with PIN code or other unlocking option depending on the smartphone) to authenticate with the reader. If unchecked: unlocking the smartphone is not required to authenticate with the reader. © STid – MU_ULTRYS_V3.0.1_EN...
Page 93 Unlock required required Configuration name Site code Prohibit Deletion: prohibit the deletion of the virtual access card by the user. Only the administrator, via SECard (Settings / Credits / Delete your virtual access card) can delete it. © STid – MU_ULTRYS_V3.0.1_EN...
Page 94 SPECTRE NANO READ ONLY Note: if the Bluetooth configuration is configured on STid Mobile ID CSN: ® ® Step 2: Step 3: Remote mode is not accessible. © STid – MU_ULTRYS_V3.0.1_EN...
Page 95 The LED sequence is repeated as long as the reader is switched on and stops if communication via the internal USB is established (for configuration for example) or if the reader is reconfigured using the BLE or if the system is restarted. © STid – MU_ULTRYS_V3.0.1_EN...
Page 96 Ex: RSSI filter= -49dBm + Reversal not selected A tag that will have a RSSI value of -20dBm will be sent back, A tag that will have a RSSI value of -60dBm will not be sent back. © STid – MU_ULTRYS_V3.0.1_EN...
Page 97 Tag 3: AA 02 AB CD 00 00 00 00 00 00 00 03 Tag 4: AA 02 FF FF 00 00 00 00 00 00 00 03 Tags 1, 2 and 3 are not transmitted. Only tag 4 is transmitted. © STid – MU_ULTRYS_V3.0.1_EN...
Page 98 Both types of output are « Pull up to V+ » or « Open drain ». Status of outputs: select for each output the default state ‘Open’ or ‘Closed’ and if the state is maintained during the detection process. © STid – MU_ULTRYS_V3.0.1_EN...
Page 99 SPECTRE NANO READ ONLY Reading mode = Continuous reading without using input In this mode, the reader scan continuously. There is no action on input activation. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 100 SPECTRE NANO READ ONLY Activate the relay on detection ‘OFF’. Activate the relay on detection ‘ON’: maintaining the relay as long as there is detection or for a fixed period of between 1s and 20s. © STid – MU_ULTRYS_V3.0.1_EN...
Page 101 Realy activation (triggered by the event) Possibility of activating the relay when an event is detected on the input, regardless of the reading of an identifier. At Step 3: it is no longer possible to activate the relay on detection. © STid – MU_ULTRYS_V3.0.1_EN...
Page 102 Select the output type and default state for output. Activate the relay on detection ‘OFF’. Activate the relay on detection ‘ON’: maintaining the relay as long as there is detection or for a fixed period of between 1s and 20s. © STid – MU_ULTRYS_V3.0.1_EN...
Page 103 RF detection and remains in this state as long as, at each scan is at least one detection Note: as long as the action is detected on the input, the output remains toggled. © STid – MU_ULTRYS_V3.0.1_EN...
Page 104: Step 6- Light And Sound Indicator Setting
The intensity of the LED is adjustable in 10% steps (from 10% to 100%). User ID upload: LED: Color indicating the detection of an identifier by the antenna. The intensity of the LED is adjustable in 10% steps (from 10% to 100%). Buzzer: OFF or ON+option : © STid – MU_ULTRYS_V3.0.1_EN...
Page 105 SPECTRE NANO READ ONLY Customized event*: LED lights if action on the input. Default set to no color / Buzzer OFF. LED: Color indicating the detection of an identifier by the antenna. Buzzer: OFF or ON+options : LED settings: © STid – MU_ULTRYS_V3.0.1_EN...
Page 106 SPECTRE NANO READ ONLY * The LED ‘Customized event’ only appears if ‘Reading Mode’ = Continuous reading + Activation de la LED personnalisée ». Display in other cases: © STid – MU_ULTRYS_V3.0.1_EN...
Page 108: Step 7- Reading & Communication Parameters
- A different private key for EPC and for Bluetooth ® - An identical private key for the EPC and for Bluetooth ® in this case, the value of the key is defined in the Bluetooth® configuration: © STid – MU_ULTRYS_V3.0.1_EN...
Page 109 The advanced options in this part depend on whether or not a Bluetooth® configuration is activated and the protocol chosen: Bluetooth ® Bluetooth ® Reading Output reading Advanced options activation mode protocol mode RS232 RS485 RS232 RS485 Other protocols © STid – MU_ULTRYS_V3.0.1_EN...
Page 110 Force the value defined in the field to the value of the CSN. The value of the code will be transmitted in high order on one or two bytes. The CSN can therefore be truncated depending on the size of the protocol used. © STid – MU_ULTRYS_V3.0.1_EN...
Page 111 If this option is activated, the Data will be sent in ASCII mode. Baud Rate 9600, 19200, 38400, 57600 ou 115200 bauds Size of the Size in plain mode Size in secure mode credential sent to the system 1 to 62 bytes 1 to 6 bytes (bytes) © STid – MU_ULTRYS_V3.0.1_EN...
Page 112 Fixed to 3b Fixed to 3b Wiegand with LRC custom size / 1b up to 16b 1b up to 6b Wiegand custom size Decimal Clock&Data – Iso 2B 1b up to 7b 1b up to 6b © STid – MU_ULTRYS_V3.0.1_EN...
Page 113 SPECTRE NANO READ ONLY Note: If the "ID size" of the Bluetooth data is greater than "Size of the credential sent to the ® system": Note: © STid – MU_ULTRYS_V3.0.1_EN...
Page 114 • : ID feedback = WW XX YY ZZ • : ID feedback = ZZ YY XX WW • : ID feedback = AA BB CC DD • : ID feedback = DD CC BB AA © STid – MU_ULTRYS_V3.0.1_EN...
Page 115 Size of the credential sent to the system: Data sent to the system: AABBCCDD Example 4 : ID encoded in the Tag: AABBCCDDEEFF001122334455 Formatting: ID Formated: DDCCBBAA Size of the credential sent to the system: Data sent to the system: DDCCBBAA © STid – MU_ULTRYS_V3.0.1_EN...
Page 116 SPECTRE NANO READ ONLY 2nd case: UHF data formatting before uploading to the system with an active Bluetooth ® configuration: Possibility to format the UHF ID manually (ditto case 1) or to use the Bluetooth data format. ® © STid – MU_ULTRYS_V3.0.1_EN...
Page 117 : If beyond the Timeout no valid Bluetooth ® identifier is read, the reader starts again in UHF scan. Bluetooth ® then UHF: If beyond the Timeout no valid UHF identifier is read, the reader starts again in Bluetooth scan. ® © STid – MU_ULTRYS_V3.0.1_EN...
