Operation Manual
Portable Band Saw
62850
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps, and technical data can differ insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.
Advertisement
Related Manuals for XPOtool 62850
Summary of Contents for XPOtool 62850
- Page 1 Operation Manual Portable Band Saw 62850 Illustration similar, may vary depending on model Read and follow the operating instructions and safety information before using for the first time. Technical changes reserved! Due to further developments, illustrations, functioning steps, and technical data can differ insignificantly.
- Page 2 To allow for a smooth execution of your complaint or return, it is important to contact our customer service team before returning the goods. Returns Department WilTec Wildanger Technik GmbH Königsbenden 28 52249 Eschweiler E-mail: service@wiltec.info Tel: +49 2403 55592–0 Fax: +49 2403 55592–15 https://www.XPOtool.com Item 62850 Page 2 The Tool Experts 05 2022-1...
- Page 3 Do not expose the device to rain, other sources of water, or high air humidity. Protection class 2 In correspondence with the essential effective safety standards of the European rules https://www.XPOtool.com Item 62850 Page 3 The Tool Experts 05 2022-1...
- Page 4 Adjusting tools might get caught up in moving parts and cause damage to the device as well as severe injuries. • Do not overreach and always ensure a safe stand. https://www.XPOtool.com Item 62850 Page 4 The Tool Experts 05 2022-1...
- Page 5 Maintain labels and nameplates on the tool. These carry important safety information and must remain readable. • Always be sure to prepare to begin work before turning on the tool to avoid unnecessarily star- ting the same. https://www.XPOtool.com Item 62850 Page 5 The Tool Experts 05 2022-1...
- Page 6 Always make sure to let the moving parts of the tool come to a complete halt before placing it anywhere. Never attempt to forcefully stop the rotation of the accessory. https://www.XPOtool.com Item 62850 Page 6 The Tool Experts 05 2022-1...
- Page 7 4. Place the guide bar (G) against the workpiece, keeping the blade at a 90° angle to the work- piece. 5. Turn the band saw on and allow it to come reach full speed before making a cut. 6. Adjust the speed by tuning the speed dial (E). https://www.XPOtool.com Item 62850 Page 7 The Tool Experts 05 2022-1...
- Page 8 Do not attempt to clean ventilation slots by inserting pointed objects through openings. Technical specification Voltage (V) 220–240 Frequency (㎐) Power (W) 1100 Saw blade speed (㎧) 0,7–2,4 Cutting capacity (㎜) 127 Protection class https://www.XPOtool.com Item 62850 Page 8 The Tool Experts 05 2022-1...
- Page 9 Explosion views and parts list № Name Tension handle External carbon brush Auxiliary handle Motor housing Speed dial On/off switch Guide bar Blade Screw Guide bearing Power switch to L LED light https://www.XPOtool.com Item 62850 Page 9 The Tool Experts 05 2022-1...
- Page 10 D-52249 Eschweiler Important notice: The reprint or reproduction, even of excerpts, and any commercial use, even in part, of this instruction manual require the written permission of WilTec Wildanger Technik GmbH. https://www.XPOtool.com Item 62850 Page 10 The Tool Experts 05 2022-1...
