STARZ ENTERTAINMENT DSR-7400 SERIES QUICK START GUIDE
RF INPUTS: Connect RF inputs as labeled below.
ASI OUTPUTS: Connect ASI (or optional* IP) outputs as labeled below.
SIGNAL LOCK: Enter frequency and modulation parameters in the Quick Install menu to gain signal lock.
AUTHORIZATION: Contact Starz Affiliate Support for signal authorizations. (888) 783-2275, Opt. #2
ASI OUTPUTS
RF INPUTS
Hit the "OK" button with "Quick Install" highlighted as shown.
SIGNAL LOCK
Write down UA 1 and UA 2, as you will need these when calling 888-783-2275, Opt. #2 for authorization.
AUTHORIZATION
Transcoded
SERVICES
G13-V
G15-V
PAGE 1 OF 2 (SEE REVERSE)
*GigE
OUTPUT
Set and verify the following fields shown below:
RF Port 1
Input Port RF Port 1 or RF Port 3
16APSK
Modulation Mode DVBS2
1110.00 17
Transponder 17 or 20
32.500
Symbol Rate 32.500
v. T2