Page 118: Step 8- User Security Roles
SPECTRE NANO READ ONLY Step 8- User Security Roles ULTRYS allows to manage three different profiles by configuration file. Define an Administrator password to protect the configuration file. Define a User 1 password and select the corresponding rights. Define a User 2 password and select the corresponding rights.
Page 119: Step 9- Configuration Save And Protect
Administrator password. If this option is enabled, the reader can only be configured again via the USB connection. Authorize ULTRYS to retrieve and open the reader and UHF parameters from the reader and the configuration card. See 11-Open an existing configuration.
Page 120 SPECTRE NANO READ ONLY Authorize ULTRYS to retrieve and open the reader and Bluetooth parameters from the ® reader and the configuration card. See 11-Open an existing configuration. Select a directory and a file name to save The name and location of ‘Configuration Loaded’ indicates now the chosen name and location.
Page 121 SPECTRE NANO READ ONLY Get a summary of the configuration created. Print: allows printing of configuration information on a network, local or virtual printer (PDF). © STid – MU_ULTRYS_V3.0.1_EN...
Page 122: Reader Configuration Spectre Nano Osdp
SPECTRE NANO OSDP 6. Reader configuration SPECTRE NANO OSDP™ 6-1 ULTRYS settings ➢ Connect the SPECTRE NANO reader to the PC using the provided USB cable to load the configuration via serial link directly onto the reader. ➢ Connect an UHF encoder to the PC to load the configuration onto UHF OCB configuration card.
Page 123 Check the compatibility of the reader. Check the USB cable. Check the Baudrate reader: it must be fixed to 115200. Note: during the connectivity test on a UHF encoder, a sound and light signal (orange) will be emitted for 1 second. © STid – MU_ULTRYS_V3.0.1_EN...
Page 124: Create New Configuration
Configuration protection loaded into the reader Reader configuration Step 4 does not exist in the SPECTRE NANO OSDP setup wizard Installation configuration Light and sound indicator settings Reading & communication parameters User Security Roles Configuration save and protect © STid – MU_ULTRYS_V3.0.1_EN...
Page 125: Step 1- Uhf Frequency Band Regulation
Type the first characters to display a country or select the country in which the installation will be done. For a country which is not in the list, please contact STid: support@stid.com. To approve the feasibility to install your reader in the selected country, you can check the compatibility.
Page 126 Check the USB cable Check the communication with reader With reader part number Enter the first 5 characters of the reader part number Example: SNAW43, SNAW53. Message: OK Message: the reference reader is not compatible with regulation selected. © STid – MU_ULTRYS_V3.0.1_EN...
Page 127: Step 2- Configuration Protection Loaded Into The Reader
If you lose this protection code, you won’t be able to reconfigure the reader again and the reader must be reset at the factory. To change the protection code, it will be necessary to know the current protection code. © STid – MU_ULTRYS_V3.0.1_EN...
Page 128: Step 3- Reader Configuration
You must select the firmware version that is compatible with your reader. To do so, you can manually select the reader and firmware version, or you can use the function "Auto detection – Connect and check my reader configuration". © STid – MU_ULTRYS_V3.0.1_EN...
Page 129: Step 4- Antenna Selection
Examples: SNAW43, SNAW53 Message: NOK Check your reader’s reference number Step 4- Antenna selection The SPECTER NANO reader works with an integrated antenna. Step 4 does not exist in the SPECTER OSDP™ setup wizard. © STid – MU_ULTRYS_V3.0.1_EN...
Page 130: Step 5- Installation Configuration
SPECTRE NANO OSDP Step 5- Installation configuration Name the lane Maximum 10 characters. For example, Entry1.… © STid – MU_ULTRYS_V3.0.1_EN...
Page 131 There are two possible displays of Step 1, depending on whether a Bluetooth® configuration is already defined or not: No existing configuration: The Step 1 screen is as follows Existing configuration: The Step 1 screen is as follows: © STid – MU_ULTRYS_V3.0.1_EN...
Page 132 Virtual access card parameters ® Step 1: Load a Bluetooth configuration (.pse) Warning: if a Bluetooth ® configuration is already defined, loading a SECard (.pse) file will erase the current settings. Click on ‘Load a Bluetooth ® configuration’ © STid – MU_ULTRYS_V3.0.1_EN...
Page 133 SPECTRE NANO OSDP A window opens to select the desired configuration file. 3- Enter the passwords used when saving the SECard (.pse) file. Check the entry of the administrator Check the password entry password from the pse file © STid – MU_ULTRYS_V3.0.1_EN...
Page 134 SPECTRE NANO OSDP ® Step 2: Bluetooth configuration Some parameters are inherited from the .pse SECard configuration file and therefore cannot be changed. Modifiable parameters Non-modifiable inherited parameters © STid – MU_ULTRYS_V3.0.1_EN...
Page 135 SPECTRE NANO OSDP These parameters must be those used for encoding the Bluetooth ® virtual badge. © STid – MU_ULTRYS_V3.0.1_EN...
Page 136 SPECTRE NANO OSDP Name Configuration name: enter the name of the configuration Mobile ID. The name must be a maximum of 14 characters. The configuration name "Conf Mobile ID" is reserved for the STid Mobile ID configuration. ® Reading mode UHF or Reader configured to read UHF identifiers or Bluetooth®...
Page 137 SPECTRE NANO OSDP ® Bluetooth reading mode STid Mobile ID® can store 3 types of cards: Private ID Reader configured for private code reading only. Private ID otherwise Reader configured for private code reading. If this is not found or if the security settings are incorrect, then the reader will read and return the CSN.
Page 138 Use a key to read and a key to write. Allows you to define the security keys used for Bluetooth data. ® The default keys are 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 © STid – MU_ULTRYS_V3.0.1_EN...
Page 140 Remote control button active: If the "Remote" identification mode has been activated, allows you to associate the current configuration with the Remote 1 or Remote 2 button. Possibility to use the fields to name the buttons. © STid – MU_ULTRYS_V3.0.1_EN...
Page 141 If checked: the smartphone must be unlocked (with PIN code or other unlocking option depending on the smartphone) to authenticate with the reader. If unchecked: unlocking the smartphone is not required to authenticate with the reader. © STid – MU_ULTRYS_V3.0.1_EN...
Page 142 Configuration name Site code Prohibit Deletion: prohibit the deletion of the virtual access card by the user. Only the administrator, via SECard (Settings / Credits / Delete your virtual access card) can delete it. © STid – MU_ULTRYS_V3.0.1_EN...
Page 143 SPECTRE NANO OSDP Note: if the Bluetooth configuration is configured on STid Mobile ID CSN: ® ® Step 2: Step 3: Remote mode is not accessible. © STid – MU_ULTRYS_V3.0.1_EN...
Page 144 The LED sequence is repeated as long as the reader is switched on and stops if communication via the internal USB is established (for configuration for example) or if the reader is reconfigured using the BLE or if the system is restarted. © STid – MU_ULTRYS_V3.0.1_EN...
Page 145 Ex: RSSI filter= -49dBm + Reversal not selected A tag that will have a RSSI value of -20dBm will be sent back, A tag that will have a RSSI value of -60dBm will not be sent back. © STid – MU_ULTRYS_V3.0.1_EN...
Page 146 Tag 3: AA 02 AB CD 00 00 00 00 00 00 00 03 Tag 4: AA 02 FF FF 00 00 00 00 00 00 00 03 Tags 1, 2 and 3 are not transmitted. Only tag 4 is transmitted. © STid – MU_ULTRYS_V3.0.1_EN...
Page 147 Both types of output are « Pull up to V+ » or « Open drain ». Status of outputs: select for each output the default state ‘Open’ or ‘Closed’ and if the state is maintained during the detection process. © STid – MU_ULTRYS_V3.0.1_EN...
Page 148 SPECTRE NANO OSDP Activate the relay on detection ‘OFF’. Activate the relay on detection ‘ON’. © STid – MU_ULTRYS_V3.0.1_EN...
Page 149 SPECTRE NANO OSDP Reading mode = Continuous reading without using input In this mode, the reader scan continuously. There is no action on input activation. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 150 SPECTRE NANO OSDP Activate the relay on detection ‘OFF’. Activate the relay on detection ‘ON’. © STid – MU_ULTRYS_V3.0.1_EN...
Page 151 Reading mode = Trigger of the reading by the event (use the input) In this mode, if the input is activate, the reader on the lane. Select the output type and default state for output. Activate the relay on detection ‘OFF’. Activate the relay on detection ‘ON’ © STid – MU_ULTRYS_V3.0.1_EN...
Page 152 RF detection and remains in this state as long as, at each scan is at least one detection Note: as long as the action is detected on the input, the output remains toggled. © STid – MU_ULTRYS_V3.0.1_EN...
Page 153: Step 6- Light And Sound Indicator Setting
LED: Color indicating the detection of an identifier by the antenna, as long as the reader does not receive a permanent OSDP_LED command. Buzzer: OFF or ON+option : Buzzer: indicating the detection of an identifier by the antenna, as long as the reader does not receive a permanent OSDP_BUZ command. © STid – MU_ULTRYS_V3.0.1_EN...
Page 155: Step 7- Reading & Communication Parameters
- A different private key for EPC and for Bluetooth ® - An identical private key for the EPC and for Bluetooth ® in this case, the value of the key is defined in the Bluetooth® configuration: © STid – MU_ULTRYS_V3.0.1_EN...
Page 156 The baudrate can be modified with the values: : Returns all of the data read.( osdp_RAW) Protocol Size in plain mode Size in secure mode RS485 1 to 62 bytes 1 to 6 bytes © STid – MU_ULTRYS_V3.0.1_EN...
Page 157 SPECTRE NANO OSDP Advanced options: The advanced options in this part depend on whether or not a Bluetooth® configuration is activated: Bluetooth ® Bluetooth ® Reading reading Advanced options activation mode mode © STid – MU_ULTRYS_V3.0.1_EN...
Page 158 Bluetooth configuration ‘Private ID reading mode otherwise CSN’ or ‘CSN only’ is active. ® Disabled: the response will be osdp_busy. Enable: the response will be osdp_ACK. Disabled: uses IEEE 0x2C17E0. Enabled: uses IEEE 0xF51BC0. © STid – MU_ULTRYS_V3.0.1_EN...
Page 159 SPECTRE NANO OSDP Note: If the "ID size" of the Bluetooth data is greater than "Size of the credential sent to the ® system": Note: © STid – MU_ULTRYS_V3.0.1_EN...
Page 160 • : ID feedback = WW XX YY ZZ • : ID feedback = ZZ YY XX WW • : ID feedback = AA BB CC DD • : ID feedback = DD CC BB AA © STid – MU_ULTRYS_V3.0.1_EN...
Page 161 Size of the credential sent to the system: Data sent to the system: AABBCCDD Example 4 : ID encoded in the Tag: AABBCCDDEEFF001122334455 Formatting: ID Formated: DDCCBBAA Size of the credential sent to the system: Data sent to the system: DDCCBBAA © STid – MU_ULTRYS_V3.0.1_EN...
Page 162 SPECTRE NANO OSDP 2nd case: UHF data formatting before uploading to the system with an active Bluetooth ® configuration: Possibility to format the UHF ID manually (ditto case 1) or to use the Bluetooth data format. ® © STid – MU_ULTRYS_V3.0.1_EN...
Page 163 : If beyond the Timeout no valid Bluetooth ® identifier is read, the reader starts again in UHF scan. Bluetooth then UHF: If beyond the Timeout no valid UHF identifier is read, the reader starts ® again in Bluetooth scan. ® © STid – MU_ULTRYS_V3.0.1_EN...
Page 164: Step 8- User Security Roles
SPECTRE NANO OSDP Step 8- User Security Roles ULTRYS allows to manage three different profiles by configuration file. Define an Administrator password to protect the configuration file. Define a User 1 password and select the corresponding rights. Define a User 2 password and select the corresponding rights.
Page 165: Step 9- Configuration Save And Protect
Administrator password. If this option is enabled, the reader can only be configured again via the USB connection. Authorize ULTRYS to retrieve and open the reader and UHF parameters from the reader and the configuration card. See 11-Open an existing configuration.
Page 166 SPECTRE NANO OSDP Authorize ULTRYS to retrieve and open the reader and Bluetooth parameters from the ® reader and the configuration card. See 11-Open an existing configuration. Select a directory and a file name to save The name and location of ‘Configuration Loaded’ indicates now the chosen name and location.
Page 168 SPECTRE NANO OSDP Print: allows printing of configuration information on a network, local or virtual printer (PDF). © STid – MU_ULTRYS_V3.0.1_EN...
Page 170: Reader Configuration Spectre Atx Read Only
SPECTRE ATX READ ONLY 7. Reader configuration SPECTRE ATX READ ONLY 7-1 ULTRYS settings ➢ Connect the SPECTRE ATX reader to the PC using the provided USB cable to load the configuration via serial link directly onto the reader. ➢ Connect an UHF encoder to the PC to load the configuration onto UHF SCB configuration card.
Page 171 Check the compatibility of the reader. Check the USB cable. Check the Baudrate reader: it must be fixed to 115200. Note: during the connectivity test on a UHF encoder, a sound and light signal (orange) will be emitted for 1 second. © STid – MU_ULTRYS_V3.0.1_EN...
Page 172: Create New Configuration
Step 4 does not exist in the SPECTRE ATX READ ONLY setup wizard Installation configuration Step 6 does not exist in the SPECTRE ATX READ ONLY setup wizard Reading & communication parameters User Security Roles Configuration save and protect © STid – MU_ULTRYS_V3.0.1_EN...
Page 173: Step 1- Uhf Frequency Band Regulation
Type the first characters to display a country or select the country in which the installation will be done. For a country which is not in the list, please contact STid: support@stid.com. To approve the feasibility to install your reader in the selected country, you can check the compatibility.
Page 174 Check the USB cable Check the communication with reader With reader part number Enter the first 5 characters of the reader part number Example: ATXR41, ATXR42, ATXR51…… Message: OK Message: the reference reader is not compatible with regulation selected. © STid – MU_ULTRYS_V3.0.1_EN...
Page 175: Step 2- Configuration Protection Loaded Into The Reader
If you lose this protection code, you won’t be able to reconfigure the reader again and the reader must be reset at the factory. To change the protection code, it will be necessary to know the current protection code. © STid – MU_ULTRYS_V3.0.1_EN...
Page 176: Step 3- Reader Configuration
You must select the firmware version that is compatible with your reader. To do so, you can manually select the reader and firmware version, or you can use the function "Auto detection – Connect and check my reader configuration". © STid – MU_ULTRYS_V3.0.1_EN...
Page 177 Message : NOK Check the USB cable Check the communication with reader With reader’s number reference Enter the first 6 characters of your reader’s reference number Examples: ATXR41, ATXR51, ATXR42 Message: NOK Check your reader’s reference number © STid – MU_ULTRYS_V3.0.1_EN...
Page 178: Step 4- Antenna Type Selection
Step 4- Antenna type selection The SPECTRE ATX reader only works with antenna embeded(ANT_UHF2). Step 4 does not exist in the SPECTRE ATX configuration wizard. Step 5- Installation configuration Name the lane Maximum 10 characters. For example, Entry1. © STid – MU_ULTRYS_V3.0.1_EN...
Page 179 Ex: RSSI filter = -49f=dBm + Reversal not selected A tag that will have a RSSI value of -20dBm will be sent back, A tag that will have a RSSI value of -60dBm will not be sent back. © STid – MU_ULTRYS_V3.0.1_EN...
Page 180 Tag 3: AA 02 AB CD 00 00 00 00 00 00 00 03 Tag 4: AA 02 FF FF 00 00 00 00 00 00 00 03 Tags 1, 2 and 3 are not transmitted. Only tag 4 is transmitted. © STid – MU_ULTRYS_V3.0.1_EN...
Page 181 Select the reading mode, the output settings depend on this mode. Both types of output are Pull up to V+ or Open drain. Status of outputs: select for each output the default state ‘Open’ or ‘Closed’ and if the state is maintained during the detection process. © STid – MU_ULTRYS_V3.0.1_EN...
Page 182 SPECTRE ATX READ ONLY Reading mode = Continuous reading without using input In this mode, the reader scan continuously. There is no action on input activation. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 183 Reading mode = Trigger of the reading by the event If Input is activated, the reader scans on the lane. The reading duration is defined in ‘Advanced settings’. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 184 SPECTRE ATX READ ONLY Reading mode = Output activation (triggered on outputs) An action on Input toggles the corresponding output regardless of RF function of the reader. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 185: Step 6- Light Indicator Configuration
Note: as long as the action is detected on the input, the output remains toggled. Step 6- Light indicator configuration The SPECTRE ATX reader is not equipped with an LED card or a Buzzer. Step 6 does not exist in the SPECTRE ATX setup wizard. © STid – MU_ULTRYS_V3.0.1_EN...
Page 186: Step 7- Reading & Communication Parameters
Note: After setting an EPC security key, if you return to step 5 with the Previous button, and you set an EPC filter, then returning to step 7, the "EPC ID Security" checkmark is displayed. in gray, the key field is still accessible but not taken into account © STid – MU_ULTRYS_V3.0.1_EN...
Page 187 Add STX (0x02) and ETX (0x03) in the frame. Carriage return (0x0D). Line feed (0x0A). Checksum byte by XORing of all previously characters without the STX. ASCII If this option is activated, the Data will be sent in ASCII mode. © STid – MU_ULTRYS_V3.0.1_EN...
Page 188 SPECTRE ATX READ ONLY Wiegand 26 bits - 3i Note: the graphic indicating the lanes, depends on the configuration of the number of antennas/lanes. Wiegand with LRC customized size Wiegand customized size Decimal Clock&Data – Iso 2B © STid – MU_ULTRYS_V3.0.1_EN...
Page 189 • : ID feedback = WW XX YY ZZ • : ID feedback = ZZ YY XX WW • : ID feedback = AA BB CC DD • : ID feedback = DD CC BB AA © STid – MU_ULTRYS_V3.0.1_EN...
Page 190 SPECTRE ATX READ ONLY The reader emits the credential code present in the field only once during this time. This time is adjustable from 0 to 30 seconds. © STid – MU_ULTRYS_V3.0.1_EN...
Page 191: Step 8- User Security Roles
SPECTRE ATX READ ONLY Step 8- User Security Roles ULTRYS allows to manage three different profiles by configuration file. Define an Administrator password to protect the configuration file. Define a User 1 password and select the corresponding rights. Define a User 2 password and select the corresponding rights.
Page 192: Step 9- Configuration Save And Protect
To protect the configuration file, you can define a password. This password is different from Administrator password. Select a directory and a file name to save. The name and location of ‘Configuration Loaded’ indicates now the chosen name and location. © STid – MU_ULTRYS_V3.0.1_EN...
Page 193 SPECTRE ATX READ ONLY Get a summary of the configuration created. Print: allows printing of configuration information on a network, local or virtual printer (PDF). © STid – MU_ULTRYS_V3.0.1_EN...
Page 194: Reader Configuration Spectre Atx Osdp
SPECTRE ATX OSDP 8. Reader configuration SPECTRE ATX OSDP™ 8-1 ULTRYS settings ➢ Connect the SPECTRE ATX reader to the PC using the provided USB cable to load the configuration via serial link directly onto the reader. ➢ Connect an UHF encoder to the PC to load the configuration onto UHF OCB configuration card.
Page 195 Check the compatibility of the reader. Check the USB cable. Check the Baudrate reader: it must be fixed to 115200. Note: during the connectivity test on a UHF encoder, a sound and light signal (orange) will be emitted for 1 second. © STid – MU_ULTRYS_V3.0.1_EN...
Page 196: Create New Configuration
Step 4 does not exist in the SPECTRE ATX OSDP™ configuration wizard Installation configuration Step 6 does not exist in the SPECTRE ATX OSDP ™ configuration wizard Reading & communication parameters User Security Roles Configuration save and protect © STid – MU_ULTRYS_V3.0.1_EN...
Page 197: Step 1- Uhf Frequency Band Regulation
Type the first characters to display a country or select the country in which the installation will be done. For a country which is not in the list, please contact STid: support@stid.com. To approve the feasibility to install your reader in the selected country, you can check the compatibility.
Page 198 Check the USB cable Check the communication with reader With reader part number Enter the first 5 characters of the reader part number Example: ATXW43, ATXW53. Message: OK Message: the reference reader is not compatible with regulation selected. © STid – MU_ULTRYS_V3.0.1_EN...
Page 199: Step 2- Configuration Protection Loaded Into The Reader
If you lose this protection code, you won’t be able to reconfigure the reader again and the reader must be reset at the factory. To change the protection code, it will be necessary to know the current protection code. © STid – MU_ULTRYS_V3.0.1_EN...
Page 200: Step 3- Reader Configuration
You must select the firmware version that is compatible with your reader. To do so, you can manually select the reader and firmware version, or you can use the function "Auto detection – Connect and check my reader configuration". © STid – MU_ULTRYS_V3.0.1_EN...
Page 201 Message : NOK Check the USB cable Check the communication with reader With reader’s number reference Enter the first 6 characters of your reader’s reference number Examples: SLAR41, SLAR51, SMAR41 Message: NOK Check your reader’s reference number © STid – MU_ULTRYS_V3.0.1_EN...
Page 202: Step 4- Antenna Type Selection
Step 4- Antenna type selection The SPECTRE ATX reader works with a built-in antenna. Step 4 does not exist in the SPECTRE ATX setup wizard. Step 5- Installation configuration Name the lane Maximum 10 characters. For example, Entry1. © STid – MU_ULTRYS_V3.0.1_EN...
Page 203 Ex: RSSI filter = -49f=dBm + Reversal not selected A tag that will have a RSSI value of -20dBm will be sent back, A tag that will have a RSSI value of -60dBm will not be sent back. © STid – MU_ULTRYS_V3.0.1_EN...
Page 204 Tag 3: AA 02 AB CD 00 00 00 00 00 00 00 03 Tag 4: AA 02 FF FF 00 00 00 00 00 00 00 03 Tags 1, 2 and 3 are not transmitted. Only tag 4 is transmitted. © STid – MU_ULTRYS_V3.0.1_EN...
Page 205 Select the reading mode, the output settings depend on this mode. Both types of output are Pull up to V+ or Open drain. Status of outputs: select for each output the default state ‘Open’ or ‘Closed’ and if the state is maintained during the detection process. © STid – MU_ULTRYS_V3.0.1_EN...
Page 206 SPECTRE ATX OSDP Reading mode = Continuous reading without using input In this mode, the reader scan continuously. There is no action on input activation. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 207 Reading mode = Trigger of the reading by the event If Input is activated, the reader scans on the lane. The reading duration is defined in ‘Advanced settings’. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 208: Step 6- Light Indicator Configuration
(physically on the BUS + 200ms Step 6- Light indicator configuration The SPECTRE ATX reader is not equipped with an LED card or a Buzzer. Step 6 does not exist in the SPECTRE ATX setup wizard. © STid – MU_ULTRYS_V3.0.1_EN...
Page 209: Step 7- Reading & Communication Parameters
Note: After setting an EPC security key, if you return to step 5 with the Previous button, and you set an EPC filter, then returning to step 7, the "EPC ID Security" checkmark is displayed. in gray, the key field is still accessible but not taken into account. © STid – MU_ULTRYS_V3.0.1_EN...
Page 210 • : ID feedback = WW XX YY ZZ • : ID feedback = ZZ YY XX WW • : ID feedback = AA BB CC DD • : ID feedback = DD CC BB AA © STid – MU_ULTRYS_V3.0.1_EN...
Page 211 SPECTRE ATX OSDP The reader emits the credential code present in the field only once during this time. This time is adjustable from 0 to 30 seconds. © STid – MU_ULTRYS_V3.0.1_EN...
Page 212: Step 8- User Security Roles
SPECTRE ATX OSDP Step 8- User Security Roles ULTRYS allows to manage three different profiles by configuration file. Define an Administrator password to protect the configuration file. Define a User 1 password and select the corresponding rights. Define a User 2 password and select the corresponding rights ©...
Page 213: Step 9- Configuration Save And Protect
To protect the configuration file, you can define a password. This password is different from Administrator password. Select a directory and a file name to save. The name and location of ‘Configuration Loaded’ indicates now the chosen name and location. © STid – MU_ULTRYS_V3.0.1_EN...
Page 214 SPECTRE ATX OSDP Get a summary of the configuration created. Print: allows printing of configuration information on a network, local or virtual printer (PDF) © STid – MU_ULTRYS_V3.0.1_EN...
Page 216: Reader Configuration Spectre Atx4 Read Only
➢ Connect the SPECTRE ATX4 reader to the PC using the provided USB cable to load the configuration via serial link directly onto the reader. ➢ Connect an UHF encoder to the PC to load the configuration onto UHF SCB configuration card. © STid – MU_ULTRYS_V3.0.1_EN...
Page 217 Check the compatibility of the reader. Check the USB cable. Check the Baudrate reader: it must be fixed to 115200. Note: during the connectivity test on a UHF encoder, a sound and light signal (orange) will be emitted for 1 second. © STid – MU_ULTRYS_V3.0.1_EN...
Page 218: Create New Configuration
Step 4 does not exist in the SPECTRE ATX4 READ ONLY setup wizard Installation configuration Step 6 does not exist in the SPECTRE ATX4 READ ONLY setup wizard Reading & communication parameters User Security Roles Configuration save and protect © STid – MU_ULTRYS_V3.0.1_EN...
Page 219: Step 1- Uhf Frequency Band Regulation
Type the first characters to display a country or select the country in which the installation will be done. For a country which is not in the list, please contact STid: support@stid.com. To approve the feasibility to install your reader in the selected country, you can check the compatibility.
Page 220 Check the USB cable Check the communication with reader With reader part number Enter the first 5 characters of the reader part number Example: ATX4R41, ATX4R42, ATX4R51…… Message: OK Message: the reference reader is not compatible with regulation selected. © STid – MU_ULTRYS_V3.0.1_EN...
Page 221: Step 2- Configuration Protection Loaded Into The Reader
If you lose this protection code, you won’t be able to reconfigure the reader again and the reader must be reset at the factory. To change the protection code, it will be necessary to know the current protection code. © STid – MU_ULTRYS_V3.0.1_EN...
Page 222: Step 3- Reader Configuration
You must select the firmware version that is compatible with your reader. To do so, you can manually select the reader and firmware version, or you can use the function "Auto detection – Connect and check my reader configuration". © STid – MU_ULTRYS_V3.0.1_EN...
Page 223 Message : NOK Check the USB cable Check the communication with reader With reader’s number reference Enter the first 6 characters of your reader’s reference number Examples: ATX4R41, ATX4R51, ATX4R42 Message: NOK Check your reader’s reference number © STid – MU_ULTRYS_V3.0.1_EN...
Page 224: Step 4- Antenna Type Selection
Use ‘Add /Delete lane’ to configure the number of lanes you will use in your application. The default setting is one antenna on the first lane. For more information about the possible combination please refer to the document NA_SPECTRE. © STid – MU_ULTRYS_V3.0.1_EN...
Page 225 RF ports are assigned in order to add the antennas in the configuration wizard.When an antenna is removed from the configuration, the RF port connection for other antennas does not change. Example: Ant 2 deleted from lane 1 and added to lane 2. © STid – MU_ULTRYS_V3.0.1_EN...
Page 226 SPECTRE ATX 4 READ ONLY Select the cable length for each antenna For each antenna, select the cable length you would like to use between antenna and reader. © STid – MU_ULTRYS_V3.0.1_EN...
Page 227 Ex: RSSI filter= -49dBm + Reversal not selected A tag that will have a RSSI value of -20dBm will be sent back, A tag that will have a RSSI value of -60dBm will not be sent back. © STid – MU_ULTRYS_V3.0.1_EN...
Page 228 Scan time, EPC filter and RRSI filter settings are the same for antennas on the same lane. The cable length and RF power antenna are set for each antenna. Example 1: 4 antennas on lane 1. Example 2: 2 antennas on lane 1 et 2 antennes on lane 2. © STid – MU_ULTRYS_V3.0.1_EN...
Page 229 Tag 3: AA 02 AB CD 00 00 00 00 00 00 00 03 Tag 4: AA 02 FF FF 00 00 00 00 00 00 00 03 Tags 1, 2 and 3 are not transmitted. Only tag 4 is transmitted. © STid – MU_ULTRYS_V3.0.1_EN...
Page 230 Both types of output are « Pull up to V+ » or « Open drain ». Status of outputs: select for each output the default state ‘Open’ or ‘Closed’ and if the state is maintained during the detection process. © STid – MU_ULTRYS_V3.0.1_EN...
Page 231 SPECTRE ATX 4 READ ONLY Reading mode = Continuous reading without using inputs In this mode, the reader scan continuously. There is no action on input activation. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 232 If an Input is activated (In1, In2, In3 or In4), the reader scans on all lanes set. The duration of the reading is defined in ‘Advanced settings’. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 233 Reading mode = Trigger of the reading on the event lane If an Input is activated, the reader scans on the corresponding lane. The reading duration is defined in ‘Advanced settings’. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 234 SPECTRE ATX 4 READ ONLY Reading mode = Output activation (triggered on outputs) An action on Input toggles the corresponding output regardless of RF function of the reader. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 235: Step 6- Light Indicator Configuration
Note: as long as the action is detected on the input, the output remains toggled. Step 6- Light indicator configuration Step 6 does not exist in the SPECTRE ATX4 configuration wizard. © STid – MU_ULTRYS_V3.0.1_EN...
Page 236: Step 7- Reading & Communication Parameters
Note: After setting an EPC security key, if you return to step 5 with the Previous button, and you set an EPC filter, then returning to step 7, the "EPC ID Security" checkmark is displayed. in gray, the key field is still accessible but not taken into account. © STid – MU_ULTRYS_V3.0.1_EN...
Page 237 Add STX (0x02) and ETX (0x03) in the frame. Carriage return (0x0D). Line feed (0x0A). Checksum byte by XORing of all previously characters without the STX. ASCII If this option is activated, the Data will be sent in ASCII mode. © STid – MU_ULTRYS_V3.0.1_EN...
Page 238 SPECTRE ATX 4 READ ONLY Wiegand 26 bits- 3i Note: the graphic indicating the lanes, depends on the configuration of the number of antennas/lanes. Wiegand with LRC customized size Wiegand customized size Decimal Clock&Data – Iso 2B © STid – MU_ULTRYS_V3.0.1_EN...
Page 239 • : ID feedback = WW XX YY ZZ • : ID feedback = ZZ YY XX WW • : ID feedback = AA BB CC DD • : ID feedback = DD CC BB AA © STid – MU_ULTRYS_V3.0.1_EN...
Page 240 SPECTRE ATX 4 READ ONLY The reader emits the credential code present in the field only once during this time. This time is adjustable from 0 to 30 seconds. © STid – MU_ULTRYS_V3.0.1_EN...
Page 241: Step 8- User Security Roles
SPECTRE ATX 4 READ ONLY Step 8- User Security Roles ULTRYS allows to manage three different profiles by configuration file. Define an Administrator password to protect the configuration file. Define a User 1 password and select the corresponding rights. Define a User 2 password and select the corresponding rights.
Page 242: Step 9- Configuration Save And Protect
To protect the configuration file, you can define a password. This password is different from Administrator password. Select a directory and a file name to save. The name and location of ‘Configuration Loaded’ indicates now the chosen name and location. © STid – MU_ULTRYS_V3.0.1_EN...
Page 243 SPECTRE ATX 4 READ ONLY Get a summary of the configuration created Print: allows printing of configuration information on a network, local or virtual printer (PDF). © STid – MU_ULTRYS_V3.0.1_EN...
Page 244: Reader Configuration Spectre Atx4 Osdp
SPECTRE ATX 4 OSDP 10. Reader configuration SPECTRE ATX4 OSDP™ 10-1 ULTRYS settings ➢ Connect the SPECTRE ATX4 reader to the PC using the provided USB cable to load the configuration via serial link directly onto the reader. ➢ Connect an UHF encoder to the PC to load the configuration onto UHF OCB configuration card.
Page 245 Check the compatibility of the reader. Check the USB cable. Check the Baudrate reader: it must be fixed to 115200. Note: during the connectivity test on a UHF encoder, a sound and light signal (orange) will be emitted for 1 second. © STid – MU_ULTRYS_V3.0.1_EN...
Page 246: Create New Configuration
Step 4 does not exist in the SPECTRE ATX4 OSDP™ configuration wizard Installation configuration Step 6 does not exist in the SPECTRE ATX4 OSDP™ configuration wizard Reading & communication parameters User Security Roles Configuration save and protect © STid – MU_ULTRYS_V3.0.1_EN...
Page 247: Step 1- Uhf Frequency Band Regulation
Type the first characters to display a country or select the country in which the installation will be done. For a country which is not in the list, please contact STid: support@stid.com. To approve the feasibility to install your reader in the selected country, you can check the compatibility.
Page 248 Check the USB cable Check the communication with reader With reader part number Enter the first 5 characters of the reader part number Example: ATX4W43, ATX4W53 Message: OK Message: the reference reader is not compatible with regulation selected. © STid – MU_ULTRYS_V3.0.1_EN...
Page 249: Step 2- Configuration Protection Loaded Into The Reader
If you lose this protection code, you won’t be able to reconfigure the reader again and the reader must be reset at the factory. To change the protection code, it will be necessary to know the current protection code. © STid – MU_ULTRYS_V3.0.1_EN...
Page 250: Step 3- Reader Configuration
You must select the firmware version that is compatible with your reader. To do so, you can manually select the reader and firmware version, or you can use the function "Auto detection – Connect and check my reader configuration". © STid – MU_ULTRYS_V3.0.1_EN...
Page 251 Message : NOK Check the USB cable Check the communication with reader With reader’s number reference Enter the first 6 characters of your reader’s reference number Examples: ATX4W43, ATX4W53 Message: NOK Check your reader’s reference number © STid – MU_ULTRYS_V3.0.1_EN...
Page 252: Step 4- Antenna Type Selection
Use ‘Add /Delete lane’ to configure the number of lanes you will use in your application. The default setting is one antenna on the first lane. For more information about the possible combination please refer to the document NA_SPECTRE. © STid – MU_ULTRYS_V3.0.1_EN...
Page 253 SPECTRE ATX 4 OSDP In OSDP™, the lane number corresponds to the "Reader Number": © STid – MU_ULTRYS_V3.0.1_EN...
Page 254 RF ports are assigned in order to add the antennas in the configuration wizard.When an antenna is removed from the configuration, the RF port connection for other antennas does not change. Example: Ant 2 deleted from lane 1 and added to lane 2. © STid – MU_ULTRYS_V3.0.1_EN...
Page 255 SPECTRE ATX 4 OSDP Select the cable length for each antenna For each antenna, select the cable length you would like to use between antenna and reader. © STid – MU_ULTRYS_V3.0.1_EN...
Page 256 A tag that will have a RSSI value of -60dBm will not be sent back. Scan time, EPC filter and RRSI filter settings are the same for antennas on the same lane. The cable length and RF power antenna are set for each antenna. © STid – MU_ULTRYS_V3.0.1_EN...
Page 257 SPECTRE ATX 4 OSDP Example 1: 4 antennas on lane 1. Example 2: 2 antennas on lane 1 et 2 antennes on lane 2. © STid – MU_ULTRYS_V3.0.1_EN...
Page 258 Tag 3: AA 02 AB CD 00 00 00 00 00 00 00 03 Tag 4: AA 02 FF FF 00 00 00 00 00 00 00 03 Tags 1, 2 and 3 are not transmitted. Only tag 4 is transmitted. © STid – MU_ULTRYS_V3.0.1_EN...
Page 259 Both types of output are « Pull up to V+ » or « Open drain ». Status of outputs: select for each output the default state ‘Open’ or ‘Closed’ and if the state is maintained during the detection process. © STid – MU_ULTRYS_V3.0.1_EN...
Page 260 SPECTRE ATX 4 OSDP Reading mode = Continuous reading without using inputs In this mode, the reader scan continuously. There is no action on input activation. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 261 If an Input is activated (In1, In2, In3 or In4), the reader scans on all lanes set. The duration of the reading is defined in ‘Advanced settings’. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 262 Reading mode = Trigger of the reading on the event lane If an Input is activated, the reader scans on the corresponding lane. The reading duration is defined in ‘Advanced settings’. Select the output type and default state for output. © STid – MU_ULTRYS_V3.0.1_EN...
Page 263: Step 6- Light Indicator Configuration
200ms Trigger of the An action on Input reading on the activates the scan by lane event lane on lane Step 6- Light indicator configuration Step 6 does not exist in the SPECTRE ATX4 configuration wizard © STid – MU_ULTRYS_V3.0.1_EN...
Page 264: Step 7- Reading & Communication Parameters
Note: After setting an EPC security key, if you return to step 5 with the Previous button, and you set an EPC filter, then returning to step 7, the "EPC ID Security" checkmark is displayed. in gray, the key field is still accessible but not taken into account. © STid – MU_ULTRYS_V3.0.1_EN...
Page 265 • : ID feedback = WW XX YY ZZ • : ID feedback = ZZ YY XX WW • : ID feedback = AA BB CC DD • : ID feedback = DD CC BB AA © STid – MU_ULTRYS_V3.0.1_EN...
Page 266 SPECTRE ATX 4 OSDP The reader emits the credential code present in the field only once during this time. This time is adjustable from 0 to 30 seconds. © STid – MU_ULTRYS_V3.0.1_EN...
Page 267: Step 8- User Security Roles
SPECTRE ATX 4 OSDP Step 8- User Security Roles ULTRYS allows to manage three different profiles by configuration file. Define an Administrator password to protect the configuration file. Define a User 1 password and select the corresponding rights. Define a User 2 password and select the corresponding rights.
Page 268: Step 9- Configuration Save And Protect
To protect the configuration file, you can define a password. This password is different from Administrator password. Select a directory and a file name to save. The name and location of ‘Configuration Loaded’ indicates now the chosen name and location. © STid – MU_ULTRYS_V3.0.1_EN...
Page 269 SPECTRE ATX 4 OSDP Get a summary of the configuration created. Print: allows printing of configuration information on a network, local or virtual printer (PDF). © STid – MU_ULTRYS_V3.0.1_EN...
Page 270: Open An Existing Configuration
11. Open an existing configuration CAUTION: To open an SNA configuration, use ULTRYS v3.0.X minimum. 11.1 Configuration file © STid – MU_ULTRYS_V3.0.1_EN...
Page 271 1- Select a configuration file .ucg on your PC or USB stick. 2- If the file has been protected for reading, enter the password and confirm. Select the profile to use and enter the corresponding password. Please confirm. © STid – MU_ULTRYS_V3.0.1_EN...
Page 272: Reader Via Usb
11.2 Reader via USB Connect the reader via USB cable provided. 2- Configure the communication parameters. 3- Please confirm. 4- Select the profile to use and the corresponding password. Please confirm. © STid – MU_ULTRYS_V3.0.1_EN...
Page 273 5- ULTRYS then displays the configuration wizard with all settings loaded from the reader. Check connection and COM port settings. Note for an SNA configuration: Depending on the permissions defined when creating the SNA reader configuration in step 9, the UHF and / or Bluetooth settings will not be loaded ®...
Page 274: Configuration Badge (Scb/Ocb Uhf)
Connect an UHF encoder (ARC, STR or GAT Desk). 2- Configure the communication settings. 3- Present the SCB/OCB UHF to the encoder. 4- Please confirm. 5- Select the profile to use and the corresponding password. Please confirm. © STid – MU_ULTRYS_V3.0.1_EN...
Page 275 6- ULTRYS then displays the configuration wizard with all settings loaded from the SCB/OCB UHF. Check connection and COM port settings. Note for an SNA configuration: Depending on the permissions defined when creating the SNA reader configuration in step 9,...
Page 276: Load The Configuration Into The Reader
12. Load the configuration into the reader © STid – MU_ULTRYS_V3.0.1_EN...
Page 277: Loading The Configuration Into The Reader
12.1 Loading the configuration into the reader 1- Connect a reader via USB cable. 2- Configure the communication settings. 3- Configure the latency of com port to 1 Double click on the good COM port number. Open Advanced… Put Latency on “16” © STid – MU_ULTRYS_V3.0.1_EN...
Page 278 Load. Close. ULTRYS then displays the home page. Error the site code of the SPECTRE reader is not the same in configuration file. The selected RF regulation is not compatible with the reader. The reader type of the current configuration is not compatible with the connected reader.
Page 279: Configuration Card (Scb/Ocb Uhf)
3- Present a compatible SCB/OCB UHF card to the encoder. 4- Load 5- Close. ULTRYS then displays the home page. The tag presented to the encoder is not compatible to create a SCB/OCB UHF or is not in RF Field.
Page 280: User Credentials
The user credentials encoding is done in three steps. To move from one step to another, you must click on “Next”. Configuration details loaded User ID definition Encoding tags Step 1- Configuration details loaded Check the configuration loaded is the correct one to use or open the configuration to use. © STid – MU_ULTRYS_V3.0.1_EN...
Page 281 TLTA-W75B-943_S (TeleTag V4-UHF FastID Programmable Removable Windshield tag- Broadband) TMSW94B3361 (IronTag 360-360 Flexible on-metal tag-Broadband-Impinj MonzaX2K- Black) CCTW490_AN (UHF EPC1 Gen2 Impinj Monza 4 programmable ISO Prox card) ETA-W75B-574BE10 (ETA v2 – Self destroying programmable adhesive label). © STid – MU_ULTRYS_V3.0.1_EN...
Page 282 If an EPC filter has been set in the ‘Advanced settings’, select ‘EPC Filter’ and the corresponding lane to encode automatically the value of the EPC filter into the user credential. Example: In this example, if the lane 1 is selected, the user credential will be encoded with the EPC filter © STid – MU_ULTRYS_V3.0.1_EN...
Page 283: Step 2 - User Id Definition
For Wiegand protocols only (except 3i), it is possible to enter the identifier in Decimal or Hexadecimal. Enter directly the ID value in the field and click Next. Use to encode a single tag or a specific value. © STid – MU_ULTRYS_V3.0.1_EN...
Page 284 Fill in each corresponding field, the beginning, the end and the increment to generate the list of user IDs to encode. This mode allows you to import lists in Excel format to be used for the user IDs programming. © STid – MU_ULTRYS_V3.0.1_EN...
Page 285 This mode allows you to import lists in Text format to be used for programming the user IDs. Select the correct Delimiter or CR/LF. © STid – MU_ULTRYS_V3.0.1_EN...
Page 286: Step 3- Encoding Tag
Step 3- Encoding tag Present the user credential which you would like to encode to the encoder and click on this button. The credential data reading is written on Operations windows. © STid – MU_ULTRYS_V3.0.1_EN...
Page 287: Annex 1: Using The Epc Code Feedback Format And Epc Filter
The feedback modes allow the full compatibility with existing credential. To encode the credential, we would prefer standard mode (mode 1). Using mode Encoding the value 1122334455 on 5 bytes without EPC filter. Value ascended Settings Value encoded by ULTRYS by the Reader 000000000000001122334455 1122334455 000000000000001122334455 5544332211 112233445500000000000000...
Page 288: Using Epc Filter And Modes
Using EPC filter and modes Encoding the value 1122334455 on 5 bytes with EPC filter ‘AA’. Settings Value ascended Value encoded by ULTRYS by the Reader AA0000000000001122334455 1122334455 AA0000000000001122334455 5544332211 AA2233445500000000000000 AA22334455 AA2233445500000000000000 55443322AA 00000000000000AA22334455 AA22334455 11223344550000AA00000000 1122334455 © STid – MU_ULTRYS_V3.0.1_EN...
Page 289: Using Secure Mode
Using secure mode Encoding the value 1122334455 on 5 bytes in secure mode. Encoded value on 16 bytes Value ascended encrypted. by the Reader 789C9B12C733B3657EF030CE17F250BE 1122334455 © STid – MU_ULTRYS_V3.0.1_EN...
Page 291: Clock & Data 2B
1101 0 0000 1 1000 0 0000 1 1010 1 0110 1 0100 0 1110 0 1000 0 1111 1 1111 1 0000 2 009 6 16 Zeros Char.1 Char.2 Char.3 Char.4 Char…. Char.10 Char.11 Char.12 Char.13 Zero © STid – MU_ULTRYS_V3.0.1_EN...
Page 292: Clock & Data 2H
1101 0 0000 1 1000 0 0000 1 1010 1 ..0110 1 0100 0 1110 0 1000 0 1111 1 0010 1 000... 16 Zeros Char.1 Char.2 Char.3 Char.4 Char… Char.7 Char.8 Char.9 Char.10 Zero © STid – MU_ULTRYS_V3.0.1_EN...
Page 293: Protocoles Wiegand
Byte 1 Byte 2 – Byte 3 Structure Site Code Card Code Max Value 0xFF - 255 in decimal 0xFF FF - 65535 in decimal Example 0x0F - 15 in decimal 0xC350 - 50000 in decimal © STid – MU_ULTRYS_V3.0.1_EN...
Page 294: Wiegand 3Ca
For the hexadecimal code “0x 01001950C3”, the frame sent will be: 0000 0001 0000 0000 0001 1001 0101 0000 1100 0011 0011 Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Digit.8 Digit 9 Digit 10 © STid – MU_ULTRYS_V3.0.1_EN...
Page 295: Wiegand 3La
For the hexadecimal code “0x 01001950C3”, the frame sent will be: 0000 0001 0000 0000 0001 1001 0101 0000 1100 0011 Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Digit 8 Digit 9 Digit 10 © STid – MU_ULTRYS_V3.0.1_EN...
Page 296: Wiegand 3Eb
For the hexadecimal code “0x 0F3129DD3B “, the frame sent will be: 0011 0001 0010 1001 1101 1101 0011 1011 Parity Digit 1 Digit 2 Digit 3 Digit 4 Digit 5 Digit 6 Digit 7 Digit 8 Digit 9 Parity © STid – MU_ULTRYS_V3.0.1_EN...
Page 297: Revision
Add SPECTRE ATX / ATX4 READ ONLY / OSDP ™ Redesign of the document: one chapter per type of reader 05/10/2021 Addition of SPECTER NANO Read only and OSDP ™ 04/03/2022 3.0.1 Bluetooth® activation by sensor new distance added b © STid – MU_ULTRYS_V3.0.1_EN...

Stid ultrys User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for Stid ultrys

Summary of Contents for Stid ultrys

Table of Contents
